Well Pump Dealers in Karnal

• Discharge Range: 23 - 250 in 1 Phase 23 — 250 In 3 Phase
• Power Range: 0.5 HP - 5.0 HP in 1 Phase 0.5 HP - 10 HP in 3 Phase
• Version: 220-240V 50 Hz, A.G.-1 Phase, 350&40V — 3 Phase
• Speed: 2880 rpm.
• Head Range: 42 — 200 mtr In 1 Phase 42 — 350 mtr in 3 Phase
• Outlet size: 25, 32, 40 & 50 mm
• Degree of Protection: IP 68
• Maximum Outer diameter: 98 mm
• Duty: S1 (Continuous)
• Mounting Standard: As per NEMA

• Specification:
• Power Range: 0.5 HP - 1.5 HP
• Version: 220-240V,  50 Hz, A.C.
• Method of Starting: Capacitor start and capacitor run (CSCR) in water filled Capacitor start and run (CSR) in oil filled
• Speed: 2880 rpm.
• Discharge Range: 25 - 80 lpm
• Head Range: 12 - 83 mtr.
• Outlet size: 25 & 32 mm
• Degree of Protection: IP 68
• Maximum Outer diameter: 76 mm.
• Duty: S1 (Continuous)
• Mounting Standard: NEMA / Key way
• Material of Construction Pumps: NRV Housing
• Cast Iron (Regular) Stainless Steel (Platinum): Impeller
• Nory*: Diffuser
• Norly*: Pump Jacket
• Stainless Steel: Pump Shaft
• SS 410: Suction inter Connector
• Cast Iron (Regular) Stainless Steel (Platinum): Coupling
• SS 410 : Material of Construction Motor
• Upper - Lower Housing & Motor Base: Cast Iron (Regular) / Stainless Steel Jacket (Platinum)
• Stator Body: Stainless Steel
• Shaft: SS 410
• Bearing: Leaded Bronze in water filled Anti frictional deep groove ball bearing in oil filled
• Thrust Bearing Set: Carbon V/s SS in water filled

To keep a strict check on the quality of the products, we have hired a team of quality analysts having rich domain experience. We strictly follow the packaging guidelines and we ensure that finest quality packaging material is used as packaging protects the enclosed product from physical, chemical and microbiological invasion.   Details Product Code : BSP 39 Brand Name : SINGLA MOTORS Price And Quantity Minimum Order Quantity - 1 Unit of Measure - Piece/Pieces Applications: Municipal water supply Rural water supply Irrigation Sprinkler System Pressure boosting units and fire fighting system Industrial and mining application Ponds and Gardens Salient Features: More longevity High Operating efficiency Designed for wide voltage flactuation Easy to dismantle and repair Rigid construction Highly durable Water lubricated bearing Pumped Liquids:Clean, thin non-aggresive, nonexplosive, clear, cold, fresh water without abrasives.Trade Information Payment Terms - Cash Advance (CA), Cash in Advance (CID) Supply Ability - As Per Requirement Months Main Export Market(s) -  Asia, Middle East, Africa

• Power: 0.5 HP and 1.0 HP
• Power Source: 220-240 V, 50 Hz, 1 Phase
• Motor Speed: 2880 rpm
• Maximum Discharge Flow: 600 - 3000 lph
• Sealing: Mechanical Seal (Carbon V/s Ceramic)
• Brand: OSWAL
• Motor Frame: Aluminum
• Degree Of Protection: IP 54
• Insulation: Class B
• Suction Lift: 8 mtr
• Suction x Delivery Size: 25 x 25 mm
• Pump Casing: Stainless Steel
•  :

• Power: Electric
• Application: Rural water supply
• Theory: Jet Pump
• Fuel: Diesel
• Place of Origin: Haryana, India
• Usage: Water
• Brand Name: FARMBURG AGRO
• Port: icd tkd delhi
• Packaging Details: as customer requirement

We are best offering jet shallow well pump

shallow well pumps, Submersible Pumps, Centrifugal Monoblock Pumps

Borewell Pumps, Auto Parts
