vibrating fork level limit switch for food grains
Get Price Quote
Jaycee started in 2000 starting with manufacturing of vibrating tuning fork level switches for solid with various outputs suiting control requirements. also manufacturing vibrating fork/tuning fork level switches for liquid applications. In addition, the manufacturing range include vibrating rod level switches and capacitance level transmitter or switches, rf admittance level switches, near rf admttance level swiches, rotating paddle level switches, conductivity based level switches , capacitance level switches and capacitance rf level transmitters, fuel level sensors and transmitters. And in 2012 introduced electromagnetic flow meters. products designed and manufactured by Jaycee conform to various international quality standards.
Vibrating Fork Level Switch
1,000 - 90,000 Per Piece
10 Piece (MOQ)
vibrating point level switch for high, low or demand levels of dry bulk solids in bins, silos or hoppers. This compact switch can be top, side or angle mounted. The vibrating fork design ensures the tines are kept clean, and the unique fork and crystal assembly design eliminates false high level readings even if tines become damaged. Used for liquidsolid interface detects settled solids within liquids or solids in confined spaces like feed pipes. It is designed to ignore liquids in order to detect the interface between a solid and a liquid. This has an optional 4-20 mA output for monitoring buildup on the fork in sticky applications, to determine the need for preventative maintenance. Key Specifications High resistance to mechanical forces, and strong vibration resistance to high bulk material loads Suitable for low density material: standard version, liquidsolid interface version, and low density option Low frequency, low energy operation High or low level alarm in solids with simple failsafe highlow selection
Best Deals from Vibrating Fork Level Switch
Vibrating Fork Level Switch
15,000 - 45,000 Per Piece
1 Piece(s) (MOQ)
Trumen Vibrating Fork Liquid Level Switch
Get Price Quote
1 Piece (MOQ)
Trumen LFV Vibrating Fork Level liquid level switch used in all liquids, It detects the point level switching measurements reliably. for all liquids, independent level switch and it detects. LFV level switch is used as protection device of Hi and Low level switching in liquid applications. This level switch can be used as empty or full detection, dry run and pump protection in tanks and pipelines. This device can also be used in hazardous areas, chemical and food industry.
Vibrating Fork Level Switch
55,000 Per Piece
Specification Compact and Mini type Rod Extension up to 3 meters Hygienic versions with various process connections and 0.5 micron fine polishing Plastic or aluminum housing Adjustable sensitivity Supply voltage: 20…255 V AC, 20…60 V DC Process pressure : up to 40 bar Relay or electronic output Switching performance does not depend on the change of liquid conductivity, dielectric constant, pressure and temperature Medium temperature max. +130 °C (266 °F) Output test with optional test magnet IP67, IP65/IP68 protection
Vibrating Fork Type Level Switch
Get Price Quote
The vibratory level sensor provides reliable point level detection in a wide variety of process control applications in bins, silos and hoppers, filled with grained or powdered materials or for liquids in a tank. The vibrating probe principle eliminates problems associated with temperature, humidity and material changes, while providing state-of-the-art electronic reliability and accuracy that requires no calibration.
Vibrating Fork Level Switch
Get Price Quote
We offer Vibrating Fork Level Switch The vibrating fork level switch is specifically suited for sensing the presence of low-density dry powders or fine granular solids in bunkers and silos. It's stainless steel symmetrical fork offers reliable operation with even very low-density materials. The operation of vibrating fork level switch is unaffected by parameters such as changing material composition, changing moisture content and low specific gravity. Vibrating Fork Level Switch - APPLICATION EXAMPLES Dry Powders – Cement, Pulverized coal, Coffee Powder, Milk Powder, Chemical Powder Fine Grained Solids – Food Grains, Plastic Pellets, Wood Vibrating Fork Level Switch - FEATURES Calibration free and easy installation. Insensitive to material build-up. Field selectable fail safe mode. Adjustable time delay. Meets International Standards Built-in Diagnostics Customer specified insertion lengths up to 6m with cable or pipe extensions. Compact as well as remote mounted versions available
Vibrating Fork Level Switch
Get Price Quote
The vibrating fork level switches are specifically designed for sensing the presence of low-density dry powders or fine granular solids in bunkers and silos. It’s stainless steel symmetrical fork offers reliable operation with even very low-density materials. The operation of the instruments is unaffected by parameters such as changing material composition, changing moisture content and low specific gravity. application examples dry powders – cement, pulverized coal, coffee powder, milk powder, chemical powder fine grained solids – food grains, plastic pellets, wood.
vibrating fork level switches
Get Price Quote
Thorough metal construction, sturdy and durable No calibration necessary, user friendly Large vibrating range and the amplitude up to 8mm for the weak sticky materials hanging on the fork. Adjustable amplitude for distinguishing from the density of different substances. Ultra red LED offers a immediate warming for the operator to control the measurement. Flexible AC, DC power input makes not only less inventory but broad application. Various output modes, flexible use. Suitable for measurement of level of liquid, particulate and dense materials. Available to detect solid substances in liquid. Protection classification: IP67. Certification: CE, RoHS
Vibrating Fork Level Switch
2,500 - 3,500 Per piece
Vibrating Fork Level Switch
Get Price Quote
Features Compact size. Universal industrial power supply. 12 to 80 VDC & 12 to 265 VAC). Low power consumption. No calibration required. Various customized process connections. Starting from 1" threaded size. Settable switching delay as a standard feature. Applications Free flowing powders and granules (size max. 10mm). Suitable for side as well as top mounting. Minimum and maximum fail safe field selectable. Process temperature max 250 ºC. Process pressure max. 15 bar.
Compact Vibrating Fork Point Level Switch for Liquids
Get Price Quote
Applications • All liquids from free-flowing to viscosity up-to 10,000cP.• Suitable for side as well as top mounting.• Minimum and maximum fail safe field selectable.• Flow/No-Flow detection in pipe-lines.• Process temperature max 150 ºC.• Process pressure max. 15 bar. Features • Compact size and wide range.• 12 to 80 VDC for PNP/NPN o/p.• Low power consumption.• No calibration required.• Various customized process connections. like Threaded/Flanged/TC etc starting form 1/2".• Various o/p available like DC ANP/NPN/ Two wire DC 8/16, Two wire AC and NAMUR.
vibrating fork level switches
Get Price Quote
We are one of the preeminent Suppliers of Vibrating Fork Level Switches in Madhya Pradesh. The design of the Switches conforms to all the applicable standards. And their efficiency is ascertained to be high. To avail them in customized specifications, contact us!About Vibrating Fork Level Switches :Elixir liquid level switch has no moving parts and is not affected by the turbulence in the tank, floating particles, suspensions or gas bubbles. This makes it a superior choice over the traditional float switches. If the liquid/slurry service material is very viscous, Elixir is the instrument of choice. The instrument neither requires adjustments nor is dependent on the position, thus making it the best option for liquid level switching in small tanks, pipes and mixing tanks.Applications :You can use Elixir for level detection of all types of liquids in storage tanks, mixing tanks and pipe lines having temperature up to 200°C and viscosity up to 10,000 cP and density greater than 0.7 gm/cc. Elixir is suitable for most of the applications, where traditional float switches were previously used and for liquids, which are sticky, corrosive, agitated, splashing and foaming.Where is it used :Elixir has well used in the edible oil, food, pesticides, power, pharmaceutical, chemicals, dairy, distilleries, sugar, detergent, minerals, textile, water and many other industries and their utilities. Anywhere you use a float operated switch for liquid level indication, Elixir level switch comes as a better solution.
Vibrating Fork Point Level Liquid Switch
Get Price Quote
We are reckoned as the leading manufacturer, exporter and suppliers of Vibrating Fork Point Level Liquid Switch in Maharashtra, India. These switches are cost-effective and easy to install. It’s based on piezo driven vibrating fork technology and is used in chemical, pharmaceutical, process, food & beverage and hydraulic & lubrication systems. They are manufactured using quality approved raw materials in accordance with industry standards. Details : Cost-effective and easy to install switches based on piezo driven vibrating fork technology Insertion L - 125 to 2500mm Bulk Density - ≥0.5Kg/m3 Wtd Parts - SS304/316 Max Temp - 150oC Max Pressure - 10Kg/cm2 O/P - 5A, 250VAC x DPDT Enclosure - Cast Al x IP66, Ex-P IIB Options - Integral, Two part Applications : Chemical, Pharmaceutical, Process, Food & Beverage and Hydraulic & Lubrication Systems.
Vibrating Fork
Get Price Quote
Vibrating Fork Type Level Switch
9,000 - 13,000 Per Piece
Vibrating Fork type Level Switches are single point level switches. Vibrating Fork type Level Switches are also known as Tuning Fork Level Switches. The electronics control unit is integral with the sensing probe. Fail safe logic is field selectable. There ate two type of Vibraing Fork Level Switches
Sapcon Vibrating Fork Level Switch
10,000 Per
Vibrating Fork Level Limit Switch
Get Price Quote
In point level measurement with vibrating level switches, a rod or a fork is set vibrating. When the vibrating probe comes into contact with the medium, the vibration changes and the device outputs a switching command. Vibrating level switches are used in liquids as well as in granular and powdery bulk solids.
Level Switch - VIbrating Fork for Solids ( PNP )
Get Price Quote
Vibrating fork type level switches are single point level switches. Vibrating fork type level switches are also known as tuning fork level switches. The electronics control unit is integral with the sensing probe. Fail safe logic is field selectable.
Vibrating Fork Level Switch
Get Price Quote
Pipe Fork is a compact level switch suitable for all kinds of fluids and is used in tanks, containers and pipelines. Pipe fork is used in all types of fluids having viscosity up to 10,000 cP & densities greater than or equal to 0.7 gm. cc.
Compact Vibrating Fork Level Switch (LFV11)
Get Price Quote
Vibrating Fork Level Switch
Get Price Quote
Vibrating Fork Level Switch
8,500 Per Piece
Vibrating Fork Level Limit Switch
Get Price Quote
Electronics of LSV excites the piezo-electric-crystals inside tuning fork, which makes the fork tines vibrate.LSV electronics simply invoke the peizo-electric crystals which are present inside of the turning fork and which enable fork tines to vibrate at their precise resonance frequency while in the free air.
Vibrating Fork Level Switch
Get Price Quote
VIBRATING FORK LEVEL SWITCHE work on vibration damping principal and are used for material with low densities where rotary paddle switches can not be used. The vibrations also provide self cleaning action, so these level switches can easily be used for materials that stick to probe and tank wall. The electronically stimulated fork vibrates at it’s mechanically resonance frequency of 125 Hz when the fork is free of the service material. The resonance is caused by the piezoelectric crystals. One of the Piezo crystals produces a small voltage which is transmitted to the switching amplifier. If the fork is covered by the bulk material, a damping effect is produced and the Piezo crystal does not produce the voltage and the amplifier will be switched on and a corresponding signal output is actuated. Small depositions on the container wall do not affect the operation of our switch. The switches are supplied with integral electronics and are available in lengths from 250 to 3000 mm. The Vibrating Fork Level Switches are extensively used in building, cement, food dairy, plastic, timber, chemical and mining industries. The operating temperature for standard model is 150 Deg C and can be custom made to suit temperature up to 200 DegC. These switches are supplied with heavy duty SS316 forks and can be successfully used for most applications like - bins and hoppers requiring minimum and maximum level detection of solids, powders, granules, pellets, flakes, etc. These are not affected by incoming material. They are highly sensitive, reliable, easy to install, require no calibration, economical and suitable for highly dusty environment. The vibrating fork level switches are extensively used in building, cement, food, dairy, plastic, timber, chemical and mining industries. Vibrating Fork Level Switch Manufacturer, Exporter and Supplier Vibrating Fork Level Switch is the Main Product of VEKSLER INSTRUMENTS. VEKSLER INSTRUMENTS is pleased to introduce themselves as the most Preferred Manufacturer and Supplier of Vibrating Fork Level Switch in India. We are also a one of the leading exporters of Vibrating Fork Level Switch from India. Our Vibrating Fork Level Switch is easy to use and cost effective. Our product range is Vibrating Fork Level Switch and Vibrating Fork Liquid Level Switch. Back to Top
Vibrating Fork Level Switch
Get Price Quote
The vibrating fork level switch is specifically suited for sensing the presence of low-density dry powders or fine granular solids in bunkers and silos. It’s stainless steel symmetrical fork offers reliable operation with even very low-density materials.
Vibrating Fork Level Switches for Liquids and Solids
Get Price Quote
Vibrating fork level switch consists of two forks or two arms which vibrate continuously because of their contact with piezo electric crystals. Hence the name vibrating fork. The tuning fork vibrates at its mechanical resonance frequency of about 1000 Hz. The frequency changes when the fork is covered by the medium. This change is detected by the integrated oscillator and converted into an output – Relay, PNP or analog. The material could be a viscous liquid, slurry or even free flowing powders. (Contact our technical team to help you decide the type of fork to be used.) Features : Compact size, rugged design Proven Technology No Calibration required Universal power supply 230VAC & 11-55VDC on our selected models. Suitable for all types of solids, powders, liquids and viscosity upto 10,000cp Can offer for high temperature and high pressure applications (on request) Suitable for hazardous area Unaffected by flow, bubbles, turbulence, foam, solid contents etc. No moving parts, maintenance free. Custom length available. Application : Pharmaceuticals Pulp & Paper Processing Food & Beverages. Rocks, Sand & Gravels. Dairy Mining Plastics
Vibrating Fork Level Switch
9,000 Per Piece
vibrating fork level switches
Get Price Quote
Vibrating Fork type Level Switches are single point level switches. Vibrating Fork type Level Switches are also known as Tuning Fork Level Switches. The electronics control unit is integral with the sensing probe. Fail safe logic is field selectable.
Trumen Vibrating Fork Point Level Switch
10,500 Per Piece
1 Piece (MOQ)
