Fine Filters Pvt Ltd. LBS Marg, Mumbai, Maharashtra

Membrane filter, The Balston GS Series Membrane Filter Cartridges combine absolute membrane filtration down to 0.01 μm, with an integral pre-filter to protect the membrane. Ideally suited for high purity compressed air and gas requirements, these membrane cartridges are available in several housing configurations shown above. Use as a Final Filter for: Ultra-high purity gases Corrosive or toxic gases Cylinder gases Doping gases

Demister pads, Fine Filters" Compressed Air Gas Filters consist of a two-stage separation-cum-filtration process. Typical Applications include filtration of compressed Air N2 CO2 Cl2 Natural gasSO2NH3 etc. In the first stage, the airgas passes through a carefully positioned Demister Pad placed above the inlet nozzle. The Demister Pad is made of knitted St. Steel wire loops with symmetrical interlocks. Due to the high free volume and large impingement area, it has a very low pressure drop. As the airgas passes through the pad, the liquid droplets contact the large wire surface area and due to the greater inertia, they are held back. As more and more droplets collect, they coalesce and grow in size and then fall back in the drain sump due to gravity.

Ceramic filter, Fine Filters" Compressed Air Gas Filters consist of a two-stage separation-cum-filtration process. Typical Applications include filtration of compressed Air N2 CO2 Cl2 Natural gasSO2NH3 etc. In the first stage, the airgas passes through a carefully positioned Demister Pad placed above the inlet nozzle. The Demister Pad is made of knitted St. Steel wire loops with symmetrical interlocks. Due to the high free volume and large impingement area, it has a very low pressure drop. As the airgas passes through the pad, the liquid droplets contact the large wire surface area and due to the greater inertia, they are held back. As more and more droplets collect, they coalesce and grow in size and then fall back in the drain sump due to gravity. The airgas exiting out from the top of the Demister pad will contain traces of oil and moisture in mist form in the range of about 25-30 microns. In the next stage, the airgas enters the porous ceramic filter elements hanging above the Demister Pad.
