FTN Series offers the perfect solution for those outdoor areas where environmental disturbances and small animals may cause false alarms.   5m/2m narrow range ● 190° horizontal flexibility ● Enhanced pet immunity ● Super Multi Dimension Analysis Logic ● Double conductive shielding ● Intelligent AND logic

With long, narrow detection areas that extend from both its sides the BX-80N is specifically designed to be wall-mounted centrally on a building, covering the building perimeter with a multi-layered, horizontal barrier that detects intruders before they break in. To help reduce false activations, the range can be adjusted so that detection extends only to the end of the building. The unit also has a size-judging function, which helps it discriminate between large and small objects within the detection area. The BX-80N is stylishly designed to blend in with any architecture and is simple to install and set up - there being no need to align transmitters and receivers. FEATURES   ● Double conductive shielding ● Advanced temperature compensation ● Limited detection range function ● Size judging function to avoid false alarms ● Variable detection range up to 24m(12m on each side) ● Audible alarm indicator to deter intruders ● Attractive, slender design

The new telescope lens has a high level of visibility for optical alignment work. We call Sniper viewfinder. FEATURES ● Detection range 60m/100m/200m ● International protection IP65 ● Alignment dial ● Sniper viewfinder with X2 magnification ● Vivid interior color ● Quad beam with aspherical lenses

The AX-70/130/200TN Series of short range photoelectric detectors are compact in design with IP65 high durable structure. Rubber packing is used for all conceivable points where water, dust or bugs may penetrate, such as wiring holes, wire ports and the outer chassis. Preventing these factors helps deliver performance with higher reliability in severe outdoor environmental condition. In addition, the length between the upper and lower optics, and the width of the optics are ideally engineered to produce the most intelligent detection pattern which reduces false alarms by detecting human intruders only. AX-70TN – Detection range 20mAX-130TN – Detection range 40mAX-200TN – Detection range 60m FEATURES ● IP65 structure ● Lightning and surge protection ● Anti-frost hood cover ● 99% beam blocking stability ● A.G.C. circuit ● Adjustable beam interruption time

The VX-402 provides an innovative solution to external area detection. It employs a highly reliable dual detection technique, which prevents false activations caused by small animals and birds. Two discrete detection areas are created and only when an intruder is detected inside both areas is an alarm output triggered. Double Conductive Shielding ensures that the sensor is resistant to interference from foreign light sources such as the sun and car headlights. FEATURES ● Limited detection range function ● Size judging function ● Double conductive shielding ● Sensitivity selection switch ● Temperature compensation ● Selectable N.C./N.O. alarm output ● Photocell for day and night operation

The SIP-3020, SIP-4010, and SIP-404 detectors in the REDWALL-V Series are designed for use in small and mid-sized outdoor areas. They have an intelligent detection system that uses data on the ambient environment, such as temperature and illuminance conditions, to automatically adjust the sensitivity. Mechanisms for easy installation enable accurate adjustment of the detection area at setup, which results in more reliable operation. The optional AVF-1 Area View Finder allows the installer to visually identify the detection area. The detectors are also equipped with anti-rotation and anti-masking. They can also detect vandalism or tampering on the units. These functions provide greater security in operations. Detectors in the REDWALL-V Series are ideal for triggering outdoor camera systems where high performance is required.   Intelligent PIR Detection System - Detection of ambient temperature and illuminance for automatic sensitivity management - Advanced detection algorithm - Three dual pyro-elements with patented Double Conductive Shielding ● Anti-vandalism functions - Anti-rotation function with 3-axis accelerometer - Anti-masking function with photo-beam - Reinforced polycarbonate housing - Max. 4m (13ft.) installation height ● Independent sensitivity selector for near/far areas ● Detection range selector ● Adjustable alarm interval time ● Detection logic selector ● Independent N.C. and N.O. outputs ● BS8418 Compliant - U.K.

The LX Series is robust, weatherproof and specifically designed for short-range outdoor applications. With wide-angle and long-range options, advanced features such as sensitivity and range adjustment and a built-in light sensor providing day and night modes, the LX-402/802N Series is highly versatile. An ingenious mirror assembly provides a pet alley configuration and Double Conductive Shielding ensures that the sensor is resistant to interference from foreign light sources such as the sun and car headlights. LX-402 – 12×15m 120° wide angle modelLX-802N – narrow & long range model   FEATURES ● Double conductive shielding ● Selectable detection patterns (pet alley or multi-level) ● Area-masking strips (LX-402 only) ● Sensitivity selection switch (high, mid and low) ● Selectable pulse count (test or 2) ● Day & night modes

Limited detection range function, Size judging function, Double conductive shielding, Sensitivity selection switch, Temperature compensation, Selectable N.C.N.O. alarm output, Photocell for day and night operation.

The AX-350/650TF Series of long range photoelectric detectors with selectable beam frequencies. The selectable beam frequencies can be used to avoid unwanted crosstalk that can occur when using multiple photobeams over long distances or beam stacking applications. Also the AX-350TF/650TF Series employs multiple beam technology and utilizes an AND circuit that requires all beams to be interrupted simultaneously before an alarm is generated. This reduces false alarms due to accidental beam interruption by falling leaves and small animals. AX-350TF – Detection range 100m AX-650TF – Detection range 200m FEATURES ● Selectable 4 channel beam frequencies ● 16 step LED indicator ● Environmental disqualification circuit ● IP54 structure ● Lightning and surge protection ● Anti-frost design ● 99% beam blocking stability ● A.G.C. circuit ● Adjustable beam interruption time

Model : AX-350TF

With the growth of our personal possessions, the need for their protection has become integral. Perimeter intrusion has become a common menace these days, and owing to that,security aspects likehaving boundary surveillance and perimeter security installed have become a prerequisite. Having them in place can help you stay safe and worry-free about your home, and the possessions inside. So why wait? Optex, a leading intrusion alarm system manufacturer, offers a range of home and commercial security products to keep the miscreants at bay.Withthe safety of your property and its valuables in the good hands of Optex, you can rest assured with complete peace of mind and a strong sense of security

There is not much use of detecting an intrusion until and unless an alarm is raised. That is why you need an intrusion alarm system to protect your property from unwanted visitors. A proper intrusion alarm is a system designed to detect intrusion into a building or area. An Intrusion alarm system manufacturer designs such systems for residential, commercial, industrial, as well as military properties for protection and raising alarms against burglary or property damage, as well as for personal protection against intruders. In addition to the sensor technology that one can install for the protection of their property, installing an intrusion alarm also needs to be considered. Optex Pinnacle India, an expert intrusion alarm system manufacturer in India, can ensure proper protection for you. There are a variety of alarms monitoring systems or operator front-ends that are available as per your requirements. Each system has unique features available, but the basic functions that all systems follow are: -Displaying the alarm locations in an easy-to-understand format, displayed mostly as multiple levels of overlaid maps that are helpful when it comes to detecting the exact location of the alarm trigger.

OPTEX developed a unique pyro-element, which creates original area configuration with 94 high density detection zones. By utilizing the AND detection pattern technology - upper and lower detection areas have to be activated in order to generate an alarm condition. The HX-40 prevents false alarms caused by pet or small animal. The dual signal processing circuit automatically adjusts and sharpens its detection sensitivity to assess surrounding environmental conditions so the HX-40 offers high detection performance against missed alarms in a hostile environment. Mounting height 2.5m - 3m ● Dual signal processing circuit – Summer night compensation logic – Advanced temperature compensation logic ● 180°angle adjustable bracket / Hood ● Intelligent AND detection logic ● Vegetation sway analysis logic ● Double conductive shielding ● Ideal detection area setting – adjustable detection length – spot area flexible masking

HX-80series offers high detection performance. The most important element in reliable outdoor detector is accuracy to distinguish a human from a small animal. FEATURES ● Mounting height 2.5-3m● Flexible detection area setting● Intelligent AND logic with unique pyro-element

Of the latest developments in outdoor security technologies, the quad beam detector has been one of the most successful. These have a quad lens set up between a transmitter and a receiver communicating via pulsed AIR Beams, as compared to the dual lens set up of previous detection systems. This very design nature of a quad beam detector can significantly help reduce false alarms. In addition, these detection systems offer double modulation beams that differ in pulse patterns, which in turn helps enhance signal discrimination against potential noise interference such as sunlight or other external light sources. One of the best innovations in intrusion detectors, the multifaceted setup of quad beam detectors provide an almost fool proof level of defense for all kinds of properties, be it commercial, industrial or even residential. The quad beam detector can be used in a number of mounted detection systems. Though it is one of the most effective solutions for rugged, industrial installations with its features of restricted false alarm ratio and high uptime of system, it works well in commercial and residential areas as well.
