PVC Cable Dealers in Vishwakarma Industrial Area, Jaipur

We share a forefront with the famed organizations, supplying superior quality Gemini Installation Cables at affordable rates. We have hired expert warehousing personnel who keep a stringent check on the entire range of stored lot ensuring zero damage to the products till the final dispatch to the clients.   Construction : installation_vertiConductor - Solid annealed bare/tinned copper wire of 0.4, 0.5, 0.6, 0.7 or 0.9mm.Other sizes on customer’s request. Insulation - PVC/Solid polyethylene/Nylon. Single coloured conductors have fully color-coded insulation. Bi-coloured conductors are produced by printing of coloured rings on the coloured insulation. Cable Assembly - Components are assembled in concentric layers or in units for higher pair sizes. Core Wrap - One or more plastic tapes. Screen - If required, pairs/triads/quads can be individually or overall screened or both. Screening by Copper/Aluminum Mylar Tapes with minimum 30% overlap. Drain Wire - If required, solid tinned copper wire of 0.5 mm. Outer Sheath - PVC Black/Grey.

Our company is a highly acclaimed Manufacturer of PVC Cables from Rajasthan, India. We ensure that only certified components are used for fabricating the cable in compliance with set industrial parameters. These PVC Cables offered by us are extensively used for electrical installations in commercial or residential area. We are capable of delivering bulk orders of PVC Cables to customers across the world.

Low Voltage cables are used to supply power to large motors and other industrial equipments. These cables are manufactured for a voltage range of 1kV to 3.3kV for IEC and BS specifications. Electrical power, lighting and internal wiring in households, industrial and administrative buildings, agricultural premises, switchgear and distribution boards

LT PVC / XLPE Power Cables are available in different combinations with us, such as Aluminium, Copper Conductors, Round Solid conductor, stranded conductors, sector shaped conductors, taped inner sheath, extruded inner sheath, round steel and Aluminium wire/flat galvanized steel strip armoured/ unarmoured, single/ double outer sheathed, etc. are available. We provide types of insulation that includes - PVC, HR PVC and XLPE. The inner & outer sheaths can be PVC, HR PVC, FRLS, HR-FRLS or FR depending upon the application and requirement of customers.

• Voltage: 1100 V
• Length: 1.50 sq.mm
• Application: Agricultural Use
• Is It Insulated: Insulated

• Type: CU/PVC
• Brand Name: Gemini
• Number of Core: 1 Core
• Standard: BS 6004
• Conductor: Flexible Class 5 Copper Conductor to BSEN 60228
• Insulation: PVC Type T1 1 to EN50363-3

We are among the major players in the market offering top-notch PVC Cables and that too at marginal prices. We sternly keep a check on the designing and manufacturing of products and ensure that the material is strictly procured from the leading names only. The raw material is examined on the grounds of quality to deliver finest range of products. Features: Sturdy construction Finely finished Reasonably priced

We are offering lt-pvc cable operating charateristics 1. Max. Conductor temperature for continuous operation : 70°c 2. Ambient air temperature : 40°c 3. Standard ground temperature : 30°c 4. Thermal resistivity of soil : 150°c cmwatt 5. Thermal resistivity of pvc : 650°c cmwatt 6. Depth of laying (for cables laid direct in ground) : 75 cm 7.types of installation multi core cable - installed single single core cable - three cable in trefoil touching each other

PVC Power Cables, Pvc Compounds, pvc pipes granules

We are actively engaged in providing XLPE Cables to the clients. The XLPE Cables are manufactured from high grade raw material. The XLPE Cables are appreciated for their reliability and durability. Our XLPE Cables are tested on different parameters like quality and durability. Matching with the international standards, our XLPE Cables are high on demand in the market.

Our company has made its mark as the distinguished Manufacturer, Exporter and Supplier of PVC Insulated Unsheathed Single Core Cables from Rajasthan, India. Our professionals fabricate the PVC Single Core Cables in adherence to international quality norms. We package the Domestic Wire Cables in high-grade materials in order to ensure customers obtain a defect-free order. We are offering P.V.C Insulated Unsheathed Single Core 1100V at nominal rates Details : Packing - 90 Mtrs. Conductor - Plain Annealed High Conductive Copper Conductor Conforming to is : 8130 Insulation - Pvc Type a of Is: 5831 (general Purpose) Specification - Is: 694/1990

High Conductivity annealed stranded or solid copper conductors to SANS 1411 Part 1. Insulated with general purpose grade PVC in plain colours to SANS 1411 Part 2. INSTALLATION INFORMATION For the wiring of : Industrial Control Panels Light Fittings Housing Appliance Communication Panels PROPERTIES Specification :SANS1507-2 Temperature Range :-10°C to 70°C Voltage Rating :600 / 1000 V Core Identification :Blue, Black, Brown, Yellow/Green, Orange, Pink, Violet, Grey, White Red Packaging :100m Shrink-wrapped coils up to 70mm2

PVC Insulated Cables, pvc insulated sheathed cable, unarmoured cable

Pvc Cable, PVC Scrap

Pvc Cable, PVC Compound, PVC Granules, Pvc Pipe, PVC Wire, Pvc Cables

Pvc insulated & sheathed submersible cable with annealed bunched copper. Features resistant to oil & soil. high modulus of elasticity. Construction characteristics conductor flexibility: flexible bunched electrolytic grade copper as per class 2 or 5 of is: 81301984 sheath colour: black conductor material: annealed bare copper

Pvc Control Cable, Pvc Power Cable

PVC Insulated Multi Strand Cable, raw copper wire, transformer winding wire

PVC Insulated Flexible Four Core Flat Cable, Flexible Wire, Submersible Cable

Pvc Cable, dal mills, PVC Wire

Pvc Cable, AAAC Conductors, aac cable, abc cables, Acsr Cable, LT Cables

PVC Insulated Cables, PVC Insulated Wires

Pvc Cable, Wires

Pvc Cable, XLPE Cables, AB Cable Accessories, ACSR Conductors

Pvc Power Cable, electric control cables

polyvinyl chloride cable, Fence Pole, indoor vcb, epc

Pvc Cable, Power Cable

PVC Insulated Cables, Hdpe Pipes, Core Flat Cables - (3)
