Eddy Current Testers Dealers in Mumbai

• Brand Name: Institut Dr. Foerster GmbH & Co. KG, Germany
• Type of Testing Machines: Eddy Current Crack Detection Machine
• Model Name/Number: Circograph CI
• Operating Frequency: 30 kHz - 1 MHz
• Test material: Ferromagnetic, austenitic, and non-ferromagnetic material
• Max. throughput: 3 m/s during continuous testing
• Defect Display: From 0.030 Mm At Ro 20 / Ro 35
• Sensor system: Rotating sensor system with a maximum of two (Ro 20 and Ro 35) opposite test heads

Compact test system for longitudinal surface defects The CIRCOGRAPH CI combines a compact design with intuitive operation in one high-precision rotating test system. The CIRCOGRAPH CI features a user-friendly operation unit as well as easy "Turn-and-Push" rotary switch. The 2-channel system can be adjusted optimally to suit your test tasks thanks to a large range of different rotating heads. Longitudinal defects in the material surface can thus be detected from depths as low as 30 µm.   Your advantages at a glance: Compact design Simple operation thanks to integrated operation unit and "turn-push" operation Universal testing system, can be adapted to individual applications and requirements 2-channel test system Seamless, continuous testing Defect depth resolution from 30 µm
