Current Transformers Dealers in Andheri, Mumbai

We manufacture Tape Insulated Bar Primary CTs ( Ring & Rectangular Type) which are generally prefered because they are simple in construction, mechanically stronger, economical and easy to connect in existing switchgear. They are used in control panels and generator panels(Metering , protection and special protection ps class).they are available in round or rectangular window and suitable for a wide range of electrical test equipment. SPECIFICATIONS :Primary Current : 50A to 6000ASecondary Current : 5,1,5/rt3 and 1/rt3 AAccuracy Class : For Metering CTs : 0.5 to 5AFor Protection CTs : 5P,10P accuracy limit factor 5,10,15,20Burden : 1.25 VA to 60 VAMounting :M.S. clamp if required. The Standard Tape Wound Type CT'S is manufactured using high quality material to offer high performance and quality. It is durable and is mainly used as a measuring device for metering and protection system in various industries. In addition, it is verified on various parameters to match the prevailing quality standards.

Energy meter CT’s made using hybrid cores are DC immune current transformers for energy meters meeting IS 13779 / IEC 62053. The CT is small in size with customized casing and metal shield, (optional) for protection against external magnetic field. The wound CT is epoxy potted for durable and long life performance. Number of turns can be wound/adjusted as per customer requirements. CTs can be provided with or without metal shield in custom casings.

Ring current transformer, variable voltage transformers

• Color: Black, Orange, Blue, Grey
• Usage: Industrial Use
• Rated Voltage: 0-110 V, 110-220, 220-440 V
• Driven Type: Electrical
• Packaging Type: Box, Carton
• Condition: New, Used
• Feature: Proper Working, Easy To Install, Rust-resistant

We are offering current transformers. The basic application of current transformers are: lowering the very high primary current passing through bus bars, cables, or wires to 5a or 1a, a measurable quantity by measuring instruments. isolating the measuring instrument and protective devices from mains. reproducing proportionate primary current on its secondary side, as required for extending the range of the instruments.

  All types of LT CT's as per IS:2705, IS:6949, BS:3938, IEC 185 or customers      specification for any current upto 10000 AMPS

A current transformer (CT) is used for measurement of alternating electric current. Current transformers, together with voltage (or potential) transformers (VT or PT), are known as instrument transformers. When current in a circuit is too high to apply directly to measuring instruments, a current transformer produces a reduced current accurately proportional to the current in the circuit, which can be conveniently connected to measuring and recording instruments. A current transformer isolates the measuring instruments from what may be very high voltage in the monitored circuit. Current transformers are commonly used in metering and protective relays in the electrical power industry. Application Measuring purposes (the CT lowers the current to be suitable for metering instrument) or, Protection of the power circuit (input current for protection relays).

• Core Type: SPCT
• Country of Origin: Made in India
• Rated Primary Rating: 30A to 4000A
• Rated Secondary Output: 5A
• Rated Burden: 1VA to 15VA
• Class of Accuracy: 0.5 to 5

Current Transformer, Fully Automatic Capacitance, industrial testing kit

ring type current transformers, Instrument Transformers

Current Transformer, Din Rail Timer, Power Supply, Solid State Buzzer

Current Transformers, Transformer, Lt Transformer

Current Transformers, Transformers

auxiliary current transformers, Voltage Transformers

Current Transformers, Digital Panel Meters, multi function meters

Current Transformers, Magnetic Cores and Shields, DC Shunts

Current Transformer, Potential Transformer, Power Transformer
