Bead Mills Dealers in Mumbai

• Power:  220V/50Hz
• Weight:  50Kg
• Grinding Chamber: Designed Volume: 400ml Effective Volume: 200ml
• Inner Chamber material:High wear resistant hard alloy 9CrMo18: Outer Materia: SS304
• Grinding pin and rotor material:High wear resistant hard alloy 9CrMo18: Cooling Mode: Cooling water passing through gridning chamber
• Mechanical Sealing: Self design mechanical seal. Sealing Support : SS304
• Dispersion & Grinding: ROOT patented turbine and pin type rotor. Dispersing linear speed：10.2 m/sec
• Separating mode: Dynamic separation; no stuck and high efficiency
• Grinding Media: 95% zirconia beads Zirconia beads spec : Dia 0.4 mm- Dia 1.4mm Filling quantity recommended：50% ᷉ 90%
• Dimension: 540(L)x 190(W)x240(H)mm

• Finishing: Polished
• Machine Weight: 900-1000kg
• Pressure: Low Pressure
• Usage: Paint Industry
• Specialities: Excellent Functionality, Less Maintenance, Ruggedly Constructed, Durable, Easy To Use
• Type: Bead Mill
• Brand Name: Nirlaxson
• Material: Stainless Steel
• Voltage: 440V
• Condition: New
• Power: 3-6kw
• Driven Type: Electric
• Phase: Three Phase
• Warranty: 1 Year
• Country of Origin: India
• Corrosion Resistance: Yes
• Machine Structure: Vertical
• Operating Type: Manual
• VOL. IN LITRES: 50 LTR to 200 LTR
• INNER SHELL: SS304 / SS316
• OUTER SHELL: SS / MS
• SHAFT: SS304 / SS31
• RPM: 950 RPM
• NO. OF DISC: 1 NO.
• DISC MOC: NYLON / TEFLONE

• Country of Origin: India
• Type: Horizontal Bead Mill
• Certification: ISO 9001:2008
• Application: Grinding Use
• Voltage: 220V, 380V, 440V
• Automatic Grade: Automatic
• Driven Type: Electric
• Warranty: 1yrs

This Series Of Bead Mills Are Efficient Ultra Micro Wet Grinding And Dispersing Machines In Common Use, And They Are Widely Used For Producing Coating, Dyestuff, Paint, Ink, Medicine, Magnetic Powder, Sensitive Film, Pesticide, Cosmetics And Paper Making, And So On. We Use Advantages Of The Same Kind Of Mill In Our Country On These Mills. So These Mills Have High Efficiency, And Can Work Continuously And Have Less Pollution, Its Self-Control Is Dependable. Its Cost Is Low. Its Appearance Is Nice. The Maintenance Is Convenient. Especially These Mills Are Very Practically Useful.

• Type: Paint Making Machine
• Brand Name: Hallmark
• Certification: TPI
• Color: Blue
• Voltage: 440
• Condition: New
• Warranty: 12 Months
• After-Sales Service Provided: Yes
• Product Type: Micronising
• Place of Origin: India

• diameter range: 0.5-3.0 mm

The optimum configuration for every poduct with an extremely wide choice of material for parts wetted choice of materials for parts wetted by the product including hardened and stainless steel, hard chrome-plated stainless steel, polyurethane and engineered cermics, Easy to use- all type of mill can be taken apart in just a few steps, allowing simple and rapid changover to different mill confirguration.

The Bead Mill provided by us is used for reducing the sizes of different kinds of particles. The Bead Mill offered by us is fabricated under the strict supervision of the experts for maintaining the level of quality in it. Besides, the Bead Mill is offered at market’s leading prices.

Batch Type Bead Mill has all contact parts made out of 304 quality Stainless steel. The cabinet is totally enclosed in a M.S. Frame giving steam-line appearance and comprises of the following: Main motor for driving the S.S. Shaft complete with 'V' belts. One S.S. Shaft with impellers made of S.S. 304 quality duly hardened for longer service. The above drive is provided with imported self aligned bearings to withstand high speed and initial torque of the mill. The grinding chamber is provided with a cooling jacket in MS construction provided with inlet and outlet nozzle.

Bead bills reduce particles to sub micron size. Consisting of a cylindrical vessel that contains a motor-driven central shaft, which is equipped with impellers of different types. Bead mill comes with an enclosed vessel. While operating this enclosed vessel is filled with grinding media, agitator shaft activates media, creating shearing and strong forces. Rotation of agitator imparts energy to surrounding media. Forces either fracture, tear, or crush particulate. It can be operated continuously since it is equipped with devices, which retain the beads within the milling chamber. Then the final product is evenly dispersed in liquid.
