Steel Prop Dealers in Kolkata

• Outer Diameter: 60.30 mm
• Inner Diameter: 48.30 mm

We are offering Adjustable Steel Props in which Steel Tubes are used for inner and outer of props. These props are known for their durability, high performance and wide functionality. We also offer customized products in this variety, and can manufacture them as per the requirements of the clients.

(Heavy Duty) Height-M Safe Axial Load-Kg. Prop Closed Extended Closed Extended 0P 1P 2P 3P 4P 1.10 m 1.50 m 2.00 m 2.00 m 3.00 m 1.75 m 2.75 m 3.25 m 3.75 m 4.65 m 3500 kgs. 3200 kgs. 3000 kgs. 2900 kgs. 2300 kgs. 3000 kgs. 2300 kgs. 2200 kgs. 2000 kgs. 1150 kgs. Note : Props must be braced in both directions by tubes and right angle Couplers at approximately 250 mm above Prop Nut when extended beyond 3.6 metres.

• Length: 1500-3000mm
• Brand Name: KOSC
• Shape: Round
• Material: Steel
• Usage/Application: Construction
• Diameter: 40 NB and 50 NB
• Surface Type: Color Galvanized
• Pipe Thickness: 1.6-3.0mm

Outter member made from 60.3mm od & inner member made from 48.3mm od m.s. pipes . Junior props are made from 50.8mm od & 44.4mm od m.s. pipes. Provided with nut with self cleaning notch.

Adjustable Steel Props also known as telescope steel props are the most economic, ideal and vary commonly used supporting device for all kinds of form work, slabs, beams, wall and columns.
