Electronic Lab Trainer Dealers in Mumbai

• Brand Name: TAGLab

We are offering basic electronics trainer. Study diodes ( si / ge / fast switching ), transistors ( cb, ce, cc for different npn & pnp transistor ), fet, ujt, mosfet, scr, diac, traic, ldr, zener diodes, led's study of resistors, capacitors, inductors, potentiometers, output transformer, speaker & relay basic theorems & laws such as resistors / capacitors / inductors in series / parallel combinations ohm's laws, kirchoff's voltage law, kirchoff's current law rc, rl & rlc series & parallel resonance circuits, filters ( lp, hp, bp, br ) clipping, clamping, half wave, full wave & bridge rectifier circuits voltage regulators circuits using zener diodes & transistors; digital gates using diodes & transistors transistor, power, audio, differential & feedback amplifiers ( current series / shunt ) oscillators such as phase shift, astable, monostable, bistable & schmitt trigger.

• Features: User-friendly operation, Compact design ,Longer serving life
• Application: Laboratory
• Model Number: 8531
• Type: Analog
• Material: Metal
• Automation Grade: Manual
• Color: BLACK
• Power Supply: 230V
• Country of Origin: Made in India
• Duty Cycle: 20 to 70% at 50Hz approximately.
• Type of Chopper: Jones Chopper.
• D.C. Source: 24V DC (Unregulated).
• Trigger Circuit: 1. UJT Trigger Circuit with variable trigger frequency to trigger the Main SCR.
• Commutation: Class “D” Type.
• Output Voltage: 5V to 20V approximately (variable).
• Output Frequency: 30V to 100Hz approximately.
• Controls: 1] Mains ON / OFF.
• Test Points: Multicoloured Test Points are provided at various stages in the circuit to observe the waveforms and voltages.
• Indicator: Mains ON / OFF.
• Experiments: 1] Study of SCR Trigger Circuit for a Jones Chopper.
• Standard Accessories: Detailed Instruction Manual.

• Usage/Application: Industrial
• Phase: Single Phase
• Automation Grade: Automatic
• Frequency: 50 Hz
• Material: MS
• Packaging Type: Box
