Delta Temperature Controller Dealers in Mumbai

Digital Temperature Controller heat or cold generators (with manual and programmable automatic defrosting).Temperature display and adjustment. All purpose temperature controller. Front panel functions :- Relay ON Indicator. Defrost Indicator Alarm Indicator Timer Indicator Keypad Lock Indicator

• Power: 230V AC ± 15%, 50/60 Hz
• Size: 96 x 96 x 110mm, 48 x 96 x 150mm

Digital temperature controller, The Dimension are 96 X 96 X 150mm. Other related products manufactured are Potentiometric type controllers withwithout deviation indicator, Portable and Mains operated temperature indicators.Display : 4.5 Digit, 12.5mm Red Led. Range : 100 0C to 1700 0C in various models Resolution : 0.1 0C or 1 0C Accuracy : Better than 0.25 % ± 1 digit Sensor : Suitable for RTD (pt100), thermocouple (Type J, K, R, S, T), solid state Sensors.

• Type: Temperature Controller, On/ Off And PID
• Application: Industrial
• Color: Black
• Feature: Durable, Stable Performance, High Accuracy
• Voltage: 110V, 220V
• Display Type: Digital
• Theory: Temperature Controller
• Frequency: 50Hz, 60Hz
• Driven Type: Electric, 24V
• Certificate: ISI Certified
• Current Type: AC
• Country of Origin: India
• Brand Name: Premier Electrosystems

1] Analog Temperature Controller (48 x 48) 2] Digital Temperature Controller (48 x 48, 72 x 72, 96 x 96) Digital Timer PID Temp. Controller Process Indicator Counter Programmable Logic Controllers Accessories

• Brand Name: West Control Solutions
• Model Name/Number: 6100+ & 8100+ & 4100+
• Enclosure: IP66
• Certifications: CE,UL,ULC,CSA
• Sampling Time: 4 per second,14 bit resolution approximately
• Output Type: Relay,SSd,DC linear V or mA,Triac,24V transmitter power supply
• Product Category: Single Loop Controller
• Dimensions and Size: 48mm x 48mm x 110mm (HxWxD),1/16 DIN; 96mm x 48mm x 100mm,1/8 DIN; 96mm x 96mm x 100mm,1/4 DIN
• Primary Input Type: Universal (TC,RTD,DC linear mA/mV)
• Other Inputs: Digital,Remote setpoint
• Max. Number of Outputs: 3
• Control Type: PID,ON/OFF,Manual,Alarm,Ramp to Setpoint
• Power Supply: 100-240V AC 50-60Hz,20-48V AC 50/60 Hz,22-65V DC
• Communicatons: RS-485 serial (West ASCII or MODBUS)
• Panel Sealing: IEC IP66,NEMA4X

we manufacture and supply high grade digital temperature controller. Our digital temperature controllers are designed to measure, display and control temperature of furnaces over wide range, with high accuracy. Different digital temperature controller sensors are used for the desired temperature control range. In our digital temperature controller, uses of proportional controller minimize overshoot and undershoot of the furnace. The measured temperature is displayed on a digital led display of our digital temperature controller. features of digital temperature controller automatic cold junction compensation (thermocouples)broken sensor indication & sensor linearizationusing dfg techniques are the standard features

• Brand Name: Autonics
• Weight: Approx. 150g
• Model No.: TK4S-B4CN
• Display: 4-digit 7-segment LED
• Control Method: ON/OFF control, P, PI, PD, PID control
• Sampling Duration: 50ms
• Control Output 1: Current(DC0/4-20mA) or SSR drive
• Option Input: CT, Digital(DI-1)
• Option Output: Alarm 1/2, RS485 comm.
• Power Supply: 100-240VAC
• Protection Structure: IP65(front panel)
• Hysteresis: RTD/Thermocouples: 1 to 100Deg.C variable Analog: 1 to 100-digit
• Proportional Band: 0.1 to 999.9Deg.C
• Integral Time: 0 to 9999 sec
• Derivative Duration: 0 to 9999 sec
• Control Period: Relay output, SSR drive output: 0.1 to 120.0 sec Current output or SSR drive output selectable: 1.0
• Manual Reset: 0.0 to 100.0%
• Ambient temperature: -10 to 50Deg.C, storage: -20 to 60Deg.C
• Ambient Humidity: 35 to 85% RH, storage: 35 to 85% RH
• Insulation Type: Double insulation or reinforced insulation

• Brand Name: PPC
• Driven Type: Electric
• Current Type: AC
• Color: Black
• Condition: New
• Power: 220V
• Application: Industrial
• Size: 72(w)* 72(h)* 110 (d) Mm (cutout- 68*68mm) 48(w)* 96(h)* 110 (d) Mm (cutout- 46*92mm) 96(w)* 96(h)* 110 (d)mm (cutout - 92*92 Mm)
• Model Number: ppc-dtc
• Feature: High Performance
• Voltage: 230
• Display Type: Digital
• Type: Digital Temperature Controller, FE-CON(J) / CR-AL (K) / PT-100 (RTD)
• Weight: .200-400gm
• Theory: Temperature Controller
• Frequency: 50Hz
• Temperature Range: 0-400C
• Resolution: 1
• Accuracy: 1
• Country of Origin: India
• RANGE: 0 -60.0/100/250/400/600/1200 degree centigrade,
• OUTPUT: TIME PROPORTIONAL / ON-OFF - RELAY- 6A/10A ( 1C/O) / SSR
• SETTING: POTENTIOMETRIC SETTING (PUSH TO SET ),
• DISPLAY: 3 ½ DIGIT, 7 SEGMENT DISPLAY,
• POWER SUPPLY: 230 VAC / 50 HZ

• Type: Digital Temperature Controller
• Application: Industrial
• Weight: 400-800gm
• Color: Black
• Feature: Auto Controller, High Performance, Stable Performance
• Condition: New
• Display Type: Digital
• Theory: Temperature Controller
• Frequency: 50Hz

setpoint and process both are displayed simultaneously. the process display is 12.5mm height. the setpoint display is 8mm height. the power supply is 90-260 vac. notes 1. on-off control: relay is on upto the set temperature and cuts off at the set point. system temperature will come down and again relay will go on at temperature 2 °c below the set point. same function is repeated. adjustable dead band is provided for specific application. time-proportionating control : relay will be on and off in band of ±2 °c of set-point. on-off : time will adjust as per the heat requirement of the system. of course total time cycle will be of 15 seconds. 2. 4½ digit temperature indicator/controller nippon 2020a. 3. contact factory for supply volts of 90 - 260 vac & retransmission output     principle  :  input signal is signal conditioned, linearised and amplified.  it is compared with the set point and accordingly relay operates.   inputs  :  j,k,r,s,t and other thermocouples, r.t.d's like pt-50, pt-100 (2~3 wire), 0-1vdc, 4-20 ma... etc. range, indicating  : refer table - a accuracy, resolution ambient compensation: automatic  setting  : by push button - coarse/fine pots or by membrane key - trimpot setting accuracy : better than 0.2% output  : relay contacts rated at 230v/6a. control  : on-off or time-proportional (refer note on back side)  sensor open protection: built-in indicates ' 1', relay cuts-off.  ambient temperature:  0-55 °c supply :  230 vac ±10%, 50 hz standard, 90-260 vac on request. box size  :  96 (h) x 96 (w) x 180 (d) or  72 (h) x 72 (w) x 110 (d) or  48 (h) x 48 (w) x 100 (d) in mm note : 24 vdc for loop power 4-20 ma input on re

• Color: Black/ Grey
• Usage: Industrial
• Name: PID Controller

Input: J, K, R, S, T, RTD Control Action: On Off PID Control Logic: Heat/ Cool Auto tune: Yes Power Supply: 230 V AC +/- 10%

• Size: 48 x 48 mm
• Control Type: PID/On-Off
• Brand Name: Sub Zero
• Accuracy: +/- 0.5% FS
• Display Type: 4 Digit/7 Segment
• Mounting Type: Panel
• Voltage: 230 VAC
• Frequency: 50/60 Hz
• Model No.: PT244-T
• Input Type: Thermocouple, RTD
• Control output Type: Relay/SSR
• Resolution: 1 Degree C

Libratherm̢۪s new ECO - MODEL series 480, 720 & 960 of Digital Temperature Indicator / Controllers available in ABS enclosure are low cost, accurate, rugged and reliable instruments suitable for general purpose temperature measuring and controlling applications. It accepts thermocouple or RTD as the sensing input and provides Relay / Solid State Relay control output for controlling the electrical or fuel fired heating or cooling system. The range covers simple Temperature Indicator, Single and dual set point ON/OFF or Time proportional Controllers. ApplicationFurnace / Oven / Refrigeration control Heat treatment Environmental chambers Plastic / Packaging industry Cold Storage and Chilling plants Laboratory equipment ..etc. Special model available for Infra red heaters.Optionally AvailableModel with dual input and dual set point Model with dual display to indicate PV & SVSimultaneously with single and dual set point control

• Brand Name: Omron
• Size: 72 x 72 mm
• Control Type: On-Off
• Display Type: 3 Digit/7 Segment
• Mounting Type: DIN Rail
• Voltage: 24 VAC/DC
• Frequency: 50/60 Hz
• Model No.: E5CWL Series

• Input: Thermal Couple K E J S
• Thermal Resistance:: Pt 100 Cu50

The XMT*3000 digital temperature controller can replace traditional display meter. It adopts three - positions keys to set freely and single 4 digit LED display. It has 2-on / off control , it is simple digital meter with control capability more reasonable . Range: K (0 to 1300 deg C); E (0 to 800 deg C)                               S (0 to 1600 deg C); J (0 to 1000 deg C)                                            Pt100 (-200.0 to 200.0; 0 to 600 deg C)                                Cu50(-150.0 to 150.0deg C) ·          Display: 4 digit LED display        OUT Indicator Light: When OUT is ON, a green LED light .        Set key (SET): Switches the setting mode and registers the                                     setting value and selected value .              Dec Key : Decreases numeric value of the setting value .               Inc Key : Increases numeric value of the setting value .  ·          Basic Error:  +/- 0.5 % +/- a dot of the total range of the input. ·          Control Output:  Relay contact   AC 250V    7A (impedance)  ·          Control Means: 2 - on / off control  ·          Power AC 220 V   (50/60 Hz )  ·          Work Environment: temperature 0 - 50 deg C, Humidity < 85 % RH, No corrode  ·          Size:  XMTG 48x48x90 mm   Hole 44x44

STIACK is a leading supplier runner temperature controls. Economical and full featured for challenging moulding applications. Available from 1 – 24 zones

PID Soft Start controllers are especially designed for hot runner coil heaters and tubular heaters. It is very efficient and economical. Multi zone hot runner controllers are made by individual temperature controller modules assembled in a cabinet. Soft start facility in this controller will help evaporate any moisture present inside the heater. The coil heaters have MgO content, and are therefore hygroscopic in nature. If kept unused for long periods, there is moisture deposition on the terminals. So we recommend de-moisturizing the heaters by preheating at 100° C to 120°C using controllers with soft start functions.

• Brand Name: DIXELL
• Display Type: Digital
• Model: XR02CX

• Size: 96 X 96 Mm
• Temperature Range: -200 DegreeC
• Brand Name: Delta
• Input Type: Thermocouple
