Eco Engineering Co. Kurla, Mumbai, Maharashtra

AIL Forged Steel Y-pat tern Globe and Check Valves have established themselves in the industry for their rugged and compact design, and reliable service. These valves are of fered in Carbon Steel and Alloy Steel. They are available in a range of sizes starting from 14” to 2” (in reduced-bore design) and from 38” to 112” (in full-bore design). The rugged construction ensures an ideal body and bonnet, suited to handle high pressure and temperatures - up to 4250C in carbon steel and 5400C in alloy steel. The Y-pattern design ensures a near-perfect straight flow which significantly reduces pressure drop and turbulence when compared to conventional designs. As a standard, valves are supplied with screwed bodybonnet joint, which ensures ease of inspection and in-line maintenance, thus minimising downtime. AIL Y-pattern valves can be of fered to NACE MR-0175 and other special NACE requirements. They can also be supplied with IBR certification.

By virtue of their Y-type configuration, AIL Globe Valves have a relatively straight flow and a lower pressure drop compared to conventional globe valves. The valves are suitable for tight shutoff and throttling in high pressure and high temperature lines. Some of the unique features of AIL Y-Globe Valves are : Pressure Seal Bonnet Low operating torque due to use of thrust bearings Non-rotating stem Integrally-stellited body seats Fully-guided disc with Stellite seating and guiding surface Impactor handwheel in sizes of 6” (150mm) and above

We are one of the well-known Butterfly Valves manufacturers. We have a team of trained technocrats which has abundant experience in dealing with all sorts of industrial butterfly valves. Moreover, we are specialized in the manufacturing of different types of butterfly check valves.

The AIL Trunnion Mounted Ball Valve is the preferred choice of ball valve in higher sizes and pressure ratings, and in critical process applications requiring special capabilities. In this design, sealing takes place by allowing the seat to move towards the ball along the flow axis, which leads to lower operating torques over other types of valves. The valves have advanced design features such as a built-in cavity relief mechanism, compact internal trunnion holder, and intrinsic double block and bleed facility. The valves are of two-piece design, bolted at the body connection joint and with flanged or butt weld ends, and are available in both reduced bore and full bore designs.

We offer swing check valves.

Salient features Bolted body-bonnet design for valves up to Class 800. Valves with welded bonnet also available on request. Screwed with seal-welded body-bonnet design for valves of Class 1500. Bellows-sealed Gate and Globe valves available in class 800 Bolted body-bonnet joints provided with spiral-wound stainless steel gasket and graphite filler for maximum protection against leaks. Die-formed graphite inner packing rings and braided graphite end rings with Inconel wire reinforcement corrosion inhibitor. T-head stem-disc connection of gate valve fully meets strength requirements of API 602 and API 598 Rolled ACME thread on stem for smooth operation Tapered shoulder on the stem for back seating Self-aligning type gland assembly with stud-and-nut tightening Integral hard-faced body seat for globe and check Spring-loaded disc on check valves suitable for nonhorizontal applications too Gate and globe valves can be of fered with electrical actuators Austenitic SS forging for body and bonnet of Cryogenic valves, resulting in excellent impact strength, minimal loss and resistance to corrosion Valves can be of fered to NACE MR-0175 and other NACE requirements Valves can be supplied with IBR certification

We are one of the well-known Butterfly Valves manufacturers. We have a team of trained technocrats which has abundant experience in dealing with all sorts of industrial butterfly valves. Moreover, we are specialized in the manufacturing of different types of butterfly check valves.

We offer Stainless Steel Gate Valves 300.

The API 603 family of AIL Stainless Steel Gate Valves is an economic alternative to API 600 Stainless Steel Gate Valves. They are available in flanged construction and in pressure ratings of ASME Class 150 and Class 300. Gate Valves are of flexible outside screw-andyoke and bolted-bonnet construction. Body and Bonnet The body and bonnet are cast with uniform section and generous radius fillets to prevent stress concentration. The castings are precision-machined for high performance Flexible Wedge. The gate valve body has a straight through port without recesses except at the seat area. This ensures minimum turbulence, erosion and resistance to flow. Long integral guide ribs in the body match with full-length guide slots in the wedge fo accurate alignment and guidance.

Different types of Stainless Steel Flanges can be easily purchased under single roof named as Eco Engg. We strictly use up-to-date equipments in the entire manufacturing process. We do not compromise with the superior quality of our products.

AIL Pneumatic Actuators are among the widely used actuators today and are in service in diverse industries such as pharmaceutical, chemical, petrochemical, food and nuclear power. Compactness, reliability, low maintenance needs and ruggedness combine to make these actuators the best choice for use with ball valves.

AW44 - Energymiser This valve is specially designed for on/off steam applications and conserves energy by providing bubble-tight sealing in steam services. The valves are IBR certified.

We are one of the well-known Butterfly Valves manufacturers. We have a team of trained technocrats which has abundant experience in dealing with all sorts of industrial butterfly valves. Moreover, we are specialized in the manufacturing of different types of butterfly check valves.

AF51 & 52 - Fire Safe Series These single-piece Ball Valves are high performance valves which come with a one-piece integrally flanged body, in sizes of up to 200mm. This design offers the unique advantage of eliminating the possibility of external leakage to the atmosphere through bolted body joints. These environment-friendly and highintegrity valves are preferred in critical applications where the media is expensive, volatile or toxic, and where external leakage or wastage is unacceptable.

AF44 - Fire Safe Series This 3-piece fire-safe design Ball Valve features a secondary metal seat which renders the valve firesafe. When the seat is totally sublimated in a fire, the ball moves and rests against the lip, forming a metalto-metal seat, thus ensuring leak-tightness.

A44 - Standard Series This 3-piece Ball Valve is the most easily on-line maintainable in its class. By removing three body connector bolts and loosening the fourth, the body can be swung away using the fourth bolt as the fulcrum, to carry out any installation or maintenance operation on the valve, thus reducing downtime. This valve can be offered in a wide variety of body and seat combinations.

We are one of the famous tube fittings manufacturers and suppliers. All kind of Pipe & Tube Fittings can be easily obtained from us and they are available in different shapes and sizes. Our stainless steel pipe fittings are universally used in various industrial applications. We offer pipe fittings, tube fittings, stainless steel pipe fittings etc., at the most genuine price.

We are one of the famous tube fittings manufacturers and suppliers. All kind of Pipe & Tube Fittings can be easily obtained from us and they are available in different shapes and sizes. Our stainless steel pipe fittings are universally used in various industrial applications. We offer pipe fittings, tube fittings, stainless steel pipe fittings etc., at the most genuine price.

We are one of the famous tube fittings manufacturers and suppliers. All kind of Pipe & Tube Fittings can be easily obtained from us and they are available in different shapes and sizes. Our stainless steel pipe fittings are universally used in various industrial applications. We offer pipe fittings, tube fittings, stainless steel pipe fittings etc., at the most genuine price.

We are one of the famous tube fittings manufacturers and suppliers. All kind of Pipe & Tube Fittings can be easily obtained from us and they are available in different shapes and sizes. Our stainless steel pipe fittings are universally used in various industrial applications. We offer pipe fittings, tube fittings, stainless steel pipe fittings etc., at the most genuine price.

The AIL Series 5HP-44 Ball Valve has been specially developed to meet the industry�s requirement of a safe and reliable shut-off valve for high-pressure applications. This valve incorporates a number of product features like high-pressure seals, thicker flanges on the body connectors, high-tensile bolting, special acetal resin seats, high-strength stem and high-pressure integrity gland assembly.

The ASME B16.34 family of AIL Gate, Y-Globe and Swing Check Valves features a pressure seal bonnet design for high pressure services. These valves are extensively used in high pressure and high temperature steam, oil, gas, chemical and water applications in thermal power plants, fertiliser plants, petrochemical plants and refineries. The valves are available with butt-weld ends in pressure ratings of Classes 900, 1500 and 2500, and come in carbon steel and alloy steel construction.

AD13 - �T� Port Diverter Valve AD14 - �L� Port Diverter Valve AT13 - �T� Port Three-way Valve AT14 - �L� Port Three-way Valve The Diverter Valve is designed to divert media from the bottom inlet port to either of the two outlet ports. The Three-way Valve, also known as a Mixer Valve, permits use of any port as inlet. NOTE Available in screwed and socket-weld designs. For material specifications and general dimensions, refer to table on A44 series.

AIL Ball Valves can be supplied in a highly versatile range of body, seat and trim combinations to suit almost all types of services. Details of certain common materials of construction are furnished here. For a more exhaustive list of available materials and for guidance on body/ball/seat material combinations, refer to Ordering Information on rear cover. NOTE : Materials conforming to NACE standard, and for special services like Oxygen and Hydrogen can be supplied.
