Internal Grinders Dealers in Ghaziabad

• Max./Min. Grinding Diameter: 50/5 mm
• Max. Grinding Length: 70 mm

This is a compact machine for high precision internal bore & face grinding of components in medium to High Production volumes. Suitable for small components like connecting rods, bushes, fuel injection parts etc. The machine is capable for grinding with CBN or conventional abrasives, tooled up with Belt driven or High Frequency Spindles (option) for optimum productivity.

• MAJOR SPECIFICATIONS: Swing Diameter
• 300: 415
• work Head Spindle Taper: A2-6
• A2-8: Max chuck size
• 250: 350
• Ex. Grinding Wheel dia.: 75

Machine is with Internal Grinding spindle suitable for Bore & Face grinding application. Stiff Linear Roller guide-ways for maximum rigidity. Most efficient & cost effective lubrication system with CNC interlocking. Convenient approach to diamond touch. Efficient & compact coolant filtration system with lowest running cost. Twin spindles  are also available for counter bore grinding application. High static and dynamic stable machine structure using Damping Concrete Polymer Composite Machine base, Highly effective for vibration sensitive application and critical roughness values. Carriage are driven by precision stretched ball screw to achieve better accuracy. Rigid hollow work spindle. Swivel work head available as optional. Lifetime protection of spindle and slides against coolant and fumes with non-wear parts. Machine also offered with TWIN Spindle / Hard Turning station as optional. User friendly interface. Lowest running cost. Production monitoring. Eco friendliness. Machine suitable for Parts: Gears, Bushes, Rings, Drive shafts. etc

We are offering cnc production internal grinder. Over the years of experience in the industry, we have been able to provide the customers with a commendable range of ig-50 cnc cnc production internal grinder

Internal Grinder, CNC Machines, Spline Milling Machine
