Solar Modules Dealers in Ghaziabad

• Tc of Open Circuit Voltage (ß): -0.35 ±0.01 % /°c
• Tc of Short Circuit Current(a): 0.05 ± 0.02% /°c
• Tc of Power: -0.44 ± 0.02% /°c
• Maximum System Voltage: 1000 V(tuv),600v(ul)
• NOCT: 45° C ± 2° C
• Temperature Range: - 40° C to + 85° C
• Efficiency Reduction At 200w/m²,25°c: < 5%
• Length: 1961 ± 1.5mm
• Width: 982 ± 1.5mm
• Height: 36 mm
• Weight: 20.60 kg
• Junction Box: IP65, 4 terminal Insertaion type with 3 bypass diodes(15A)
• Cable & Connectors: 4mm², TUV & UL Certified, 1000 mm
• Application class: CLASS A (Safety classII)
• cover: High Transmission, Low Iron,3.2/4 mm Tempered ARC Glass
• Cells: 3BB,156x156mm,72 no's pcs Poly -crystalline solar cells
• Cell Encapsulation: Eva (ethylene Vinyl Acetate)
• Back cover: Composite film
• Frame: =17µ Anodize thickness aluminium frame with twin wall profile
• Maximum surface load capacity: According to IEC 61215, snow load 5400 Pa or 550kg/m &Wind load 2400pa
• Holes: Mounting hole 4 nos (ovel shape( 9*7mm) and 4mmØ Grounding hole 2 nos
• Product Warranty: 5 Years
• Performance Guarantee: Guaranteed Power Output of 90% for 10 Years and 80 for 25 Years%
• Approvals and Certificates: Tuv: Iec 61215 Ed.2, Iec 61730 ,Iec 61701
• Packing Information: 2 in 1
• Cells SPV: 72

• Material: Poly Crystalline
• Application: Home, Office etc
• Size: Standard
• Voltage at NOCT: 9-12 V DC
• Power: Available in 10Watt To 250Watt
• IP Rating: IP 65
• Search Protection: 5/10 KV
• Power Factor: 0.97

• Brand Name: Sun-Green
• Maximum Power: 101 - 245 W, 11 - 99 W, 100 W, 250 W
• MNRE Approved: Yes
• Operating Voltage: 12 V
• Type of Solar PV Module: Mono Crystalline, Poly Crystalline
• Warranty: 20 Years
• Features: High-Quality Cells, Wide power-range, Bypass diodes to avoid the effect of partial shading, Anodized aluminum alloy frame

• Warranty: 5yrs
• Brand Name: Elecssol
• Maximum Power: 1 - 10 W

PV solar plants using First Solar’s advanced thin-film series 4 modules enjoy better energy yield, proven reliability and industry-leading durability.

• Wattage: 1 W - 380 W
• Solar Cell Type: Mono,Poly,Thin-film
• Voltage: 6 V - 35 V
• Warranty: 25 years

Our organization is regarded amongst the distinguished organization offering the finest collection of solar module. Solar modules are made using the finest quality raw material that are quality certified and tested. The entire products are designed as per set industrial norms and standards. The offered product is provided in various specifications to choose from. One can easily get this from the market nearby at an reasonable rates. features: easy to use sleek design high durability
