ABB Distribution Transformer Dealers in Jaipur

• Country of Origin: India
• Type: Power Transformers
• Frequency: 50/60 Hz
• Voltage Class: 3.3, 6.6, 11, 22, 33 KV or any Specific.
• No of Phases: 3 Phase
• Vector Group: Dyn 1 or Dyn 5 or Dyn 11 or any specific.
• Insulation: Insulating Fiber glass epoxy and epoxy resin.

Industrial, Substation & Distribution purpose manufacturing range upto 2MVA. 11KV, 22KV naturally air cooled. A dry type transformer has an iron core, vacuum pressure resin impregnated high voltage windings and low voltage windings. The Low voltage winding is constructed with conductors. Depend nomex insulating material includes and apparatus to secure the windings in place during a vaccum and pressure resin impregnation process. The result is a coil that exhibits high short circuit protection due to the tightly bond conductors comparable to completely resin encased molded transformers at a substantially reduced cost. Transformers at a substantially reduced cost.   Application Areas Of Dry Type Transformers These Transformers are suitable where safety, reliability and low noise level are of the prime concern like: Airports  Electronics Industries  High Rise Buildings  Metro Railways  Nuclear Stations  Power Plants  Steel Plants  Stadiums  Textile Plants Chemical Plants  Hospitals Hotels  Material Handling  Oil Plants  Ports Ships Software Parks Schools Theaters & Multiplexes etc.   Advantages Of Dry Type Transformers These Transformers are safe, eco-friendly, fire-resistant, explosion proof, easy to install and easy to maintain beside being better in appearance. Moisture ingress resistant & immune to polluted atmosphere. Resistance to temperature fluctuations. Good impulse withstand strength. High dynamic short circuit & mechanical strength. Less space and civil work needed. Special safety features are not required. Longer transformer life due to low thermal and dielectric ageing   Standard Fittings Rating & Diagram Plate Lifting Lugs Earthing Terminals LV & HV Side Cable Box   Details : Off circuit tap changer to provide ±5% in 5 Step, ±7.5% in & Step taps in step of 2.5% and customer requirement. Winding Material Aluminum or Copper with multi paper covering (MFGC). Painting Epoxy, Polyurethane or customer specific.

• Weight: As per design
• Color: All type
• Surface Finishing: Coated
• Standard: IS-2026
• Cooling Type: Oil Cooled
• Usage: Outdoor, Industrial, Commercial, Electricity Distribution
• Insulation Class: F Class, H Class
• Brand Name: Choudhary transformers Udyog
• Certification: ISO 9001:2008
• Driven Type: Electric
• Warranty: 2 Year
• Country of Origin: India
• Mounting Type: All type
• Number of Phase: Three Phase
• Power Rating: All type
• Operating Type: As per requirement
• Winding Material: Copper
• Voltage Ratio: As per requirement
• Shape: As per requirement
• Packaging Type: Wooden Box
• Overall Length: As per design
• Speciality: Easy To Use
• Size (mm): As per design
• Winding Turns: Step Up, Step Down
• Onsite Support Available: Yes
• AMC Available: Yes

The company provides a wide range of Electrical Transformers in the market. We provide Electrical Transformers in desired variations and specifications, in order to facilitate options for clients. Our range of Electrical Transformers includes Distribution Transformer, Energy Efficient Transformer, Furnace Transformer, Power Transformer and Smart Transformer. We make sure that the quality of Electrical Transformers is never compromised with. We make Electrical Transformers available at the most competitive prices in the market.

• Country of Origin: India
• Voltage: 380 V

we are the leading transformer manufacturing company in rajasthan we provide good quality transformer’s on lowest price we also provide repairing service

• Power Rating: 160 KVA
• Cooling Type: Oil Cooled
• Customised: YES
• Condition: New
• Coil Structure: Toroidal
• Size: Compact

• Standard: All transformers are designed manufactured and tested as per IS-1180 & IS-2026 (or any other prevailing standard)
• Capacity: 16 KVA to 2500 KVA
• Type: Indoor or Outdoor
• Rated Voltage: HV : 33 KV, 11 KV , 6.6 KV or 3.3 KV, LV : 11 KV, 6.6 KV, 3.3 KV or 0.433 KV
• Cooling: Naturally oil cooled (ONAN)
• Conductor: Aluminium (up to 500 KVA )/ Copper.
• Vector Group: Dyn-11 ( or any other group as per requirement)
• Connection Terminals: LV : Suitable Brass Metal Parts covered with porcelain Bushings up to 400 Kva and Epoxy Moulded Copper Bus - bar type metal part for 500 Kva and above.
• Temperature Rise: 45 C for oil & 55 C for windings.
• Tappings: 5 % in steps of 2.5 % (Other ranges also available as per requirement)

We are offering danish power transformers are known for delivering excellent performance. The expert r&d team develops one of the most advanced designs to withstand short-circuit and impulse voltage tests.

The company is also manufacturing 33/11 KV Power Transformers upto 10 MVA ratings as per requirement of the customer. All transformers are manufactured with imported CRGO Silicon Steel annealed laminations and EC Grade Copper / Aluminum. Very safe flux densities and current densities are employed in designs for maximum safety and long life. All windings are fully ampere-turn balanced and adequate cooling ducts and radiators are provided to take care of overloads as per IS 6600. The Power Transformers are supplied with Off Load Tap Switch (OCTC) or On Load Tap Switch (OLTC) as per requirement of the customer. The cooling can be ONAN or ONAF as required.     Fittings: Silicagel Breather Magnetic Oil level gauge Earthing terminals Conservator with drain plug Dial Type Thermometer Explosion vent with equalizer pipe Pulling eyes/Roller arrangement/Skid base Winding Temperature Indicators Marshalling Box Arcing Horns Thermometer Pocket with Dial Type Thermometer   Optional fittings: Lightning Arrester & Tap Changer: Off Load or on Load.

• Capacity: Up to 10000 KVA
• No. of Phases: 3 Phase
• Frequency: 50 Hz.
• Voltage Range: 6.6 KV/10KV/11 KV / 22 KV / 33 KV
• Tapping: tapping range +5% to- 5% @2.5% on HT Side
• Winding: Aluminium / Copper Wound

runthala industries covers a wide range of oil filled power and distribution transformers with the off circuit tap changer conforming to the international standards of quality and safety. These transformers are designed and developed using the latest technology and provided with a variety of terminations so as to suit the requirements for any new installation or replacement. optimum efficiency is ensured by delicate proportioning of core and winding losses using crgo m3 to m5 moh lamination, electrolytic grade copper with transposition in l.v. Coil for current sharing in parallel conductors, electric grade press paper, boards and mineral oil. Thus a better regulation is achieved resulting in a longer life. Careful designing also reduces the noise level to the minimum.    standard fittings : rating & diagram plate - earthing terminals lifting lugs - thermometer pocket oil conservator with drain plug - air release hole with plug oil level indicator - explosion vent oil temperature indicator - drain –cum-bottom-filter valve silica gel breather - cable box on l.t. Side cooling radiators     optional features : buchholz relay  with or without alarm and trip contact - magnetic oil level gauge with or without  alarm contact pressure release valve - marshalling box with o.t.i. Or with o.t.i. And w.t.i  ( both ) cable box on h.t. Side - winding temp. Indicator with alarm & trip contact oil temp. Indicator with alarm & trip contact

Vardhmans Power Transformers (Oil Filed) have a robust design and sturdy construction to competently handle short circuits. Standard Fittings : Lifting Lugs Skid Base Roller Arrangement Rating and Diagram Plate Primary Bushings Secondary Bushings Oil level Guage Silica gel Breather Drain Filter Valves Thermometer Pressure Relief Device Explosion vent

We supply a wide range of power transformers that find extensive application in aerospace & utility applications. Made using the premium grade components, these power transformers ensure steady construction and minimum losses. Known for low maintenance and trouble free service, these are in compliance with ISS/REC standards. Our power transformer are made using premium quality raw material and are Rugged and Reliable. The high quality standards adapted by Oswal Transformers are appreciated throughout the world. Power transformers upto 10 MVA and 33 KV class are regularly manufactured and supplied to the domestic/international markets as per various standards. Our power transformer finds extensive application in following areas: Aerospace application Commercial and industrial power distribution system Oil and dry-type units Utility applications

Dry Type Transformers require minimum maintenance to provide many years of reliable trouble free service. Unlike liquid fill transformers which are cooled with oil or fire resistant liquid dielectric, Dry Type Transformer utilize only environmentally safe, CSA and UL recognized high temperature insulation systems. Dry Type Transformer provides a safe and reliable power source which does not require fire proof vaults, catch basins or the venting of toxic gasses. These important safety factors allow the installation of dry type transformers inside buildings close to the load, which improves overall system regulation and reduces costly secondary line losses. Our Dry Type Transformers are a rather mature product and technology but, of all the components in a power system, a transformer replacement can be a physically challenging event, extended delivery of a replacement or repair unit and expensive transportation costs. These are transformers whose core and coils are not immersed in insulating oil. Fire-resistant dry type or "cast resin" transformers are well suited for installation in high-rise buildings, hospitals, underground tunnels, school, steel factories, chemical plants and places where fire safety is a great concern. Hazard free to the environment, dry type transformers have over the years proven to be highly reliable. �Dry type� simply means it is cooled by normal air ventilation. The dry type transformer does not require a liquid such as oil or silicone or any other liquid to cool the electrical core and coils. Dry type transformers are voltage changing (Step-up or Step-down) or isolation device that is air cooled rather than liquid cooled. The transformer case is ventilated to allow air to flow and cool the coil (coils).

Transformer, Electrical Work Panel, Distribution Panel

We manufacture and supply a wide range of Power Transformers. The Power Transformers which we offer are manufactured using superior quality components as per the industrial requirements. These Power Transformers are extremely suitable for machine tools as well as mechanical equipments. The Power Transformers which we offer is made in compliance with the industrial standards. The Power Transformers offers high performance and ensures reliability to the users. Avail the Power Transformers from us at pocket friendly rates in the market. Known For : High performanceReliability Long service life Cost effectiveness

RUNTHALA Dry Type Transformer are fitted in enclosure for Indoor installations and are totally maintenance free and safe from fire as the material used is metal, ceramic, NOMEX and resin. It is environment friendly as there is no oil, hence handling becomes easier and there are no chance of spillages and leakage and there is minimal nontoxic smoke in case of fire.

Upto 25 MVA
