Vertical Packaging Machine Dealers in Faridabad

• Type: SPM-4230 Packing Machine
• Power: 2.2KW
• Bag length: 80-300mm (L)
• Bag width: 50-200mm (W)
• Max width of roll film: 420mm
• Packing speed: 5-60bags/min
• Measuring range: 150-1200mL
• Air consumption: 0.65mpa
• Gas consumption: 0.3m³/min
• Power voltage: 220V
• Dimension: (L)1320 mm x (W)950 mm x (H)1360mm
• Deadweight of machine: 540Kg

• Brand Name: CHIRAG

We are offering automatic vertical pouch packaging machine for powders. the chirag electronics series ch-100 is ideal bagger with servo operated auger filler to pack various products at high speed. It is suitable to pack instant coffee powder, spices, milk powder, glucose powder, protein powder etc. filling range: 500gm to 2000gm/ 2000gm to 5000gm. features: controlled by plc with color touch screen. ac servo drive in auger filling/ac inverter drive for pulling paper. self diagnostic features. easy loading of film roll. no product no fill to ensure no wastage of bags. safety doors interlocked. password protection. fault history. technical specification: bag width: 60 to 225mm out put: 25 t0 30 bags/min. max. Roll dia: 480mm bag type : center seal supply voltage: 415v, 3phase, 50 hz power requirement: 5.5kw air requirement: 6kg/cm2 machine weight: 1500kg. machine dimension: 7' * 4' * 9'.

Mechanical model of Vertical Form Fill & Seal Machine fitted with Hopper type Liquid Suction pump to pack thick viscose liquids / paste in pouches. Filling range : upto 200ml Products : Sauce, paste, grease, liquid chocolate etc.

• Filling Range: 10gm to 200gm / Power / Grains etc
•  : Filling System
• Cup filler:
• Sealing Type: Centre Seal Pillow pouch / 3 sides seal / 4 sides seal
•  : Film Size
• 50 -180mm(W) X 40 – 120mm (L) Laminated:
• Speed: 10 to 80 pouch/min
•  : Power
• 220VT 50Hz / 2.5KW / Single Phase:
• Max Film Size: 320mm
•  : Dimension
• 1200L X 700W X 1520(H) mm:
• Machine Weight: 300KG
•  : Optional
• Batch Coding, Batch Cutting, Date Printer:

vertical ffs pouch packing machines, single track ffs machines
