Wire Saw Machine Dealers

Wire saw machines 20Hp, 40Hp & 60Hp available with High quality materials and Heavy body with 8mm & 10mm sheet. Heavy duty Copper Cables also available "10mm 3.5core", "16mm 3.5core", "25mm 3.5core", "35mm 3.5core", "50mm 3.5core", "70mm 3.5core", "90mm 3.5core" excellent quality and at cheapest price in India. Heavy duty alluminium cables also available Service and Quality assured from our side. Thank You for contacting us.

• Country of Origin: India
• Type machine: Direct drive
• Number of RMP: 630 m/min
• Water flow requirement: 10 litres. / min
• Power supply: 415 volts AC/3 phase/50HZ
• Installed power required: Total 21 HP
• Main motor power: 20HP 960 RPM motor
• Feed motor power: 1 HP D.C. 15000 RPM
• Sile of railing: 13 feet
• Cable main motor: 10 mtr. 1.5 sq mm Three Core (Set)
• Cable D.C. motor: 10 mtr 1.5 sq mm Four Core

In order to suit varied requirements of the clients, we have developed a secure payment procedure that have assorted offline and online options. Hi-tech machines and assistance of our packaging experts help us in meeting the standard as well as customized packing needs of the customers. Moreover, we check the entire lot before making the final dispatch.   Technical specification : Type of Machine - Gearbox Type Motor Power - 40 Hp 1440 RPM Motor/ABB/Siemens Feed Motor - 1 HP DC Motor with double reduction gearbox type Pully Dia - 800 MM Dia. Main Pully RPM - 650- RPM Appx. Rail Track - Total railing with machine 6000 mm length Control panel - All control of machine from control panel fitted with machine by means of plug & socket system Power supply - 415 Volts, AC/3 Phase, 50Hz Cable - 10 Meters Features : High performance Long service life Rust resistant body Other Details : Item Code - 8426151 Minimum Order Quantity - 11pic

Heavy & Robust Design State of the art control panel which increases the wire saw efficiency Water pump controlled from the panel The design of power and machine systems, specially suits to various working conditions of Quarry Extra safety features Specifications 60 HP Siemens Motor 1 HP DC Motor coupled with gear box for travelling movement Electric control panel with 10 meters’ control cable 110 amps BCH contractors Travelling track – Total 6mtrs 800mm main pulley giving wire speed of 24m/sec Guide pulley 2 nos

The standard DWS Diamond Wire Saw series is designed for shallow water operation, with options for diver control or topside remote control. They’re the only machines of their type with a self-adjusting , auto feed system that controls wire bend, automatically matching the feed rate to the cutting rate. Their unique hydrodynamic design requires less power due to the dramatically reduced centrifugal forces during operation.

• Usage/Application: Cutting Use
• Weight: 1000-2000kg
• Voltage: 380V, 440V
• Automatic Grade: Automatic
• Power: 9-12kw
• Driven Type: Electric
• Country of Origin: India
• Type: Diamond Cutting Machines
• Certification: CE Certified
• Color: Brown, Yellow
• Condition: New
• Warrenty: 1Yr
• diamond wiresaw machine: 60-40-20-75 HP

• Type: Automatic
• Certification: CE Certified
• Application: Industrial
• Voltage: 380V
• Power: 3-6kw
• Warranty: 1 Year
• Total Cutting length of Slab: 3000 MM
• Width of table: 900 MM.
• Width of Machine: 1300 MM.

To cater to the various cutting requirements of the Mining industry, we are engaged in offering precision-made Wire Saw Machines. These Wire Saw Machines are used in Marble & Granite mines quarries for slicing of blocks as per the specifications also. This Wire Saw Machine is robust, efficient, easy to operate and cost effective, having low maintenance cost. Due to high productivity with cost economy these Wire Saw Machines are widely in demand. Technical Details : Type of Machine 20HPMachine Gear Box TypeNumber of RMP 630 M/MINWater Flow Required 10 LTS/MINWater Flow Required Variable (Depends upon Hardness of Stone to be Cut)Power Supply 415 Volts AC/3 PHASE/50HZInstalled Power Required Total 21 HPMain Motor Power 20 HP1440 RPM MOTORFeed Motor Power 1 HP D.C. 15000 RPMSize of Railing 5700 MMCable Main Motor 10 Meter 1.5 SQ MM Thre Core (SET)Cable D.C. Motor 10 Meter 1.5 SQ MM Four CoreAluminium Pulley 600/625 MM Diameter

Welding Process: - The Saw Blades or Wire Ends to be joined should be cut straight, exactly at right angles and free from burrs on special shearing attachment (optional equipment) - Welding Current, Upsetting Pressure and Upsetting Way are set according to the blade width - The blade ends are rigidly clamped in special quick acting clamps provided on the machine - By depressing the welding lever, the welding process begins - The two ends are heated to forging temperatures in a few seconds and are then automatically forged (upset). The welding current switches off automatically - The job is de-clamped and the weld completed Process for Annealing: The upsetting way switch lever is now turned to annealing and the job is clamped again with the extended jaw distance which comes in automatically on flipping the lever to annealing position. - By pressing the annealing switch on which two heat positions are provided, the job is annealed in order to normalize the brittleness of the welded area. - Depending on the type of material, the annealing process should be repeated several times if need be. Shearing Attachment (optional): Special shears with arrangement for mounting on the front of the machine are available Grinding Attachment (optional): Grinding attachment mounted on top of the machine is necessary for removing the welding flash

Our investment in the well-structured warehouse has paid off well. We have successfully installed up-to-the-minute warehouse management software to keep the entire lot in a safe and organized manner. Strong industrial base along with a wide area network, we deliver the range in the stipulated time span.

• Size: 0.42
• Application: For stone cutting
• No of wire: One or two
• Function: Cutting slab and profilling
• Wire Stock: 6.5m
• Power: 20/25kw
• Power Supply: 380V/50Hz

20hp dc dressingachine with Crompton motor

Prominent amidst the leading Supplier; count on us to avail the finest Wire Saw Machine. We have streamlined inventory system and spacious warehouse that assist us in meeting the voluminous requirements of the clients and that too in the stipulated time span. With the latest facilities, we efficiently ensure year round availability of the products.

Offering quality with performance, we provide hot saw machines which are highly efficient. Our products are in conformance with international quality & safety standards. These hot saw machines ensure trouble free and smooth running. Moreover, these are offered at industry leading rates and are delivered timely. Description The circular sawing machines are designed and made to Cut Heavy Steel section up to 600 mm beam, 200 MM Round Etc industrial sawing machine is highly efficient and can be operated continuously

• Height q: 1100mm
• Length: 1100m
• Width: 750mm
• Total Weight: 1100 Kg. Approx.

JB have developed 20 HP Wire Saw Machine is made to work on smaller cuts upto 25 Sq.m., such as in block dressing of stones. It is also complements 60 HP Wire Saw machine and has a similar installation and service package. Machine is equipped with 1 HP.DC motor with variable speed. Independent Control Panel 600 mm main pullery coupled directly on motor.
