Forged Steel Globe Valve Dealers in Jalandhar

Banking on our world class facilities and high-tech machinery, we as a Manufacturer, Exporter and Supplier, aim to enchant our customers by distinction. Forged Steel Globe Valve on offer is available in an assortment of Specifications. The excellent material used in manufacturing is of top class quality. The manufacturing process is carried out by a team of skilled professionals who put their utmost efforts to ensure they produce the best possible quality.Specification : Bolted/ Welded Bonnet Size Range - 15mm to 50mm Product Standard -  BS - EN ISO15761/ASME B 16.34 Pressure/Class Rating - Class - 800 to 2500, Material of Construction - CS, SS, AS & Duplex Steel, Monel etc. Ends - Screwed/ BW / Flanged / Socket Weld

Bolted Bonnet, Outside And Yoke Type, Rising Stem

Salient Features Design Standard API 602 / BSEN ISO 15761 (BS 5352). Body and Bonnet are Phosphated, to ensure maximum resistance from rust. Bolted Bonnet, Outside Screw, Yoke Type, Rising Stem. Screwed Female Ends to BSPT / NPT / Socket Welded to ANSI B16.11. Test Pressure : Shell (Hydrostatic) : 207 bar (3000 psig) Seat & Back Seat(Hydrostatic) : 152 bar (2200 psig) Seat (Pneumatic) : 6.9 bar (100 psig) Maximum Working Temperature : 425°C

• Material: Steel
• Application: Water
• Brand Name: Qinn
• Item Code: Q-402

• Material: Forged Steel
• Usage/Application: Water
• Size: 50 mm
• Brand: Leader Valve
• Ends: Socket Weld
• Complies to: BSEN ISO 15761
• Bore: Regular & Full
• Item Code: FCS 007

Bronze Check Valve, Pressure Balanced Plug Valve

Specification & Features:Conforming To API 602 BS EN - 15761 Screwed female ends to NPT / Socket Welded Ends To ANSI B 16.11Bolted bonnet, outside screw, yoke type, rising steamSturdy in design & superb in quality.Handwheel operated.
