Double Sided PCB Dealers in Mumbai

• Max board size: 600 mm x 450mm
• Copper Thickness: 6 oz Cu

The double sided PTH PCB is the universal workhorse of the electronics industry. The complexity and density of components means much equipment has to use both sides of the Printed Circuit Board - and better products usually supplement this with plated-through-holes where the copper connections go right through the connecting holes to the opposite side of the board. These all the way through the board connections make double sided PTH PCB a much more physically robust item.

We offer Single & Double Sided PCBs. Most common PCBs for consumer and industrial electronics devices. Large volume single-sided which can be CEM or FR4 pierced and blanked with hard tools & double sided PTH RoutedScored.

• Brand Name: contec electronics
• Place of Origin: mumbai

The Double Sided Printed Circuit Boards that we offer are individual PCBs that are stepped up onto a bigger panel, tooled with fiducial marks to assist assembly and and are bridged (using break out pips) or scored so boards can be freed from the panel. It allows many PCBs to be manufactured at once and also means manyPCBs can be assembled together that reduces the process time. The entire gamut is manufactured using CEM1, CEM3, FR2, FR4, polyimide, RT duroid and PTFE. Double Sided Printed Circuit Board Features Hot air solder leveling (HASL) tin lead (Non RoHS-compliant) Electro less nickel Immersion Gold Immersion TIN Surface coatings About Double Sided Printed Circuit Board Various colors (white, black, yellow) Photo image able solder resist Green Red Blue Component notation (silkscreen legend) two pack epoxy
