Screw Conveyor Dealers in Kanpur

SINGHASINI Screw Elevators are widely used in all industries for handling of bulk solids . For an efficient operation the design has to be matched for the specific duty and characteristics of the bulk material to be handled . Particular care is required with infeed arrangements for optimum performance . All our elevators are individually designed and manufactured to secure the best results for each application. STANDARD SPECIFICATION : Inclination upto 90° can be accomodated. Gravity feed options are available.  OPTIONAL  EXTRAS : Clean out doors. Alternative material of construction and finish. Drive arrangement to suit individual requirements. Split casings for easy cleaning. Chute of hopper style inlets. Mobile or fixed units. Dust extraction hoods. Jacketed construction suitable for steam , oil or water. Screw Elevators are tailor made and sizes depend on individual requirement, should you require any information please feel free to get in touch with us.

These types of conveyors are basically for bulk materials with variable properties depending on the application. They can be sealed against dust or moisture, jacketed to act as dryer or cooler. Screw flights fabricated in an array of configurations perform different tasks or help to convey different types of materials. Ribbon flights density and viscous materials which may usually cause bridging at the centre tube. Screw conveyors are compact and easily adapted to suit any location. They can be manufactured in any type of orientation and direction either horizontally, inclined or vertical. These types of conveyors can be used to feed, distribute, collect or blend materials flow in processing or conveying operation. [1] Screw feeder / dozer [2] U- Trough / Tubular Screw[3] Inclined Screw [4] Bi-direction Screw   The materials of construction may be mild steel or stainless steel depending on the requirement. Special materials like polymers have also proved to be an excellent alternative to steel.

• Brand Name: Mrida
• Material: Stainless Steel
• Type: Horizontal
• Capacity: 200 Kg
• Color: Blue
• Voltage: 220V
• Diameter: 25
• Usage/application: Powder, Grains Etc
• Automation Grade: Automatic
• Orientation: Horizontal
• Power: 1.5 Kwt

we are engaged in manufacturing and exporting an extensive range of Tubular Conveyor. Used to transfer materials from one machine to another, these machines are highly applicable in milling and construction industries. We manufacture the machines under the firm observation of the expert professionals making use of the quality approved materials sourced from the reliable vendors.

• Usage: Moving Goods
• Specialities: Long Life, Excellent Quality
• Driven Type: Electric
• Operating Mode: Automatic
• Corrosion Resistance: Yes
• Price: As per the Height of the Conveyor
• Sizes: 4 Inch to 12 Inch Length as per Requirement (6 Sizes)

• Machine Weight: 100-200 Kg
• Rated Power: 1-3 KW
• Packaging Type: Carton Box
• Usage: Moving Goods
• Voltage: 220V
• Phase: Single Phase
• Operating Mode: Automatic
• Machine Material: Mild Steel

To maintain optimum product environment, we use superior grade packaging material that is nontoxic. The labels on packs provide products details clearly and are smudge-proof. Quality is one aspect on which we can never compromise. And, for this, our personnel work hard and ensure that the entire lot complies with defined quality norms. Features: High-Performance Sturdy Structure Long Service Life

• Voltage: 440 V
• Frequency: 50 Hz
• Brand Name: Hovert
• Phase: Three Phase
• Power Source: Electric

This is a device used for transferring the material from Sigma Mixer to Plodder machine. The machine is provided with FourSix Screws through which material mixed and feeded to Plodder. The design of this machine provide the material feeding to Plodder with uniform rate of feed along with enhanced mixing of the material.

Screw conveyors are one of the most reliable and cost-effective methods for conveying bulk materials. Due to their versatility, screw conveyors can convey a wide variety of bulk materials ranging from dry, free-flowing Portland cement to wet, sluggish dewatered bio solids. Screw conveyors can be designed to operate in almost any position, from horizontal to vertical. Inclined screw conveyors are used to convey and elevate bulk materials from one level to another. Depending upon the bulk material and the objective, proper design and construction of an inclined screw conveyor will provide many years of uninterrupted service and productivity. The purpose of this article is to help the reader understand the basics of inclined screw conveyor design for various applications.   Working Principle :   A screw conveyor consists essentially of a shaft mounted screw rotating in a trough and a drive unit for running the shaft. The material is moved forward along the axis of the trough by the thrust of screw thread or flight. The trough is usually of the U-shape. A helical blade is attached to a drive shaft which is coupled to a drive unit. The shaft is supported by two end bearings and intermediate bearings. The U-shaped trough has a cover plate with an opening for loading the conveyor. A discharge opening is provided at the bottom of the trough. The loading and discharging points can be located anywhere along the trough. More than one feed hopper and discharge hopper may be fitted according to the necessity.   Application : Conveyor systems are commonly used in many industries, including the Pan Masala, automotive, agricultural, computer, electronic, food processing, pharmaceutical, chemical, bottling and canning, print finishing and packaging. Although a wide variety of materials can be conveyed, some of the most common include food items such as beans and nuts, bottles and cans, automotive components, scrap metal, pills and powders, wood and furniture and grain and animal feed. The principle of material movement along the trough is similar to the sliding motion of a nut along a rotating screw when the nut is not allowed to rotate. The weight of the material and the friction of the material against the wall prevent the load from rotating with the screw

We are offering singhasini screw conveyors are self contained, compact, dust tight conveyors designed for fast and convenient conveying of powders. They are used in leading processing plants for conveying dry powder grain size materials. principle of operation: materials that are powder granular in nature can be conveyed in a remarkable short time. In addition to conveying, mild mixing also takes place. Designed in such a manner that the flights of the screw convey the material from one end to the other. rugged construction: fabricated out of heavy steel, or any specified material of construction. Design aspects planned for maximum efficiency in leak proof construction. It has fabricated ‘u’ trough having well aligned and balanced shaft that carries screw flights over it. The shaft is supported on bearing housings & gunmetal hanger bearings. The conveyor is with built in drive arrangement gearbox as specified and supporting legs. The structure can be designed in such a manner so as to give a degree to the conveyor – this is done when the material is to be conveyed to a certain height.

Being one of the leading entities in the market, we are engaged in offering Screw Conveyor to the clients. We carry out our operations from Uttar Pradesh, India. We use SS/MS screws for our conveyors. It is manufactured by using the optimal grade components and progressive techniques. We are backed by a team of diligent professionals, which meticulously examines it on various quality parameters before making the shipment. We are renowned for offering a highly reliable after-sale service.

• Material: SS
• Motor Power: 10 HP
• Voltage: 220 V
• Power: 1-2 KW
