Water Well Drilling Rigs Dealers

• Drilling depth: 300Meters
• Type: Skid mounted drilling rig
• Application: water well
• Engine: Diesel Engine Power
• Air compressor capacity: 1100cfm/ 300psi
• mud pump: 6 X 6
• Rod Handling: 4.5 inch(15Feet)
• RotaryDrilling diameter: 152 350mm(6
• Engine Rating: 180hp @ 2200Rpm
• Air compressor: ELGI

• Type: Water Well Drilling Rigs
• Application: WATER WELL
• Certification: ISO 9001:2008
• Weight: 23000KG
• Color: Blue
• Condition: Used
• Automatic Grade: Semi Automatic
• Driven Type: Hydraulic
• Feature: Easy To Operate, High Performance
• Drilling depth: 300-400feet
• Hole Diameter: 200-300mm
• Brand Name: PRL
• Application: WATER WELL
• Power Type: HYDRAULIC
• Warranty: 1 YEAR
• After-Sales Service Provided: YES
• Color: blue
• Maximum Depth: 300Meters(1000Feet)
• Rod Handling: 4.5 inch(15Feet)
• DTH diameter: 152 254mm(6

• Brand Name: Uthara
• Application: Water Well
• Model: UTHARA DTHR-300
• Capacity Dia: 6 1/2
• Depth: 300 Meters
• Pull Up Load: 12000 Kgf
• Pull Down: 5800 Kgf
• Torque: 3800 Nm @ 100rpm
• Mounting of Rig: 6x4 Truck (Optional: 2 Truck vnrsinn)
• Injection Pump: 56 Ipm @ 30 Bar
• Power: Same Truck Engine
• Compressor: 1100 cfm @ 330psi
• Mud Pump: 1035 Ipm @ 15 Bar

• Brand Name: Sardar ji Pukhrayan
• Country of Origin: Made in India
• Usage/Application: Borewell
• Drilling Rig Type: Land Based Drilling Rigs
• Power Source: Hydraulic
• Automation Grade: Semi Automatic
• Material Grade: Mild Steel

• Usage/Application: Water well
• Brand: PRD
• Model Name/Number: PRD Speed Star
• Drilling Rig Type: Land Based Drilling Rigs
• Capacity: 363 m

Outfitted with an advanced technology and state of the art infrastructure, we are one of the eminent Manufacturers, Exporters, and Suppliers of a huge variety of Water Well Drilling Rigs. They are fabricated using high-quality raw material and modern machinery by our team of experts. In harmony with the demands of patrons, we offer Water Well Drilling Rigs in various specifications and configurations. Furthermore, they are provided with optional skid mounting. Our Water Well Drilling Rigs are built strongly to give optimum performance.   Key Specification : Drill rod handling 15feet (4.5meter)-20 feet (6.0 meter) Drilling depth up to 1500feet (450meters) Drilling diameter 6inch (152mm)-8inch (203mm) Pull up force 14000kgf Drill head torque360 kg.m (optional: 450 kg.m) Air compressor 1100 cfm300psi (optional - 1100 cfm 350 psi)

• Usage/Application: Water Well
• Drilling Rig Type: Land Based Drilling Rigs
• Drilling Depth: 200-300 meters
• Power Source: Hydraulic
• Hole Diameter: 100-200 mm
• Automation Grade: Semi Automatic

• Brand Name: GETECH
• Driven Type: Hydraulic
• Automatic Grade: Semi Automatic
• Application: Borewell
• Feature: High Strength
• Type: Water Well Drilling Rigs

Brief description: The DTH300 drill rig is ideal for water well drilling application in rock formation. Thanks to its simple and compact design, excellent performance, high accessibility and reliability at afford cost in its class. The DTH300 rig’s flexibility means it can be mounted on single truck version, two truck versions and on local truck matching the rig to the terrain it will be used. Optional: Skid mounting Key features: Proven technology ensures easy maintenance and more productive. The rig can be customize as per customer requirement All the actuators are operated by proportional control valves Key specification: Drill rod handling 15 feet (4.5 meter) - 20 feet (6.0 meter) Drilling depth up to 1,000 feet (300 meters) Drilling diameter 6 inch (152mm) - 8 inch (203mm) Pull up force 10,500 kgf Drill head torque 360 kg.m Air compressor 1,100 cfm/300 psi

• Usage/Application: Mining
• Brand: Getech
• Drilling Rig Type: Land Based Drilling Rigs
• Automation Grade: Semi Automatic
• Air Compressor: 1,100 cfm/300 psi
• Drill Head Torque: 360 kg.m

• Brand Name: KLR
• Driven Type: Hydraulic
• Condition: Nwe
• Application: Piling
• Certification: CE ISI
• Feature: High Strength, Easy To Operate
• Type: Water Well Drilling Rigs
• Warranty: 1 Year
• Country of Origin: India

KLR DTH 1500 is mounted on heavy duty 6x4 truck powered by suitable engine. This is suitable for hole dia 6.5” (continuous), 9”, 10” and 12”(over burden) up to a depth of 1500 feet. Rotary head produces max.speed of 170 rpm and max.torque 280 kg.m. Power for the Rig is taken from truck engine through transfer gear box. Mast, Rotary head, control panel, compressor, Hydraulic tank, welding machine, battery box are mounted on the same truck.

• Automatic Grade: Semi-Automatic
• Brand Name: Ashok Leyland
• Hole Diameter: 150-200 mm
• Capacity: 150-500 feet
• Model: EHD 600

• Type: Hydraulic
• Certification: ISI Certified
• Color: Yellow
• Automatic Grade: Semi Automatic
• Application: Water Well Drilling
• Warranty: 1 Year

• Brand Name: Satadhar welding works
• Power Source: Hydraulic
• Drilling Rig Type: Land Based Drilling Rigs
• Drilling Depth: 100-200 meters
• Hole Diameter: 100-200 mm
• Automation Grade: Manual
• Torque Capacity: 400ft

• Country of Origin: India
• Type: Well Drilling Machine
• Weight: 4000-6000kg
• Condition: New
• Automatic Grade: Fully Automatic
• Warrenty: 1 Year
• Brand Name: INGOZ
• Application: Water Well Drilling
• Warranty: 1 year
• After-Sales Service Provided: Engineers Available To Service Machinery Overseas
• Port: ANY INDIAN PORT
• Model Number: + 91 9313612524
• Supply Ability: 2 Unit/Units per Month
• CNC or Not: Normal
• Drilling Speed: 100 ft per hour
• Packaging Details: 40 FT FLAT RACK

• Country of Origin: Made in India
• Usage/Application: Borewell
