Wireless Barcode Scanner Dealers in Jaipur

WIRELESS Radio/Range 2.4 GHz to 2.5 GHz (ISM Band) Adaptive Frequency Hopping Bluetooth v4.2 100 m (300 ft) Line of sight Battery 2400 mAh Li-ion minimum Number of Scans Up to 50,000 scans per charge Expected Duration of Operation 14 hours Expected Charge Time 4.5 hours User Indicators Decode LEDs, Rear View LEDs, Beeper (adjustable tone and volume) **MECHANICAL/ELECTRICAL** Dimensions (L x W x H) 62 mm x 173 mm x 82 mm (2.5 in x 6.8 in x 3.2 in) Charger/Communication Base CCB01-010BT-V1N 123 mm x 102 mm x 81 mm (5.2 in x 4.0 in x 3.2 in) Scanner Weight 210 g (7.4 oz) Charger/Communication Base Weight 179 g (6.3 oz) Operating Power (Charging) Charger/Communication Base: 5W (1A @ 5V with power supply); 2.5W (0.5A @ 5V with USB) Standby Power Charger/Communication Base: 0.5 W (0.1 A @ 5V) Host System Interfaces USB, Keyboard Wedge, RS-232, RS485 support for IBM 46xx (RS488) **ENVIRONMENTAL** Operating Temperature Scanner: 5°C to 40°C (41°F to 104°F); Charging: 5°C to 40°C (41°F to 104°F) Non-Charging 0°C to 50°C (32°F to 122°F) Charger/Communication Base 5°C to 40°C (41°F to 104°F) Non-Charging Temperature -40°C to 60°C (-40°F to 140°F) Storage Temperature -40°C to 60°C (-40°F to 140°F) Charger/Communication Base Storage -40°C to 70°C (-40°F to 158°F) Electrostatic Discharge (ESD) Scanners and Cradles: ±8 kV indirect coupling plane, ±15 kV direct air Humidity 0% to 95% relative humidity, non-condensing Drop Spec. 1.8 m (6 ft) drops to concrete Environmental Sealing IP52 Light Levels 0 to 100,000 lux (9,290 to 10,000 foot candles) **SCAN PERFORMANCE** Scan Pattern Area Image (1040 x 720 pixel array) Motion Tolerance 70 cm/s (27.6 in/s) for 13 mil UPC at optimal focus Print Contrast 15% Scan Angle Horizontal: 39.2° nominal; Vertical: 27.4° nominal Roll, Pitch, Skew ±180°, ±65°, ±70° Barcode Types Reads standard 1D, PDF, 2D, and DotCode symbologies Warranty 3-year factory warranty
