PCB Connector Dealers in Meerut

TNC (F) BH for Rg 58 Specifications Electrical Characteristics Impedance 50 O Frequency Range 0 - 11 GHz Voltage Rating 500 volts peak Dielectric Withstanding Voltage 1,500 volts rms VSWR M39012 straight connectors: 1.3 max @ 0 - 11 GHzM39012 right angle connectors: 1.35 max @ 0 - 11 GHz Contact Resistance Center: contact 1.5 moouter contact: 0.2 mo Braid to Body 0.1 mo RF Leakage -60 dB minimum @ 3 GHz Insertion Loss 0.18 dB @ 9 GHz Insulation Resistance = 5,000 MO Impedance 50 O Mechanical Characteristics Mating 716 threaded coupling BraidJacket Cable Affixment Crimps: hex braid crimp Clamps: screw-thread nut and braid clamp Center Conductor Cable Affixment Crimps: crimp or solder All others: solder only Captivated Contact All crimps unless specified otherwise Cable Retention Crimps: 20 - 100 lbs Clamps: 20 - 50 lbs Mating 716 threaded coupling Material Male Center Contacts Brass, silver or gold plated Female Center Contact Beryllium copper or phosphorous bronze, silver or gold plated Other Metal Parts Brass with nickel finish (except for M39012 which are silver) Insulators TFE, Delrin Clamp Gaskets Synthetic rubber, silicone rubber Environmental Temperature Range -65°C to +165°C Weatherproof Clamps with clamp gaskets, Crimps with heat-shrink tubing Hermetic Seals Pass helium leak test of 2x10-8 ccsec Shock MIL-STD-202, method 202
