Vacuum Compressor Dealers

• Material: Matel
• Weight: 0-25Kg
• Country of Origin: India

We are offering dry vacuum compressors. Indvacuum dry vacuum compressors simplicity of design with only one shaft and direct drive produces robust, long-lasting vacuum pumps with low maintenance and running costs. These vacuum pumps operate completely oil-free; the individual chambers are separated by long-life vanes. Already featuring integrated intake filters and control valves, these vacuum pumps can be fitted with other accessories without a problem. The compact cover ensures low noise and heat emission. Optional corrosion protection also makes these vacuum pumps suitable for extracting moist air. characteristics technology:rotary vane number of stages:single-stage lubrication:dry applications:industrial other characteristics:direct-drive

These Dry Vacuum Pumps are ment to achive vacuum upto 750 mm of HG. SUDARSHAN ENGINEERING manufactures single & two stage Air Cooled, Reciprocating, Single Acting Dry Vacuum Pumps, which are ideal for Liquid Transfer, Ceramic Industries, Paper handling, Lamination Plants etc.

We are offering water ring vacuum pumps, vacuum compressors . max: vacuum attained-710 mm of mercury at 30 c inlet water – temperature, barometric pr of 760 mm of mercury.

This Twin -Lobe Vacuum Blowers have been redesigned to incorporate the latest technology for reduced noise and vibration. These heavy-duty rotary positive vacuum blowers are designed for continuous service for many Applications & operations.    COMPRESSOR USED AS BOOSTER Vacuum Boosters are used in applications where fast pump down times are required. These compressors are used to enhance the performance, ultimate vacuum and pumping speed of oil sealed/water ring type vacuum pumps.   We can use these Twin Lobe Low pressure compressors with the waterring / Oil Seal Vacuum pump to build up a high vacuum system which can capable to create 1 MM HG absolute pressure.   COMPRESSOR USED IN VACUUM DUTY These twin lobe low pressure compressors are being used in vacuum duty.  In vacuum duty the compressor can create 0.6 Kg/cm2 Pressure.

We offer Double Stage Water Ring Vacuum Pumps & Compressors. HTC Liquid ring gas pumps are rotary displacement pumps. A circulating auxiliary fluid normally water, absorbs the driving power supplied to the impellers and transmits it to the gas to be compressed. Shaft and Impellers are the only moving components. They do not have sliding contact with fixed pump components. The gaps which exists are filled with the auxiliary fluid. No lubricants can get into the pumping chamber and the gas to be pumped is not contaminated. In design, the pumps is adopted to the intended application.

We Have Singe And Two Stage Type Dry Vacuum Pumps Widely Useful In Various Industries Like Paper Handling Plants, Liquid Transfer Plants, Food Processing Plants, Vacuum Forming, Sugar, Jaggery, Sugar Cube Manufacturing Plants, Chemicals Plants, Dyes And Intermediates Plants, Dental Hospitals, Laboratories, Milk Dairies Pharmaceuticals And Many More Other Applications.This Piston Type Vacuum Pump Achieve Vacuum Up To 29.0″ Hg For Single Stage And Up To 29.6″ Hg For Two Stage Construction.

We are an eminent Manufacturer and Exporter of Dual Vacuum Compressors. The Dual Vacuum Compressors offered by us are manufactured using quality-tested components and the latest technology in compliance with set industrial norms. Our Vacuum Compressors are used on the multi clamp binders in the book binding industry. Bulk orders of the Vacuum Compressors are processed by us as per the specific requirements of the buyers.   Features : Compact design Superior performance Robust construction   Applications : Offset Machines : Heidelberg, SORD Z, KORD, SORD, Speedmaster, Printmaster, MOV Roland : Parva, ULTRA, Rekord, HMT Neibolo   Other Information : Minimum Order Quantity : 5 Pieces Port of Dispatch : New Delhi and Navah Shevah Mumbai Production Capacity : 120 month as per order Delivery Time : With in 7- 40 days

Medical air compressors supply compressed air and vacuum to hospitals, operating theatres, dental surgeries, laboratories, manufacturing processes, etc. Pattons Medical sells medical scroll compressors, vacuum pumps, driers, and other medical gas equipment for the healthcare industry. For more information, please visit the website.

Vacuum compressor The machining department handles inside more than 90% of the production cycle through fully unsupervised machine tools. Space is important, and DVP uses automatic silo-style warehouses connected to the ERP system to manage stock-ins and stock-outs.The inspection department checks each product 100%.A check list, prepared by the Engineering Department for each model, indicates which check points and specifications must be recorded.

PFC Parts for Compressor is a global supplier of Single and Two Stage Dry Bare Vacuum Pump from India.These Dry Bare vacuum pumps are single acting , air cooled reciprocating units in single and two stage constructions These piston type vacuum pumps achieve vacuum up to 29.0”Hg (737 mm ) for single stage and up to 29.6”Hg (752mm) for two stage configuration These dry Type Vacuum Pump ideally designed for Printing, Plastics, Material Handling, Food Processing Packing, health care and many other Industries.

a vacuum pump converts the mechanical input energy of a rotating shaft into pneumatic energy by evacuating the air contained within a system. The internal pressure level thus becomes lower than that of the outside atmosphere. The amount of energy produced de- pends on the volume evacuated and the pressure difference produced. mechanical vacuum pumps use the same pumping mechanism as air compressors, except that the unit is installed so that air is drawn from a closed volume and exhausted to the atmosphere. A major difference between a vacuum pump and other types of pumps is that the pressure driving the air into the pump is below atmospheric and becomes vanish- ingly small at higher vacuum levels. Other differences between air compressors and vacuum pumps are: the maximum pressure difference produced by pump action can never be higher than 29.92 in. Hg (14.7 psi), since this represents a perfect vacuum. the mass of air drawn into the pump on each suction stroke, and hence the absolute pressure change, decreases as the vacuum level increases.   technical specification: available range 1.5hp to 15hp with air receiver and base mount model

The charam compressors and vacuum pumps are available in single and double stage which has a capacity from 10 to 200 tpd per compressor for dry chlorine gas application and also 100 to 2500 cu.mtrhr for other gases.

Vacuum pump is an universal design with the feature to convert it to a single stage compressor. Vacuum pump has a universal design with the feature to convert it to a single stage compressor. This feature is very useful for large tank leakage test under vacuum or under pressure.While using liquid tanks in chemical plants for vacuum, the provision of scrubber tank is available as an additional equipment to prevent the liquid from entering the pump.Simple design makes it easy for any mechanic to dismantle and assemble the pump without any mismatch of the parts.

• Motor HP: 1.5
• No. of Piston: 2

Vacuum compressor air cooled units in single and or two stage construction. It is positive displacement piston type pumps which achieve vacuum upto 29.0" Hg for single stage and up to 29.6" Hg for two stage construction, at sea level.
