RF Connectors Dealers in Faridabad

• Country of Origin: Made in India
• Brand Name: jayaraj
• Material: Brass
• Mounting Type: PCB Mount
• Maximum Frequency: 18ghz

• Insulation Resistance: 35 milliohms or less
• Rated voltage: 250v Ac
• Contact: Copper alloy, Gold(contact area) over nickel plating
• Hex nut: Steel, Nickel plating

• Features: Impeccable finish, Easy to connect , Elevated durability

• Material: Plastic
• Contact Material: Zinc Alloy
• Pin Type: Screw
• Voltage: 36 V DC
• Rated Current: 6 A
• Size: 5.5 x 2.1 mm

• Operating Frequency Band : DC to 3 GHz
• Connector Impedance : 50 ohm + 1 ohm
• VSWR: < 1.10
• 3rd Order IMD: -116 dBm (-159 dBc) @ 1800 MHz
• 3rd Order IMD Test Method : Two +43 dBm Carriers
• Outer Contact Resistance, Maximum: 0.2 mOhm
• Inner Contact Resistance, Maximum: 1.0 mOHm Max
• Insulation Resistance, Maximum: 5000 MOhm
• Insertion Loss, typical: 0.05 dB √ (Freq in GHz)

The company is chiefly engaged in manufacturing, exporting, and supplying of Copper Inline Connector all over India and abroad. The Copper Inline Connector, which we offer, is high in performance. Longer working life and excellent quality are amongst the attributes of our Copper Inline Connector. Known For : Rugged constructionDurabilityOptimum performanceGood quality Technical Specifications Cat. No Area mm2 Dimentions (mm2) A C J ZCC-450 1.5 1.6 3.2 7 ZCC-453 1.5 1.6 3.2 15 ZCC-451 2.5 2.4 4 7 ZCC-454 2.5 2.4 4 15 ZCC-452 4.6 3.5 5.5 7 ZCC-455 4.6 3.5 5.5 15 ZCC-456 10 4.4 6.2 9 ZCC-460 10 4.4 6.2 20 ZCC-461 16 5.6 8 23 ZCC-484 25 7.5 11.1 11 ZCC-486 25 7.5 11.1 25 ZCC-485 35 9 12.6 12 ZCC-487 35 9 12.6 27 ZCC-480 50 10.5 14.1 38 ZCC-478 70 12 16 18 ZCC-481 70 12 16 42 ZCC-482 95 13.5 18.1 48
