APFC Panel Dealers in Kolkata

We are a prominent Manufacturer & Supplier of Automatic Power Factor Correction Panel. The Automatic Power Factor Correction Panel offered by us is available in the capacity of 60 to 1000 kVAr. Because of the high quality, efficient performance and long working life, our Automatic Power Factor Correction Panel is widely demanded by reputed firms like L&T Ltd., project NISER, Bhubaneswar, Orrisa, Technomac project Durgapur, etc. Specifications : APFC Panel with Microprocessor based relay for controlling power factor within required valuesRTPFC Panels using Thyristor based capacitor switching.Fully ventilation type panelEasy Maintenance and easy to remove capacitorUse of capacitive duty contactorsAlways maintain 0.99PF High-speed power factor correction Provision of detuned reactors the panels for reliable operation in presence of harmonics Features : We followed the proper IP - 54 standardProper water proof facilityAs per NFPA 70E rule - switches are properly covered to protect from deep burn in accident (Arc – flash Hazard)We use FRF supported terminals for – Easy cable connection, Prevent switch from damage and Prevent from short circuitWe use 8.8 HT bolt (Make Unbreako) for Busbar connection , to prevent Heat generation and damage of switchesWe use EC grade Aluminum Bus bar, for better conductivity and less resistance

• Brand Name: Technosoft
• Material: MS
• Surface Treatment: Powder Coating
• Automation Grade: Automatic
• Application: Industrial Applications
• Voltage: 440 V
• Display Type: Digital & Analog
• Phase: Three Phase
• Country of Origin: India
• IP Rating: IP65

• Power: 1-3kw
• Voltage: 220V

We are one of the well known manufacturers and suppliers of apfc panels in kolkata (west bengal). Our company is reliable, as we have satisfied numerous clients with our energy-efficient apfc panels over the years. We make panels available in various configurations and also offer individually tailored solutions for the same. Buyers can order for apfc panels in bulk and expect timely delivery.   Our apfc panels are appreciable for the following attributes : user friendly wide voltage measuring range aesthetically designed enclosure easy to install suitable for indoor and outdoor use

We, at our company provide our customers with a range of high performance automatic power factor corrector panel which is manufactured respecting the standards. The panels we make are exceptional because of its high grade materials and world class technology. The panels consists of banking pattern that is helpful for the development of the desired power factor for all kinds of loads and automatic control switch which maintains the load power factor for all kinds of load power factor by the sensing diverse parameters. The contacts that we made use of in the capacitor bank circuits are ideal for capacitor switching duties that is able to resist large transient current peaks at high frequencies. The contactors used here amplify of an operational life of 100000 switching conditions. The thyristor modular based APFC panel is available here too. For an individual capacitor steps, we offer three phase high rapture capacitor fuses. The fuses are fabricated according to the rules of modern industrial design with current limiting capacity of 100 kA. A broad range of APFC panels with 6, 8 and 14 stages of controllers also available at here. SPECIFICATION Rated Insulation Voltage: 0-780 Volt ACRated Operator Voltage: 110V (+/-10%), 220V (+/-10%) 415V (+/-10%) AC, System: 3-ph, 3 or 4 wireWithstand voltage: 8 KV for 1 Sec Rated Current: 100-1000Amp Fault level: 50KA for 1 Sec Ambient Temperature: 45°C Busbar Support: AL/CU as per client requirement Method of Cooling: Natural Process Degree of protection: IP-42, 54, 67 Switching: Contractor or Thyristor Dimension (mm): As per requirement Current Monitoring: As per requirement Phase Monitoring: Possible as per requirement Cable Entry: Top or Bottom Type test to be performed: Short Circuit with Stand temperature rise with stand & Degree of Protection Panel Cote: 7 tank Powder Coated Paint or as per Client’s requirement. Paint: RAL9002 or as per client requirement Panel Mounting: Floor / Ground Mounted, Wall Mounted, Mounted on Angle Frame

• Application: For contrilling the power factor, individual capacitors
• Material: Aluminium, Steel
• Voltage: 440V
• Phase: 3 Phase
• Features: Sturdy construction Resistance against corrosion User friendly interface
• Use: Industrial
• Feature: Longer functional life
• Operational Current: 2500 A
• Operational Voltage: 433 V

We make available, APFC & PLC Electrical Panel, which is manufactured using the best-quality materials. This panel is designed to perfection and is known for its smooth operations, low maintenance, high performance and flawlessness.

• Application: Control Panel
• Voltage: 220V, 380V, 440V
• Material: Mild Steel
• Power: 1-3kw, 3-6kw, 6-9kw
• Power Source: Electric
• Phase: Double Phase, Single Phase, Three Phase

As per customer requirement

Ø  What is power Factor? Power Factor (PF) is the ratio of Power Utilized (KW) and Power Drawn (KVA). Generally, when the applied to the electrical motors, the entire power is not converted as useful Work Done (KW). Depending on inductance of the motor a reactive power (KVAR) is generated which results in drawing of excess KVA. PF = KWH / KVAH To reduce the KVA drawn, the inductive KVAR is to be nullified by introducing an equal and opposite Capacitive KVAR according to the load pattern, thus OPTIMUM PF is maintained. Ø  Why Power Factor must be maintained?   By maintaining an optimum PF the Power drawn (KVA) can be reduced, thus reducing the current passing through the electrical circuits to the maximum extent possible (event up to 50%) thereby reducing the machine down time. reduction in heat losses in turn increases the life of the electrical circuits. The State Electricity Boards (SEB’s) has installed Digital Electronic Energy (Tri-Vector) Meters for consumers, which has the provision of showing the PF and insisting to maintain the average Power Factor above a Specified limit (0.85 – 0.90 PF) Otherwise, for every reduction of 0.01 from the specified PF, PENALTY is levied on the Energy Consumption Charges (KWh) on the Electricity Bill. SEB’s are also offering PF incentives if the PF is maintained above the specified PF. In few states, where the metering unit is KVAh and if the PF is maintained at its optimum of 0.99, the electricity bill amount itself is reduced considerably. The optimum Power Factor can be maintained by installing Galaxy Electro Tech’s AUTOMATIC POWER FACTOR CONTROL PANEL Ø  Salient Features of Galaxy Electro Tech’s APFC Panel: Adjustment to any step of capacitor value Micro controller based technology. Digital computation of various parameters Continuous monitoring of parameters like Line Voltage, Current, Active, reactive and Apparent Powers and energies Scrolling Display on a Dot Matrix LCD Protection of Capacitors against damage due to High Voltage, Low Voltage Tends to maintain 0.99 lag Plug-in terminal connection No-Volt release features to disconnect all capacitors in the event of power failure Dynamic control of Reactive Power and Power Factor RS 232 / RS 485 Standard output port (optional) Fine & Coarse correction Controller Ø  Benefits of Galaxy Electro Tech’s APFC Panel: Power Factor penalty is avoided Avail incentives by maintaining optimum Power Factor Optimize the capacity by reducing the maximum demand KVA Avoids excess demand charges Improvement in line voltage Reduced line current losses and cable overheat Enhanced life of electrical circuits Avail Depreciation Reduced consumption (KWH) charges Avoids overloading of Distribution Transformers Additional Service connections in existing generation of power by reducing Energy Losses Reduced line losses Benefits SEB’s and Nation Galaxy Electro Tech’s APFC Panels are available from 25KVAR – 2500KVAR  Model onwards

We are offering apfc panel. Application : improvement of power factor in the system ac rating volts : 0 – 800v ac rating amps : 100 – 1000a ac rating frequency : 50hz rated insulation voltage : 690v temp. Rise : up to 35c rise over 50c ambient. degree of protection : ip 52, 54, 55, 65 power bus. Bar : al or cu. Bas bar over current protection : properly panel cote : 7 tank powder coated paint and as per client’s requirement. panel mount : floor / ground mounted, wall mounted, mounted on angle frame. current monitoring : possible phase monitoring : possible configuration : based on customer’s requirement. type test performed : short circuit with stand temp. Rise with stand, degree of protection. product warranty : at list 12 month.

• Brand Name: BITCON
• Application: Industries
• Phase: 1 Phase,3 Phase
• Automation Grade: Automatic
• Rated Reactive Power: 50-3000KVAr
• Panel Type: Indoor / Outdoor
• Temperature: 25 Degree C - 40 Degree C
• Harmonic Attenuation: Up to 5%
• Input Voltage: 230-1000V
• Cable Entry: Top, Bottom
• Cooling Type: Forced Cooling using thermostat operated fan
• Item Code: BITCON-BITMatic

• Phase: Three Phase
• Material: Mild Steel
• IP Rating: IP65
• Ambient Temp.: 0 to 50 Degree C
• Operating Temperature: -20 to 60 Degree C

The Power Factor Improvement Panels provided by us are basically used for raising the existing power factor of the electrical system to 0.95. This is to avoid monthly penalty of the concerned electricity distribution company and also adds many years to the life of electrical equipment. Construction One incomer with metering provisionsPower factor controllerMany delta connected power capacitors Features Contractors charge the respective capacitorsController is FSU/MCCB/PFReliable performanceBright LED lamps for indicationMaintains total electrical parametersEnhances the life of electrical equipment Required for IndustriesHospitalsMultistoried buildings

We present the exclusive range of APFC panel products to our customers. By providing international standards our products are fulfilling the needs of the global clients. We offer these products with their higher durability and industry competent prices.

• Application: Improvement of Power Factor
• Rated Insulation Voltage: 690 V
• Operational Current: 2500 A
• Operational Voltage: 433 V
• Temp. Rise: Upto 35°C rise over 50°C ambient
• Degree of Protection: IP 65
• Configuration: Based on customer requirement

We are offering perfectly designed Automatic Power Factor Correction (APFC Panel) in seven color tank procedure that is skillfully manufactured by our experienced and knowledgeable workers. We provide APFC Panel to the clients as per their requirements. Besides, we also provide on time delivery of APFC Panel within scheduled time period.
