Window Patching Machine Dealers

• Model: EXCEL 10-REGULAR
• Blank Size: 20" x 24"
• Speed: Up to 150 blanks / minute (depends upon stock used)
• Paper Weight: 55 gsm to 200 gsm
• Window Size Max: 11” x 12” (280mm x 304mm)
• File Capacity: 9000 paper of 60 gsm
• Film: 15 to 125 micron (Polyester, BOPP or PVC
• Counter: Digital Preset Counter
• Machine Size: Height 56" Length 88" Width 44”
• Machine Weight: 800 kg approx
• Electrical: 2 HP AC Motor & AC Drive with thyristor control, A. C. Motor 2 h.p. with pump single phase & 3 Phase

• Weight: 2800kg
• Film Thickness: 0.03mm
• Power Of Pump: 1.5kW
• Paper Width: 120mm
• Paper Length: 140mm
• Main Power: 2.2kW
• Film Width: 30mm
• Dimensions: 5000x1550x1770mm
• Speed: 600pcs/h
• Film Length: 60mm
• Brand: Wenzhou
• Model Number: ZKT-750B

• Country of Origin: China
• Type: Window Patching Machine
• Weight: 3500kg
• Voltage: 380V
• Condition: New
• Automatic Grade: Automatic
• Power: 9-12kw
• Warrenty: 1 Year
• Warranty: 1 Year
• After-Sales Service Provided: On Line

• Automatic Grade: Automatic
• Power: 9-12kw
• Warrenty: 1 Year
• Country of Origin: India
• Film thickness: 20 microns
• Dimensions of the Machine: 1.2 mtr x 4.5 mtr ( w x l )

grafik machinery exchange india is a renowned exporter, manufacturer of window patching machine and liner carton machine. it is perfect for high volume production and has sturdy construction which ensures its dependable performance. we provide some special attachments with the machine like sub-systems for producing liner cartons, and punch cut for corner window pasting. we have flexible manufacturing ability which is helpful in ensuring highest efficiency of the machine. the modular concept is our designing base, which is helpful in ensuring longer and efficient working life of the machinery. once installed, the liner carton machine and window patching machine can be retrofitted without any difficulty; this is the key features of this product which allows its adaptation to new manufacturing conditions. we use the time-tested and latest techniques like extrusion, molding etc to fabricate the machine. the fishing and automation of this machine is done according to the industry standards.

0% Film Wastage. sturdy Design. quality Pasting. high Production. easy to Operate. new Technology. sizes Available: 20” X 24” & 16” X 20”.

• Frequency: 50-60 Hz
• Material: Mild Steel
• Voltage: 220-240V
• Film Thickness: 0.03
• Weight: 3300 kg
• Maximum Blank Size: 1000x710mm
• Minimum Window Size: 30x45mm
• Dimensions: 4225x1700x1500mm
• Main Motor Power: 3 kw

Automatic Window Patching Machine. USEFUL FOR WINDOW ENVELOPE & PACKAGING PRODUCTS. FEATURES. FOR PACKAGING PRODUCTS PNEUMATICALLY OPERATED ON LINE V CUTTING ATTACHMENT ON LINE CREASING ATTACHMENT 0% FILM WASTAGE STURDY DESIGN QUALITY PASTING HIGH PRODUCTION EASY TO OPERATE

Sheet feeding Section Intermitted belt conveying system using Servo motor and drive. Adjustment of blank size is done by computer HMI. The bottom friction feed belt works with start and stop motion with synchronize time with the machine chain conveying section. Multiple belts are equipped with gear and rack for easy movement and quick positioning. Fine control for feeder gate height adjustment.  Gluing section Single, high-hardened stainless steel tube roller for glue application. The glue roller can be adjusted for glue thickness with the help of sliding block. The stereo cylinder is hard chrome coated and with marking for easy fixing of stereo rubber. The stereo cylinder can be moved left or right, forward or backward to set the glue position accurately without stopping the machine. Glue roller can be pulled out for easy cleaning. Control System The machine works with PLC, HMI and servo control. All electronic components and detector are made from France, German, Taiwan, Japan etc,.  Delivery section Soft belt conveying can prevent product damage, Motorised belt conveyor for even overlapping ensuring perfect quality.

• Blank Size: 14"X19"(350 X 500 MM)
• Speed Max: UPTO 120 BLANK/MINUTE

Electrical : 1 HP THRUSTER CONTROL A.C. MOTOR, Window Size Max: 6"X 8(150X200MM), Pile Capacity:6000 PAPER TO 70 GSM, Counter:DIGITAL PRESET COUNTER

• Voltage: 380V
• Frequency: 50-60 Hz
• Material: MS
• Power Source: Electric
• Phase: 3 Phase
• Film Thickness: 0.03 - 0.2mm
• Max sheet size: (W) 400 x (L) 300 mm (Double up)
• Min sheet size: (W) 100 x (L) 150 mm

Manufacturer & Exporter of a wide range of products which include Window Patching Machine such as Automatic Carton Window Patching Machine, Liner Carton Machines and Bag In Box Machine.   We are providing Automatic Carton Window Patching Machine. Window patching and lining machine with disc feeder 680×680 mm, with adjustable conveyor-chain station, with continuous running single cylinder top-gluing unit, which can be withdraw from the machine for cleaning with stereo cylinder and glue-impression roller with windowing and lining material station. Cut off length can be changed by means of change gears with delivery station with variable speed shunt wound 3-phase AC motor incl. brake device for the main drive as well as complete electrical equipment for 380v, 50 cycles AC, with electrical push-button controls, with pressure and vacuum pump incl. motor, with tachometer with all necessary safety devices against incorrect operations. Station consisting of: 1 adjustable feeding table, 2 feed wheels Gluing Station, 1 single cylinder top-gluing unit incl. motor, 1 doctor blade, 1 stereo cylinder, 1 glue impression roller Windowing and Lining Material Station, 1 unwind unit, 3 draw-in rollers, 1 rotary cross cutter with stationary counter knife, air-controlled suction cylinder for windowing and lining material, heating station with sync encoders, 1 pressure roller, Complete set of change gears. Delivery Station, 1 belt transport device, 1 delivery table with transport belt, 1 set of machine tools. The machine speed indicated in our technical specifications has to be understood as a maximum quantity. The output depends on shape, weight and quality of the material which has to be worked up. Under good working conditions it may be possible to run even lighter.

Fully automatic machine suitable for high volume production. Equipped with advanced features - touch screen control and memory function for time-saving operation. Computer-driven production control system with automatic adjustment and operator friendly.
