Slitting Line Dealers in Ghaziabad

We are among the trusted names, involved in offering world-class lot of Slitting Line Machine in the national market. We are highly concerned towards providing the top-notch array of products to the buyers and thus, check the lot at different levels for quality assurance. The offered Slitting Line is available in various stainless steel coil thicknesses ranging from .4mm to 4mm.

Our company is highly esteemed in offering Slitting Line to the clients. Slitting Line is made as per the set industry norms and guidelines, utilizing the finest raw material and modern machines. Offered range is widely demanded for low maintenance. This product is stringently tested by quality analyzers on various parameters to make sure flawlessness and defect free delivery. Features : High tensile strength Dimensional accuracy Corrosion resistance

UTech Rolls Equipments Pvt. Ltd.manufactured a quality equipment with a rare combination of strength and accuracy. This highly efficient machine enables slitting of CR/HR coils in loop control/speed assisted/pull through mode as per requirement. Complete line is PLC controlled, thus all hydraulic operations can be performed from the desk most conveniently. Electrical drives consist of DC motors that enable smooth operation in all three modes. The use of eccentric adjustment mechanism employed on slitter housing (in place of the worm screw type) ensures a high level of slitting accuracy. All wear parts, Sourced from international suppliers with best technology and repute are self-lubricated types and provide longer life and maintenance free operation. The uncoiler can accommodate all types of standard coil bores on expandable opposed drums for heavy load and damage free operation. Coil cars are provided on both sides for trouble free remote handling of input and outputs coils. Scrap winders are driven by hydraulic motors for automatic speed and load control operation. Features   300 mm to 2000 mm width 0.2 mm to 10.0 mm thickness 5 MT to 40 MT coil wt. 508, 610, 760, 850 mm input coil bore 508/610 mm output coil bore 1200 mm to 2000 mm coil OD 0.05 mm slitter width accuracy Eccentric type slitter Cassette type slitter for faster tool change Outboard support for recoiler Triple bellow type drag tensioner

• Width (mm): 1250
• Thinckness (mm): 0.5-2.0

Slitter takes the strip further but now in slitted condition. All the slits are taken forward over the roller table & loop table, through line separator, pressure pad & deflector roll in to the Recoiler drum where the ends are inserted in the gripping slot. The ends are properly positioned in the slot as per the setting of Over Arm Separator and the drum is expanded.

The machine is specially design to slit the required width of steel strip. We supply the Slitting Line of capacity ranging from 5 MT to 30MT. Its main purpose is to increase the output speed, upgrade the quality with easy operation, labor saving, high safety to reach the demand for high-performance.

Our company is professional in providing Slitting Lines to customers. These Slitting Lines are available in different sizes and models as per the demands and specifications laid by the clients. Our product range is specially designed to slit all types of gauge strips to extreme close tolerances whether these are thick or thin. Our product range comprises of scrap management, coil handling and strip processing equipment. It is available in different capacities and standards according to the demand of the clients. Our product maintains constant parallel distance between the last deflector roll and re-coiler drum. Furthermore, these Slitting Lines are widely appreciated amongst our clients for their user friendly designs and high resistance to temperature variations. CharacteristicsAutomatic Strip Threading.Minimum Burr on strip.High running accuracy of knife at arbours.Constant parallel distance between the lastDeflector roll and re-coiler drum.Straight edged recoiling.Capacity to run upto 120 mts/min.Economic efficency due to high automation level.On site Installation. FeatureTypes - Singe loop and double loop/ with out loop.Thickness of 0.1mm to 10 mm.Strip widths - 300mm to 2000mm.Coil weight - 2 MT to 35 MT.

We manufacture and export slitting lines that are designed to slit all types of thin gauge strips to extremely close tolerances. These lines basically consist of coil handling, strip processing and scrap management equipment.   Features   Types - Singe loop and double loop Thickness of 0.1mm to 6 mm Strip widths - 200mm to 2000mm Coil weight - 1 tonne to 30 tonnes Characteristics of Our Slitting Lines Automatic Strip Threading Minimum Burr on strip High running accuracy of knife at arbours Constant parallel distance between the last Deflector roll and recoiler drum Straight edged recoiling Capacity to run upto 100mts/min Economic efficency due to high automation level

slitting lines, cold roll forming lines, roofing sheet forming machine

HR / CR Slitting Lines, Tube / Pipe End Facing Machines, ERW Tube Mills

Tube Mill, hydro tester, Bend Test Machine
