Expanded Metal Machine Dealers in Mumbai

Expanded Metal Machine

Get Price Quote

Expanded Metal manufactured by slitting and stretching the material in one motion leaving a diamond shaped opening. It is widely used where rigidity, strength, light weight, & free passage of light & air is required. Used in Reinforcing material in Constructions, Air or Liquid Intake Screens, Architectural Designs etc .It is avalable in piece and varied size with choice of meshstrandgaugesheet or thickness. It is also used in High Tension Power & Oil RigsWalkways, Boiler, Machinery Plate,Form, Chemical Industry, Bridges, Staircases, Racks,Partitionetc.

Expanded Metal Machine

Get Price Quote

• Shipping Volume (m3): 9.25,12.10,30.00
• Overall Dimensions (m): 2.8 x 1.5 x 2.2,3.0 x 1.75 x 2.3,5.0 x 2.0 x 3.0
• Thickness (mm): 0.3 - 0.9,0.9 - 2.0,1.25 - 2.5

The sheet is fed to the blades by means of rollers. A toothed upper blade cuts the sheet in conjunction with the straight stationary lower blade at right angle to the feed direction in such a way that a web of certain width remains standing which is stretched when the upper blade goes down. With the next stroke of the slide the cycle is repeated. The operation of Cutting - Stretching - Feeding is automatic.
