Grinding Mill Dealers in Kanpur

• Type: Disintegrator
• Application: Industrial
• Color: Blue
• Condition: New
• Driven Type: Electric
• Warranty: 1year
• Automation Grade: Semi Automatic
• Sizes: 12 Inch to 52 Inch (9 Sizes)

  Introduction   Shri Krishna Disintegrator is a coarse grinding machine lined with suitable lining plates which uses grinding and crushing mechanism through hammers to pulverize the raw material.   Working   The raw material is fed into the grinding chamber of the machine through manual feeding i.e. the rate of feeding is controlled by the person who is feeding the material into the unit.   The main shaft is set in the grinding chamber which runs on ball or roller bearing and is the only revolving part in the machine. A single row of swing type hammers are fixed to the main shaft. These hammers crush the raw material entering the grinding chamber to the desired fineness by the movement against the lining plates. The unit is provided by replaceable screens placed at the bottom of the grinding chamber. This screen is of the desired mesh thereby allowing the pulverized material of uniform consistency to pass through it. This final pulverized product is discharged through the bottom cone for collection and bagging.   Application   Shri Krishna Disintegrator is the perfect machinery fit for crushing of soft and medium-hard minerals like Mica, Arrowroot, Bark, Sugar, Lime Stone etc. This machine can also be used in Coal Mining, Ayurvedic herbs Industry, Construction Industry, Food Processing Industry and many more.   Construction   Shri Krishna Disintegrator is made from best quality raw materials at our site. The Main body is fabricated with thick M.S. Plates or C.I. as desired and is electrically welded. Every contact part of the main machine is lined with suitable heavy duty lining plates. These lining plates are like a shield to the machine from wear and tear thus increasing the longevity of the machine. The hammers fitted on the main shaft are coated with hard alloys. The main shaft runs on Heavy Duty Ball or Roller Bearings.   There are two kinds of screens that can be used at the bottom of the grinding chamber:   Steel Screens:This type of screen has steel bars which are welded in the steel frame for heavy work. Perforated steel Plate screens:This type of screen is held in M.S. iron frame and is punched in the form of patterns. This is used for light work.   *Extremely fine screen should be avoided for better output.   Features   Low Power Consumption Noise Free Functioning Energy Efficient Easy to handle Low Maintenance Robust Design

• Brand Name: SINGHASINI

INTRODUCTION: SINGHASINI HAMMERMILL with integral separator provides an automatic complete grinding system for medium to fine grinding of wide variety of spices, ayurvedic. De-oiled cakes, granules and other foodstuffs. They are suitable for handling different spices, herbs, roots, leaves, saw dust, cattle feed, bran, filtered cakes, sugar, soft & medium hard minerals and other foodstuffs. WORKING PRINCIPLE: SINGHASINI HAMMER MILL is multipurpose economy mill, which can handle lumpy and irregular size materials to produce coarse to medium fine powder. The material is fed to the mill through manual feeder where it is ground by Impact, Shearing, Crushing, and Auto collision of materials. The person feeding the material controls feeding to any desired rate. The material from the feeding hopper is fed directly in the grinding chamber and is conveyed to the periphery of the chamber through a MULTIPLE row of beaters, thus gradually reducing them to the desired fineness .The mill is a swing hammer type machine incorporating a bottom screen. Screen of required gap is placed at the bottom of the chamber and allow the pulverized material to fall by gravity to the bottom cone. The Mill is so designed to give cooler powdering operation, and hence vital properties of powder like color, taste, flavor etc. are retained to its maximum level possible. CONSTRUCTION: The HAMMER MILL is fabricated out of thick M.S. Plates for better accuracy and reinforced ribbed for high strength. The upper half of the mill is lined with specially designed, sharp edged shearing type of Striking plate for better cutting grinding action and the lower half has M.S. Perforated screen for the desired fineness. Both the striking plate and screen frame are guided by special type of grooved ring for easy removal and cleaning purpose. The Main Shaft is supported on heavy duty self-aligning type BallRoller Bearings fitted in dust proof C.I. Bearing Housings.

• Voltage: 220V
• Automatic Grade: Automatic
• Driven Type: Electric
• Warranty: 2 Year
• Body Material: Mild Steel & Stainless Steel

This is a machine used for changing the size of the material to uniform size. This machine is used to remove big useless particles of sand or dust. The material is provided as the requirement of the customer (M.S or S.S). There is also a perforated sheet to provide uniform size.    Features :  Power efficient  Robust design   Strong construction  Negligible maintenance

• Material: Mild Steel
• Automation Grade: Automatic
• Brand Name: GL
• Motor Power: 2.5 HP
• Capacity: 1 Tons. / Hour
• Application: Used for Detergent Powder Blending

Shri Krishnaji Industries Disintegrators are well designed hammer mills of simple and sturdy construction.  They are ideally suited where coarse grinding of soft and medium hard minerals products is required. The main shaft is the only revolving parts, which require no adjustment. This main shaft runs on Ball/Roller bearings and it contains fix/swing type hammers. The fineness of the finished products is controlled by the replaceable screens fitted on the lower of the disintegrator body. The screens of desire mesh can be easily changed. All portions of the body where wear and abrasion is expected are lined with replaceable hard alloy liners. The screen is adjustable. The grinding (disintegration) is achieved by the impact of hammers against the liner fitted in the body; and the fine products passes through the screens of desired fineness.   Range of Sizes Shri Krishna’ Disintegrators is available in Eight Sizes of different production capacities and power consumption.   Beaters The beaters are of steel alloy forged and heat treated. Their tips are coated with hard alloy.   Screens There are two kinds of screens (1) Steel Screens: having steel bars welded in steel frame for heavy work. (2) Perforated steel Plate screens: held in M.S. iron frame suitable to fibrous materials and light work.

• Brand Name: SINGHASINI

We are offering disintegrator. *ideally suited for coarse grinding of soft and medium hard minerals or vegetable products singhasini disintegrators are well designed hammer mills of simple and sturdy construction. The main shaft runs on ball/rollar bearings and it contains single row of four or more fixed hammers installed on a hub the grinding is achieved by the impact of the hammers against the liner fitted in the body, the fineness of the finished product is controlled by the replaceable screens fitted in the lower half of the body. All portion of the body where wear and abrasion is expected, are lined with replaceable liners.

The company is one of the renowned Manufacturers, Exporters and Suppliers of Cage Mills in Kanpur (India). The Cage Mill, offered by the company, is a quality Detergent Powder Making Machine. The Cage Mill is used for the disintegration of the lumpy mass before the treatment of the same in the flash dryers. The feed material is discharged into the flash dryer. Attributes Of Cage Mill Efficient and accurate operationsLong service lifeDurable and reliableSturdy construction

This is a mixing machine Provided with the arrangement of two Z-shaped arms which are when rotating mix the mass (Soap Flakes) inside the machine in a dough making manner. In this machine the colour, Perfume, and other kind of filler additives are added and mix with the soap. For complete customer satisfaction, we are engaged in manufacturing, exporting and supplying a broad array of Cage Mill. This mill is extensively used in numerous industries for crushing non-abrasive materials. Provided mill is manufactured at our technologically-advanced manufacturing unit under the proper direction of our highly skilled professionals. Only quality tested components and ultra-modern manufacturing technique is used while manufacturing process of the offered mill. Also, our global clients can avail this Cage Mill from us in varied models and specifications at the most reasonable price. Type 1 : Prod. : 300 Kg / 10min. Dimension : 16”x36” Power : 7.5 HP Type 2 : Prod. : 500 Kg/ 10min. Dimension : 18”x36” Power : 10 HP   Features : Power efficient Robust design Strong construction Negligible maintenance

The premix batch after Homo Mixer is passed through the Cage Mill. This Machine is designed to bring uniformity in sizes of particles and also to crush the hard lumps which remain unbroken within the Homo mixer. After Passing the Powder mix through this machine no further Sieving is required. After the discharge of this machine Powder mix is send to the Packing Silo.

The Grinding in Singhasini Roller Mill takes place by attrition and compression, which results due to the centrifugal force generated by the suspended Rollers running inside a stationary Bull Ring. The material is pushed between the revolving set of Rollers and Bull Ring and gets ground.An Upgoing stream of air lifts the fine material which passes through a classifier, the course particles are rejected and fine material is being collected in a cyclone collecter.

We are offeringFor dry or wet grinding and mixing of powders, pigments paints etc. Maximum load capacity 40 kg. Speed of 70 RPM. Heavy duty model which require no foundation.

Cage MillDesigned to break lumps & sieve detergent powder, adoptable to select suitable size of mesh to deliver acceptable particle size.Size:400 x 800mm , 600 x 900mm , 600 x 1250mm , 700 x 1500mm

Owing to a vast experience and knowledge of the industry, we have emerged as a major Manufacturer, Supplier, and Exporter of Cage Mill. We are based in Uttar Pradesh, India. We are well-equipped with the ultra-modern machines and equipment required for developing a matchless product. We fabricate it under the guidance of expert professionals, who are well-versed with the set international standards and norms. We offer this machine at a highly affordable rate. Details : Cage Mill is designed to bring uniformity in sizes of particles and also to crush the hard lumps which remain unbroken within the Homo-mixer/ Ribbon blender. After passing the mixed powder through this machine no further sieving is required in general.As a sieve is fit on the mill’s end to eliminate the oversized particles continuously through sieving.

Our Disintegrators are well designed hammer mills Of simple and sturdy construction. They are ideally suited where Coarse grinding of soft and medium hard minerals or of vegetable Products is required. The main shaft is the only revolving part, Which required no adjustment. This main shaft runs on Ball/ Roller Bearings and it contains single row of four (or more) fixed hammers Installed on a hub. The fineness of the finished product is controlled by the replaceable Screens fitted on the lower half of the Disintegrator body. The screen Of the desired mesh can be easily changed. All portions of the body Where wear and abrasions is expected, are lined with replaceable Hard alloy liners. The grinding (or disintegration) is achieved by the impact of the Hammers against the liner fitted in the desired fineness. Range Of Sizes : The “SOHANSON” Disintegrators are available in five different Sizes of different production capacities and power consumption. The Beaters : The beaters are of alloy steel forged and heat treated. Their tips are Coated with hard alloy by electric welding. The Screens : Fabricated steel screens having steel bars welded in steel frame.
