Disintegrator Dealers in Kanpur

• Brand Name: SINGHASINI

We are offering disintegrator. *ideally suited for coarse grinding of soft and medium hard minerals or vegetable products singhasini disintegrators are well designed hammer mills of simple and sturdy construction. The main shaft runs on ball/rollar bearings and it contains single row of four or more fixed hammers installed on a hub the grinding is achieved by the impact of the hammers against the liner fitted in the body, the fineness of the finished product is controlled by the replaceable screens fitted in the lower half of the body. All portion of the body where wear and abrasion is expected, are lined with replaceable liners.

Shri Krishnaji Industries Disintegrators are well designed hammer mills of simple and sturdy construction.  They are ideally suited where coarse grinding of soft and medium hard minerals products is required. The main shaft is the only revolving parts, which require no adjustment. This main shaft runs on Ball/Roller bearings and it contains fix/swing type hammers. The fineness of the finished products is controlled by the replaceable screens fitted on the lower of the disintegrator body. The screens of desire mesh can be easily changed. All portions of the body where wear and abrasion is expected are lined with replaceable hard alloy liners. The screen is adjustable. The grinding (disintegration) is achieved by the impact of hammers against the liner fitted in the body; and the fine products passes through the screens of desired fineness.   Range of Sizes Shri Krishna’ Disintegrators is available in Eight Sizes of different production capacities and power consumption.   Beaters The beaters are of steel alloy forged and heat treated. Their tips are coated with hard alloy.   Screens There are two kinds of screens (1) Steel Screens: having steel bars welded in steel frame for heavy work. (2) Perforated steel Plate screens: held in M.S. iron frame suitable to fibrous materials and light work.

• Type: Disintegrator
• Application: Industrial
• Color: Blue
• Condition: New
• Driven Type: Electric
• Warranty: 1year
• Automation Grade: Semi Automatic
• Sizes: 12 Inch to 52 Inch (9 Sizes)

  Introduction   Shri Krishna Disintegrator is a coarse grinding machine lined with suitable lining plates which uses grinding and crushing mechanism through hammers to pulverize the raw material.   Working   The raw material is fed into the grinding chamber of the machine through manual feeding i.e. the rate of feeding is controlled by the person who is feeding the material into the unit.   The main shaft is set in the grinding chamber which runs on ball or roller bearing and is the only revolving part in the machine. A single row of swing type hammers are fixed to the main shaft. These hammers crush the raw material entering the grinding chamber to the desired fineness by the movement against the lining plates. The unit is provided by replaceable screens placed at the bottom of the grinding chamber. This screen is of the desired mesh thereby allowing the pulverized material of uniform consistency to pass through it. This final pulverized product is discharged through the bottom cone for collection and bagging.   Application   Shri Krishna Disintegrator is the perfect machinery fit for crushing of soft and medium-hard minerals like Mica, Arrowroot, Bark, Sugar, Lime Stone etc. This machine can also be used in Coal Mining, Ayurvedic herbs Industry, Construction Industry, Food Processing Industry and many more.   Construction   Shri Krishna Disintegrator is made from best quality raw materials at our site. The Main body is fabricated with thick M.S. Plates or C.I. as desired and is electrically welded. Every contact part of the main machine is lined with suitable heavy duty lining plates. These lining plates are like a shield to the machine from wear and tear thus increasing the longevity of the machine. The hammers fitted on the main shaft are coated with hard alloys. The main shaft runs on Heavy Duty Ball or Roller Bearings.   There are two kinds of screens that can be used at the bottom of the grinding chamber:   Steel Screens:This type of screen has steel bars which are welded in the steel frame for heavy work. Perforated steel Plate screens:This type of screen is held in M.S. iron frame and is punched in the form of patterns. This is used for light work.   *Extremely fine screen should be avoided for better output.   Features   Low Power Consumption Noise Free Functioning Energy Efficient Easy to handle Low Maintenance Robust Design

• Size: 4-6″

DISINTEGRATOR with integral separator provide an automatic complete grinding system for medium to fine grinding of wide variety of spices, ayurvedic and other foodstuffs. They are suitable for handling different spices, herbs, roots, leaves, saw dust, cattle feed, bran, filtered cakes, sugar, soft & medium hard minerals and other foodstuffs. DISINTEGRATOR is multipurpose economy mill, which can handle lumpy and irregular size materials to produce coarse to medium fine powder. The material is fed to the mill through manual feeder where it is ground by Impact, Shearing, Crushing, and Auto collision of materials. The person feeding the material controls feeding to any desired rate. The material from the feeding hopper is fed directly in the grinding chamber and is conveyed to the periphery of the chamber through a single row of beaters, thus gradually reducing them to the desired fineness .The mill is a fixed hammer type machine incorporating a bottom screen. Screen of required gap is placed at the bottom of the chamber and allow the pulverised material to fall by gravity to the bottom cone.

Our Disintegrators are well designed hammer mills Of simple and sturdy construction. They are ideally suited where Coarse grinding of soft and medium hard minerals or of vegetable Products is required. The main shaft is the only revolving part, Which required no adjustment. This main shaft runs on Ball/ Roller Bearings and it contains single row of four (or more) fixed hammers Installed on a hub. The fineness of the finished product is controlled by the replaceable Screens fitted on the lower half of the Disintegrator body. The screen Of the desired mesh can be easily changed. All portions of the body Where wear and abrasions is expected, are lined with replaceable Hard alloy liners. The grinding (or disintegration) is achieved by the impact of the Hammers against the liner fitted in the desired fineness. Range Of Sizes : The “SOHANSON” Disintegrators are available in five different Sizes of different production capacities and power consumption. The Beaters : The beaters are of alloy steel forged and heat treated. Their tips are Coated with hard alloy by electric welding. The Screens : Fabricated steel screens having steel bars welded in steel frame.
