DC Relays Dealers in Mumbai

• Country of Origin: India
• Color: Blue
• Condition: New
• Current Type: DC
• Mounting Type: Base Mounting
• Power Consumption: 2W-5W

Offered By Us is dc Earth Leakage Relay that Works By Measuring Differential Current Between Both the –ve and +ve Current Carrying Conductors. the Dc Earth Leakage Relay Provided By Us is Supplied to Far Flung Areas of the World Through the Wide Spread Network of the Company. used For localizing and Detecting Earth Leakages in Dc Power Systems specifications sensor: back Panel Mountable with An Opening Provided for Passing the -ve and +ve Conductors Through. Size of Opening is 50 Mm Dia (smaller Dia Sensors are also Available )detectorsensing Range : + - 5 1020 Ma Selectable By Shorting Terminals On the Unit indication : +ve Leak, -ve Leaktime Delay : 10 Seconds for Turn On and Turn Offauxiliary Supply : 20 to 80 V, or 80 to 300 V Acdctrip Output : 1 Changeover Contact On Leakage Exceeding Set Valuecontact Rating 5 a 230v Ac 30 V Dcreset : auto or Manual Selectable By Shorting Terminals On the Unitmanual “reset “ Button Provided On the Unit dimensionssensor : 113mm X 30mm X 105mm ( 50mm Opening ), 87.5mm X 26mm X 81mm (20 Mm Opening )detector Unit : 70 Mm X 100 Mm X 110 Mmaccessories : cable Between Detector and Sensor of 2 Metre Length

• Front Bezel: 152 x 92 mm
• Cut Out: 132 x 72 mm

This type of relay is used to supervise the DC supply. The relay coil terminals 1 & 2 are connected to the DC supply, which is to be monitored. In case, the DC auxiliary supply is available, the relay’s ‘NO’ contact closes and healthy status is indicated through ‘WHITE’ flag. In the absence of the DC auxiliary supply, the same is indicated through ‘RED’ flag.
