Cable Switch Dealers in Mumbai

• Our Model No: CBF-LS
• Cable Range: 3 meters
• Cable material: neoprene
• Cable specification: 9 mm / 3 x 1.5 mm2
• Contact type: NO / C /NC
• Maximum load: 10 A – 250 VAC
• Contact life       : 10 million switches
• Switch angle: + - 45 deg
• Switching speed: max 600 / min
• Process temp: Upto 50’C
• Process pressure: Max – 0.1 mpa
• Liquid density: min – 0.8 g / cm 3
• Housing material: non – toxic polypropylene
• Protection: IP 68

A change in liquid level causes the float to tilt up or down and in the process move the steel ball to operate the micro switch plunger to close or open an electric circuit, which in turn operates auxiliary devices like alarm, solenoid valve, pump etc.

We are enlisted among the established Manufacturers, Suppliers and Exporters of Cable Float Level Switches from Maharashtra. The Cable Float Level Switches we make available are manufactured in compliance with set industrial norms. We maintain a large stock of the Float Level Switches, to cater the bulk and urgent requirements of the buyers. The entire range of the Float Level Switches is reasonably priced by us.

SIGMA's Cable Float Switch (Tilt Type) has a double chamber construction to make it absolutely hermetic. Switch differential is set with the help of a counter weight that can be adjusted alongside the cable of the switch. Its non-toxic body materials and mercury-free operated micro switch enable its use in drinking water applications.

Model No.: JB/CFS/401 Features• Low cost polypropylene level switch • Hermetically moulded, double chamber • Mercury free operated micro switch• Direct pump control up to 1.1 kW • Adjustable switch differential • Low specific weight of the floating bodyAPPLICATIONS• Level switch from drinking water to sewage• Pump protection in small pipes • Fail-safe indication and pump controlSPECIFICATIONSSwitch rating: 250V AC, 15 A Temperature: 0 °C to 80 °C Pressure: max. 2 bar Protection: IP 68

• micro switch: 1 Lac Operations
• 250 VAC: 10 Amp at 230 VAC Res
• 15 Amp at 230 VAC: 2 Bar
• 70 degrees C.: 5 Mtrs (Max. 20 Mtrs)
• Polypropylene (PP): PVC

Cable float switch is a control device for filling and discharging pumps, motor and magnetic valves. It is also an alarm device at certain pre-determined surface levels. It is suitable for use in non-flammable liquids at 250 volts. In dangerous enviroments (e.g. wells and pumping stations) we recommend 24 V voltage. In potentially explosive atmospheres (e.g. oil tanks) the Switch can be used in conjunction with (Ex) i-isolator switch units. Due to its large float casing the float Switch has a buoyancy which guarantees smooth, trouble-free operation under all conditions. The switch has double chamber and a final remoulding finish to make it absolutely hermetic. INSTALLATION : Cable Float Switch is simply placed in the liquid so that the float follows the movement of the surface. The switching height differential is adjusted by moving the weight along the cable. The differential is minimum, when weight is nearest to the float. If the viscosity of the liquid is high, we recommend an extra weight on the cable.

• Rated Current: 10 Amp at 230 VAC Res
• Voltage: 250 VAC
• Switching element: micro switch
• Life of Switch: 1 Lac Operations
• Optional: 15 Amp at 230 VAC
• Pressure rating: 2 Bar
• Heat rating: 70 degrees C.
• Standard Cable length: 5 Mtrs (Max. 20 Mtrs)
• Float material: Polypropylene (PP)
• Cable insulation: PVC
• Protection: IP 68

• Voltage: 250 VAC
• Switching element: : Micro Switch
• Life of Switch: 1,00,000 Operations

It is also an alarm device at certain pre-determined surface levels. It is suitable for use in non-flammable liquids at 250 volts. In dangerous enviroments (e.g. wells and pumping stations) we recommend 24 V voltage. In potentially explosive atmospheres (e.g. oil tanks) the Switch can be used in conjunction with (Ex) i-isolator switch units. Due to its large float casing the float Switch has a buoyancy which guarantees smooth, trouble-free operation under all conditions. The switch has double chamber and a final remoulding finish to make it absolutely hermetic.

This low-cost switch is used for a variety of applications such as control of submersible pumps. This can be used in fresh water , sea water, sewerage and industrial effluents.

We present the finest quality of Cable Float Level Switch in the national as well as international market. Our Float Type Liquid Level Switch is highly durable in nature and genuine in performance. These cable float level switches are commonly used in chemical, marine test instrument, food machinery, warmer machinery etc. Besides, we are one of the most reputed Float Level Switch Manufacturers in the market. Model No.: MI-017 Cable Float Level Switch

Cable Float Level Switch, Digidial Temprature Indicator Controller
