Cylindrical Bearing Dealers in Kolkata

SKF super-precision single row cylindrical roller bearings in the N 10 series (fig. 1) have, as standard, a 1:12 tapered bore (designation suffix K). A tapered bore is preferred because the taper enables accurate adjustment of clearance or preload during mounting. The bearings have two integral flanges on the inner ring and no flanges on the outer ring. To improve lubricant flow, these bearings can be supplied with a lubrication hole in the outer ring on request

• Brand Name: FAG

FAG Cylindrical Roller Bearings with cage are units comprising solid inner and outer rings together with cylindrical roller and cage assemblies. The outer rings have rigid ribs on both sides or are without ribs, the inner rings have one or two rigid ribs or are designed without ribs. The cage prevents the cylindrical rollers coming into contact with each other during rolling. The cylindrical roller bearings are very rigid, can support high radial loads and, due to the cage, are suitable for higher speeds than the full complement designs. Bearings with suffix E have a larger roller set and are thus designed for extremely high load carrying capacity. The bearings can be taken apart and can therefore be fitted and dismantled more easily. Both bearing rings can therefore have an interference fit. Single row cylindrical roller bearings with cage are available as non-locating, semi-locating and locating bearings.

• Number of Row: Single Row
• Packaging Type: Box
• Material: Chrome Steel
• Brand Name: NACHI
• Outer Diameter (mm): 75 mm
• Width: 20 mm

• Type: Roller Bearings
• Condition: New
• Packaging Type: Wooden Crates
• Bearing Number: N224, N226, N317, N318, N319, N320, NJ220, NJ222, NJ224, NJ226, NJ228, NJ230, NJ318, NJ319, NJ320
• Product NJ320, NJ322, NJ324, NJ2317, NJ2319: NU221, NU222, NU224, NU226, NU228, NU230, NU317, NU318, NU319, NU320, NU322, NU324,NU326, NU330, NU417, NU2216, NU2217, NU2218, NU2220, NU2222, NU2224, NU2226

Radial Load Cylindrical Roller Bearings work in linear contact with the raceways and have high radial load capacity. Bearing House is offering popular brands of quality Radial Load Cylindrical Roller Bearings. Our product range, is also ideal for use in high speeds, comes with the outer and inner rings that are separable except for those with complete design. Moreover, the diverse design of our cylindrical roller bearings are changed by the lip arrangement.

• Features: Compact size , Fine quality , Corrosion resistant
• Item Code: VKT-8010-NJ-310

SKF cylindrical roller bearings are available in many designs, series and sizes. The majority are single row bearings with a cage. High-capacity bearings, double row bearings, multi-row bearings, single and double row full complement bearings (without a cage) and split bearings complete the SKF standard assortment provided here.

• Number of Row: Single Row
• Shape: Round
• Bore Size: 15 - 250 mm
• Material: Stainless Steel
• Features: Optimum performance, Rugged design, Facilitate easy handling
• Packing Type: Box

SKF cylindrical roller bearings are available in many designs, series and sizes. The majority are single row bearings with a cage. High-capacity bearings, double row bearings, multi-row bearings, single, double and multi-row full complement bearings (without a cage) and split bearings complete the SKF standard assortment provided here. Bearings with a cage can accommodate heavy radial loads, rapid accelerations and high speeds. Full complement bearings incorporate a maximum number of rollers and are therefore suitable for very heavy radial loads at moderate speeds. SKF high-capacity cylindrical roller bearings combine the high load carrying capacity of a full complement bearing with the high speed capability of a bearing with a cage. The factors that influence SKF cylindrical roller bearing performance and service life include but are not limited to the following:

We are amongst the top exporter, trader, importer & supplier of Rollway Cylindrical Roller Bearings. They are light in weight and are available in all the models in standard forms. They are reliable in working. We carefully pack our range, so that they can reach the clients end in safe manner. Client’s needs and demands are kept in mind, while procuring these produces from the vendor’s end. Features:    * Light in weight    * Easy to carry    * All models are available

• Bearing Number: C124-C179
• Weight: 2.5k
• Material: Stainless Steel
• Corrosion Resistance: Yes
• Type of Bearing: Cylindrical Roller Bearing
• Dimension: 100mm
• Usage/Application: Industrial machinery and automobile industry
• Brand: NSK
• Pack Type: Box

Single-row cylindrical roller bearings are of separable construction. The ring with flanges is assembled with the cage and the rollers. During mounting, the rings are to be fixed on to their respective seats – Inner ring on the shaft and outer ring on to the housing and then they have to be put together carefully. Depending on the ring-roller-cage configuration either on the inner ring or the outer ring, the bearing series are designated as NU and N. Series NJ and NUP are variants of the NU design – denoting whether the separable inner ring has one flange (NJ) or one flange and truncated inner ring with a separable guide flange fixed on the other side of the flange so as to keep the width of the inner ring assembly same as that of the outer ring (NUP). They are manufactured in multiple series. The bearings feature high rigidity, low friction, an ability to transmit high radial loads and are suitable for high rpm. N or NU series bearings should not be exposed to axial loads. Nj series bearings can carry limited axial load in only one direction, whereas NUP series series of bearings can carry limited axial loads in both the directions. The bearings are supplied with standard clearance and normal accuracy. However, bearings with lower or higher radial clearances as well as higher running accuracy can also be supplied. The bearings in the N design – the inner ring has two pilot flanges, the outer ring is without the pilot flanges. Axial displacement of the shaft towards the element (body) is possible in both directions.

• Usage: Industrial
• Features: Easy to use, Easy installation, Variety of sizes

This roller bearing completely complements cylindrical roller bearings and incorporates maximum number of rib guided cylindrical rollers. These can therefore lift up hefty radial loads; only drawback being their inability to operate at same high-speed as caged designs cylindrical roller bearings. The standard FKL range of single row also complements the semi-locating cylindrical roller bearings.
