Techmech Cranes India Pvt Ltd Medchal, Hyderabad, Telangana

We are a well-known manufacturer & supplier of winch stacker. The winch stacker has an open platform with its two ends suspended from a guided mast, which is fixed. The machinery used for lifting is either suspended along the mast in the air or on the structure’s top. This arrangement in the winch stacker is better than the conventional elevators since the overall structural cost is much cheaper. Installations take less space thus making lifting/lowering of material easier. Winch stacker that we offer is a handy system for your material lifting needs as it can be operated from any floor.

We provide Underslung Cranes that are available in Single Girder and Double Girder Construction. The Underslung Cranes are constructed with a Bridge Girder that is fitted to the end of the lower load operating trucks that carry the runway girder’s flange. This is typically supported from the trusses of the building roof. Our Underslung Cranes come in Hand Operated crane motions and Electrically Operated crane motions. Underslung Cranes are also known as Transfer Cranes as they can be used to transfer loads from one bay to another. Loads are transferred either from crane to crane or by fixed transfer sections with the Underslung Cranes, which cannot be done with EOT cranes.

We are the leading supplier of this products.

Color : Any

Condition : New

Our company is a Hyderabad based Manufacturer & Supplier of Gantry Cranes, also known as Goliath Cranes. Gantry Cranes are suitable for applications where overhead runways are very long, require much capital for erection, and have an alignment that is difficult to maintain. In comparison, it is easier and cheaper to lengthen the runway to increase the Gantry Cranes� working area. We offer well-designed Gantry Cranes that are perfect for heavy-duty applications. The types of Gantry Cranes we provide are Deck-Leg Gantry, Through-Leg Gantry, and Semi Gantry. Types Available Deck Leg Gantry : Most commonly used type, both the tracks of Deck Leg Gantry are on ground level and the trolley travel is present between the legs.Through-Leg Gantry : This type of Gantry is used in conjunction with a cantilever girder extension from one or both ends. This type of construction allows handling loads outside the area which is bounded by runway rails. Load may not necessarily be carried through the leg.Semi Gantry : The construction of Semi Gantry is compatible with both Deck Leg and Through Type Gantry. Semi Gantry Cranes possess unequal length legs so as to operate on railway tracks with different elevations. These cranes are custom made and are available in Singe Girder, Double Girder and Offset Crab Monobox. Useful For PortsStockyardsScrap yardsRailway yardsContainer HandlingConstruction sitesMarble / Granite Industry

We are offering Jib Cranes. The term “jib crane” covers a design of cranes that has a rotating boom attached to a mast which is held in a vertical position by floor and ceiling mounting or by wall bracket mounting. However, the most widely used design is the self-supported type at the base.by handling material to and from machine tools, forging presses and other production machines, jib cranes relieve congestion and increases production, with only a relatively small investment. These cranes relieve the overhead crane of much work and reduce waiting time. “techmech cranes” range of jib cranes (upto 5.0 ton capacity & 8.0 mtr. Jib radius) consists of the following:- base mounted type: this self-supported jib crane is designed for base plate mounting on concrete foundation, and has 360° rotation. fixed wall bracket type: this jib crane is deigned for wall / rcc column bracket mounting and has 200° maximum rotation.covers the area nea the bracket mounting without obstruction at floor level. travelling wall bracket type: covers the lengthwise area near the building columns without obstruction at floor level. It requires special design for columns. These cranes do not rotate but travels on runway tracks suspended along building / shed columns. all the three motions (hoisting, trolley travel and rotation) may be hand-operated or electrified or a combination such as electric hoist with hand power rotation and trolley travel. These type of cranes are widely found in applications like fabrication shops, machine shops, assembly floors, loading and unloading purposes and can be both outdoor as well as.

We are instrumental in offering Freight Elevator which is commonly known as Goods Lift. Freight Elevator is used exclusively for vertical lifting of freight in a cage. The cage moves on rigid guide rails. Freight Elevator is used where material shifting within different floors of a building or workshop takes place. Fixed base mounted Twin Rope Drum Winch is used for the hoisting or lowering of the Freight Elevators. The Twin Rope Drum has a true vertical lift with a unique feature which is called Dual Load Path System. This helps in preventing fall of cage in case of rope failure. Meanwhile, for your convenience, it helps to use the lift and get the wire rope replaced. Specifications Cage size : From 1.0 x 1.0 x 2.0 m to 4.0 x 4.0 x 3.0 m (W � D � H).Lifting capacity : From 0.5 ton up to 5.0 ton Safety Features Of Freight Elevator Roller lever type floor limit switch : To allow Cage to sustain floor levels.Geared rotary type limit switch : To avoid over travel of the cage in Top / Lowest floor level can be avoided with the availableGravity type limit switch : To act as acute safety limit switch in case any or all other above switches fail or even in case the Push button contacts get welded or stuck.

Our company is a prominent Manufacturer & Supplier of Single Girder EOT Crane that finds its applications in different industries. Single Girder EOT Crane has robust construction to ensure quality and functionality. Single Girder EOT Crane offered by us is made of quality tested materials. The Single Girder EOT Crane is easy to operate and has greater flow coverage. Specialties Application specific designHighly efficientModular design SpecificationsCapacity (T)Span (Mtrs.)BridgeA Mtrs.B Mtrs.C Mtrs.D Mtrs.Wheel LoadNet Wt. (MT)E1/E2 (Mtrs.)1.08Beam0.6500.650.90.70.971.600.210Beam0.750.659.00.71.062.030.215Beam0.800.650.90.71.263.000.220Beam0.800.650.90.71.594.100.22.08Beam0.750.800.90.71.541.920.210Beam0.800.809.00.71.602.120.215Beam0.800.800.90.71.903.350.220Beam0.800.800.90.72.264.800.23.08Beam0.800.901.00.72.102.000.210Beam0.800.901.00.72.222.500.215Beam0.900.901.00.72.624.100.220Box1.000.901.00.73.176.300.25.08Beam0.801.101.20.93.372.900.2510Beam0.851.101.20.93.423.100.2515Beam1.001.101.20.94.055.600.2520Box1.101.101.20.94.507.400.257.58Beam0.851.401.251.04.853.600.2510Beam0.901.401.251.05.004.200.2515Box1.001.401.251.05.506.200.2520Box1.201.401.251.06.078.500.2510.08Beam0.801.601.401.06.324.400.2510Beam0.901.601.401.06.475.000.2515Box1.201.601.401.07.027.200.2520Box1.301.601.401.07.559.300.2515.08-1.001.91.501.19.376.000.2510-1.101.91.501.19.506.500.2515Box1.251.91.501.110.129.00.2520Box1.401.91.501.110.8712.000.2520.08-1.002.21.501.112.206.800.2510-1.102.21.501.112.357.400.2515Box1.352.21.501.113.3011.200.2520Box1.502.21.501.114.1014.400.25

We provide high quality double girder eot crane made of quality tested materials. Double girder eot crane provided by us is checked under rigorous quality tests during manufacturing to ensure quality. The unique qualities like robust structure and application specific design makes our double girder eot crane special. specifications wheel loads include no impact allowance.dimensions are based on 20 mtrs. Span(s) and 10 mtrs of lift.wheel base 'w' may be increased for longer lifts.all dimensions shown are for standard headroom applications and may be varied widely to suit conditions. specificationstype - I main mt duty aux. Mt a mts b mts c mts d mts e mts f mts l mts wheel basemts wheel loadmt trolley wt.mt crene wt.mt 5 I - 1.7 0.1 - 0.65 1.1 - 4.80 4.00 6.42 1.50 13.2 ii - 1.75 0.1 - 0.65 1.1 - 4.80 4.00 7.13 1.50 14.00 iii - 1.85 0.15 - 0.65 1.1 - 4.80 4.00 7.85 2.2 16.2 iv 1 1.85 0.15 0.5 0.65 0.9 0.25 0.8 4.00 8.4.00 3 17.6 10 I - 1.8 0.15 - 0.65 1.1 - 4.80 4.00 10.26 2.05 16 ii - 1.9 0.15 - 0.65 1.1 - 4.80 4.00 11 3.45 17.5 iii 3 1.95 0.15 0.65 0.65 0.9 0.4.00 4.80 4.00 11.87 4.5 20 iv 3 2.25 0.3 0.8 0.7 0.9 0.4.00 5 4.00 13.35 6.5 23.9 15 I - 1.95 0.15 - 0.8 1.2 - 5.3 4.3 14.55 3.70 21.50 ii - 2.1 0.5 - 0.8 1.2 - 5.3 4.3 15.25 5 23 iii 5 2.35 0.4.00 1 0.8 0.9 0.6 5.5 4.5 16.65 7.1 26.5 iv 5 2.7 0.4.00 1.2 0.8 0.9 0.65 5.5 4.5 17.55 9.2 28 20 I - 2.1 0.5 - 0.8 1.30 - 5.5 4.5 17.68 5.2 22.5 ii - 2.2 0.55 - 0.8 1.30 - 5.5 4.5 18.55 6.2 25 iii 5 2.6 0.35 1 0.8 0.9 0.65 5.5 4.5 19.4.00 7.5 27.1 iv 8 2.7 0.25 1.2 0.8 0.9 0.65 5.5 4.5 21.02 9.6 31.50 25 I - 2.2 0.55 - 0.8 1.50 - 5.5 4.5 20.87 5.9 24.6 ii - 2.5 0.35 - 0.8 1.50 - 5.5 4.5 21.8 6.8 27.4.00 iii 5 2.7 0.35 1 0.8 0.9 0.65 5.5 4.5 23.32 8.8 31.50 iv 8 3.05 0.47 1.2 0.85 0.9 0.9 5.5 4.5 25.17 10.7 37 30 I - 2.65 0.5 - 0.8 1.50 - 5.5 4.5 24.52 6.7 28.4.00 ii - 2.7 0.35 - 0.8 1.50 - 5.5 4.5 25.6 8.4.00 31 iii 10 3.05 0.57 1.1 0.85 0.9 1.05 5.5 4.5 27.6 10.3 37.1 iv 10 3.1 0.72 1.2 0.85 0.9 1.1 5.5 4.5 29.1 12.2 40.3 35 I - 2.65 0.35 - 0.8 1.65 - 5.5 4.5 27.75 7.6 30.1 ii - 2.8 0.57 - 0.8 1.65 - 5.5 4.5 28.92 9 32.8 iii 10 3 0.72 1.1 0.85 0.9 1.1 5.5 4.5 30.8 11.30 38.6 iv 10 3.5 1 1.30 1 0.9 1.2 5.5 4.5 33.17 13.2 45 40 I - 2.65 0.3 - 0.8 1.7 - 5.5 4.5 30.85 8 32.1 ii - 3 0.57 - 0.85 1.7 - 5.5 4.5 32.22 9.9 34.7 iii 10 3.1 0.72 1.1 0.85 0.9 1.1 6.3 5.3 33.85 12 40.1 iv 15 4.00 1.30 1.30 1 1.05 1.1 7 5.5 37.17 15 49.8 50 I - 3.1 0.67 - 0.85 1.8 - 5.5 4.5 37.95 9.5 37.8 ii - 3.1 0.72 - 0.85 1.8 - 6.3 5.3 39.07 10.8 41.30 iii 10 4.00 1.30 1.30 1 1.05 1.30 7 5.5 41.77 14.6 48 iv 15 4.80 1.50 1.30 1.30 1.2 1.2 7.8 4.80 45.7 18.8 59.5 60 I - 3.1 0.72 - 0.85 1.8 - 6.3 5.3 54.807 11 44.00 ii - 3.70 1.30 - 1 1.8 - 7 5.5 47.75 14.80 50.8type - ii 60 I 15 4.00 1.50 1.30 1.30 1.2 1.30 7.8 4.80 26.55 17.6 63.6 ii 15 4.80 1.60 1.30 1.50 1.2 1.30 7.8 4.80 28.05 21 70.8 80 I 20 3.70 1.30 1.30 1.9 1.4.00 1.50 7.8 4.80 33.62 23 50 ii 20 3.70 1.30 1.30 1.9 1.4.00 1.50 7.8 4.80 34.62 26 55 100 I 20 3.70 1.50 1.30 1.9 1.4.00 1.7 8.05 5.05 52.07 31.8 98.8 ii 20 3.70 1.50 1.30 1.9 1.4.00 1.7 8.05 5.05 43.25 35 105 125 I 25 3.70 1.60 1.30 1.9 1.4.00 1.8 8.05 5.05 50.81 34.5 113 ii 25 3.70 1.60 1.30 1.9 1.4.00 1.8 8.05 5.05 51.95 38 120 150 I 25 4.80 1.60 1.4.00 2.5 1.8 2 8.85 5.85 62.68 44.5 148 ii 25 4.80 1.60 1.4.00 2.5 1.8 2 8.85 5.85 64.07 48.6 155
