Float Switch Dealers in Mumbai

top mounted float operated suspended and tilting float switches   principle of operation   a pear shaped float weighted at its upper end is suspended inside  a vessel on the end of a flexible cable. as the liquid level rises the lower end of the float is supported by the fluid, the float tilts and operates a micro switch inside it (not a mercury switch)   material specification   customized suiting to the service (fluid) and temperature.available in ss 304/ ss 316/ pp/ pvdf

A change in liquid level causes the float to tilt up or down and in the process move the steel ball to operate the micro switch plunger to close or open an electric circuit, which in turn operates auxiliary devices like alarm, solenoid valve, pump etc.

  We have established ourselves as leading name in the field of Liquid Magnetic Float Level Switch in the market . Switching is achieved with the unique magnet system, giving snap-action latch-on switching. A switch mechanism is mounted inside the enclosure adjacent to the pressure tube. Vertical movement of the float magnet in the pressure tube simultaneously actuates the secondary and tertiary magnets in the switch mechanism to operate the contacts. Features: Snap-action Accurate mechanism Easy to maintain Other Details: Single, Bilevel and multilevel sensing with potential free contacts Float : SS-316/PU Foam/Poly propylene/BUNA-N Mounting : Flange, Threaded in MS / SS or TC joint Terminations: cable / DIN connectors / RTD head / weather proof or flame proof junction box Suitable upto 90 degree Applications: Scientific laboratory Research centres Chemical industries Technical Specifications: Float : S.S.316 or Teflon Coated or PP / PVDF/Monel Flange : Mini 1” NB to Any Size in C.S. or S.S.304 or S.S.316 or S.S. Lined C.S. Etc Reed Switch with Rhodium Contact SPST / SPDT . Rating : 0.5 Amp @ 240 VAC Switch Housing : Die Cast Aluminium, Weather Proof IP 65( Enclosure ) ( IS – 2147 )  Flame Proof to II A, II B ( IS – 2148 CMRSDhanbad Approved ) Operating Pressure : 10 Kg / Cm2Operating Temp : Maxi. 1000 C. Cable Entry : ½” NPT ( F ) OR ¾” ET ( F ) No of Switches : As Per Customer Requirement Stem Length : Up to 5 Meters

• Media Type: Liquid
• Mounting Options: Side Mount, Bottom Mount
• Power: 10-15Amp
• Body: Metal
• Features: Easy installation, Long functional life
• Range: Upto 2 Meters Max.
• Finishing: Polished

• Material: Stainless Steel
• Pole And Throw Specification: SPST
• Material: Stainless Steel
• Media Type: Liquid
• Mounting Options: Top Mount, Bottom Mount
• Process Temperature: 120
• DC Voltage: 24 VDC
• Accuracy: 0.5 %

• Mounting Options: Top Mount
• Media Type: Liquid
• Material: SS
• Pole And Throw Specification: SPST
• Brand Name: D B Instruments
• Country of Origin: Made in India
• Item Code: VMT-16-3-TC-AH
• Switching Voltage: 300 VAC / DC
• Switch Rating: 100 VA
• Maximum Working Pressure: 10 kg/cm2

• Our Model No: CBF-LS
• Cable Range: 3 meters
• Cable material: neoprene
• Cable specification: 9 mm / 3 x 1.5 mm2
• Contact type: NO / C /NC
• Maximum load: 10 A – 250 VAC
• Contact life       : 10 million switches
• Switch angle: + - 45 deg
• Switching speed: max 600 / min
• Process temp: Upto 50’C
• Process pressure: Max – 0.1 mpa
• Liquid density: min – 0.8 g / cm 3
• Housing material: non – toxic polypropylene
• Protection: IP 68

Float switches are designed as contactless magnetic switches. They are used to control level in containers tanks with non-flowing and or flowing liquids such as water, oils, caustic solutions etc. Float switches consist of a connection head, an immersion tube with one to four magnetic sensor elements and a float. Versions with straight or elbow immersion tube are available.

• Application: Water Levelling
• Voltage: 200VDC
• Frequency: 50HZ
• Power: 0-5Amp
• Hole Diameter: 0-20mm
• Brand Name: Kcass, Aarpee

We are enlisted among the established Manufacturers, Suppliers and Exporters of Cable Float Level Switches from Maharashtra. The Cable Float Level Switches we make available are manufactured in compliance with set industrial norms. We maintain a large stock of the Float Level Switches, to cater the bulk and urgent requirements of the buyers. The entire range of the Float Level Switches is reasonably priced by us.

Model No.: JB/CFS/401 Features• Low cost polypropylene level switch • Hermetically moulded, double chamber • Mercury free operated micro switch• Direct pump control up to 1.1 kW • Adjustable switch differential • Low specific weight of the floating bodyAPPLICATIONS• Level switch from drinking water to sewage• Pump protection in small pipes • Fail-safe indication and pump controlSPECIFICATIONSSwitch rating: 250V AC, 15 A Temperature: 0 °C to 80 °C Pressure: max. 2 bar Protection: IP 68

Our product range includes a wide range of mounted level switch, cylinder float level switch, SS float magnet level switch, S float inside magnet level switch, magnetic float level switch and float level switch, PP Float Switches & Much More

SPECIFICATIONS : Installation : Normally side / top for special applications Switching enclosure : Cast aluminium, weatherproof to IP 56 / IP 65 Conduit connection : Brass, " ET / " NPT Float : SS304 / SS316 / PP / PTFE Coated Min. Sp. gravity : 0.6 depending upon float material and dimensions. Process Connection : Flanged Switch Element : Micro Switch (max-temp - 150C and 250C) Switching Capacity : 5 Amp. 230V AC. Switching differential : Fixed or adjustable in steps from 10 to 300mm depending upon float, trim length, cam positioning. Repeatability : 1 mm Load / Insulation : Resistive / 150 mega ohms at 500 V DC Max temp : Upto 250C and high temp. model upto 350C Max Pressure : Upto 20kg/cm2 at ambient temperature Finish : Regular / Sanitary

• Advantages: Corrosion Free,Sturdy and durable & need no maintenance.No current / voltage is passed through water, therefore no electrolysis or Salt deposition.

Model MLS - 04 / MLS -16 magnetic level switches work on the principle of magnetic repulsion and therefore they are glandless and leak proof instruments. A permanent magnet fitted in the tail piece of the float repels another magnet inside the switch housing which in turn operates an SPDT microswitch. Microswitch contacts can be utilized for initiating audio-visual signals or pump control. SALIENT FEATURES : As our switches work on magnetic repulsion principle, they are glandless and leak proof. No power consumption. Internal assembly wirings are teflon insulated. Internal switch assembly bracket is of cast aluminium. Practically no maintenance is required except periodic cleaning. Suitable for 2.5" (65 mm) NB nozzle mounting, (for 63 mm dia float) and 2 " (51 MM) NB nozzle for 48 mm dia float. Maximum working temperature 250°C. (Process Temperature) Contact ratings of MICROSWITCH 5 AMPS at 230 VAC Resistive. Also available with Microswitich having current rating 10 A at 230 VAC Resistive. No of contacts : 1 change over as standard. Optional - 2 change over For high temperature upto 350°C (Process temperature) 1 number SPDT Reed switch with current rating 100 VA, max. switching current 5 Amps, max, switching voltage 230 VAC / 200 VDC Specific Gravity : Down to 0.75 CAUTION : Level Switches should not be used for direct starting / stopping of pumps. An external relay or contractor must always be used with the level switch. MLS-04/MLS-16 side mounted level switches must always be mounted horizontally with outgoing cable entry facing downwards. In case of high temperature Model MLS-04-92 HT/MLS-16-92HT and Low Temperature Models SMT-04-F82 and SMT-04-F92 arc suppressors/current limiting bias resistor must be provided depending on the load viz inductive or lamp load etc. to reduce the deteriorating effect of contacts due to surge voltages and high in-rush current TECHNICAL SPECIFICATION : Model (MLS-04-F82) or (MLS-04-F92S) side mounted magnetic Level Switch.Process connection- 82 or 92mm square flange with 4 bolt holes of 10/14mm dia on 82 or 92mm PCD respectively. Matenal of construction of flange, brackets, fulcrum screws, body and cover-SS 304(For wetted parts in SS 316 please denote by 16 instead of 04 in the Model). SS 316L float. 1 no SPDT microswitch having current rating 5 Amps at 230 VAC resistive. Differential between make and break-10mm approximately.Maximum working pressure 10 kg/sq.cm and temperature 250 deg C.Specific gravity down to 0.7.Cable entry neoprene gromet. Supplied with 1.5 Metre long 3-core PVC Cable. NB : In case of Model MLS-04-F92 flange size shall be 120 mm dia round flange with 4 bolt holes of 14 mm on 92 PCD. .

The Float level switch offered by Toshbro Controls is suitable for all kinds of liquid and is available in a unique 3 modular design. The 3 modules – switch, flange and float module – can be supplied in countless variants and provides problem solutions for any application.

"MAHALAXMI" make model MLS - 04 / MLS -16 magnetic level switches work on the principle of magnetic repulsion and therefore they are glandless and leak proof instruments. A permanent magnet fitted in the tail piece of the float repels another magnet inside the switch housing which in turn operates an SPDT microswitch. Microswitch contacts can be utilized for initiating audio-visual signals or pump control. Salient Features : As our switches work on magnetic repulsion principle, they are glandless and leak proof. No power consumption. Internal assembly wirings are teflon insulated. Internal switch assembly bracket is of cast aluminium. Practically no maintenance is required except periodic cleaning. Suitable for 2.5" (65 mm) NB nozzle mounting, (for 63 mm dia float) and 2 " (51 MM) NB nozzle for 48 mm dia float. Maximum working temperature 250°C. (Process Temperature) Contact ratings of MICROSWITCH 5 AMPS at 230 VAC Resistive. Also available with Microswitich having current rating 10 A at 230 VAC Resistive. No of contacts : 1 change over as standard. Optional - 2 change over For high temperature upto 350°C (Process temperature) 1 number SPDT Reed switch with current rating 100 VA, max. switching current 5 Amps, max, switching voltage 230 VAC / 200 VDC Specific Gravity : Down to 0.75   NOTE : Flanged connections as per ASA/BS/DIN or JIS available on request, as per customer requirement.   Caution : Level Switches should not be used for direct starting / stopping of pumps. An external relay or contractor must always be used with the level switch. MLS-04/MLS-16 side mounted level switches must always be mounted horizontally with outgoing cable entry facing downwards. In case of high temperature Model MLS-04-92 HT/MLS-16-92HT and Low Temperature Models SMT-04-F82 and SMT- 04-F92 arc suppressors/current limiting bias resistor must be provided depending on the load viz inductive or lamp load etc. to reduce the deteriorating effect of contacts due to surge voltages and high in-rush current.   Dimension Models : (MLS - 04 - F 82) & (MLS - 16 - F 82) (MLS - 04 - F 92 S) & (MLS - 04 - F 92 ) & (MLS - 16 - F92 S) & (MLS - 16 - F 92)   L=165mm, g=80mm, with d=49mm f Float.* Applicable only for model MLS - 04/16 - F92, when 62 mm dia float is used,L=240mm, g=135mm, with d=62mm f ALL DIMENSIONS ARE IN MILLIMETRE (TOLERANCE - ± 2 MM) Technical Specification : Mahalaxmi make Model (MLS-04-F82) or (MLS-04-F92S) side mounted magnetic Level Switch.Process connection- 82 or 92mm square flange with 4 bolt holes of 10/14mm dia on 82 or 92mm PCD respectively. Matenal of construction of flange, brackets, fulcrum screws, body and cover-SS 304(For wetted parts in SS 316 please denote by 16 instead of 04 in the Model). SS 316L float. 1 no SPDT microswitch having current rating 5 Amps at 230 VAC resistive. Differential between make and break-10mm approximately.Maximum working pressure 10 kg/sq.cm and temperature 250 deg C.Specific gravity down to 0.7.Cable entry neoprene gromet. Supplied with 1.5 Metre long 3-core PVC Cable.   NB : In case of Model MLS-04-F92 flange size shall be 120 mm dia round flange with 4 bolt holes of 14 mm on 92 PCD.   Optional : Microswitch with current rating 10 Amps at 230 VAC res. Adjustable differential upto approx-250 mm With 2 microswitches i.e., 2NO + 2NC

This low-cost switch is used for a variety of applications such as control of submersible pumps. This can be used in fresh water , sea water, sewerage and industrial effluents.

Magnetic Float Operated Level Switches It is a reliable technique in Industry for point liquid level sensing and control in open or pressurized tank. MODEL NO. : FITZER / TLS / 50 Miniature Level Switches  Fitzer small size liquid switches features a small float displacement especially suitable for narrow or restricted area. SERIES : FITZER / LS / 10

SIGMA's Cable Float Switch (Tilt Type) has a double chamber construction to make it absolutely hermetic. Switch differential is set with the help of a counter weight that can be adjusted alongside the cable of the switch. Its non-toxic body materials and mercury-free operated micro switch enable its use in drinking water applications.

This meter is more suitable for effluents,slurries, pulps, molasses & other highly corrosive liquids   Mounting:Top mounted, side mounted   Wetted parts:S.S.304.316   Process connection:Flange / screwed   Switch rating:2 / 5 Amp..230 V AC / 24 VDC

• Switching element: : Micro Switch
• Life of Switch: 1,00,000 Operations
• Rated voltage: 250 VAC

It is also an alarm device at certain pre-determined surface levels. It is suitable for use in non-flammable liquids at 250 volts. In dangerous enviroments (e.g. wells and pumping stations) we recommend 24 V voltage. In potentially explosive atmospheres (e.g. oil tanks) the Switch can be used in conjunction with (Ex) i-isolator switch units. Due to its large float casing the float Switch has a buoyancy which guarantees smooth, trouble-free operation under all conditions. The switch has double chamber and a final remoulding finish to make it absolutely hermetic.

Float switches, we are renowned manufacturers and suppliers of a gamut of cable float level switches. These switches are used in locations where liquid substances are extremely turbulent in nature. Our cable float level switches are resistant to heat, water and corrosion and are easy to install and use. We ensure low maintenance, high level of accuracy and product availability at economical rates. .

Float Operated Liquid Level Switch reliably detects the fluid level in the tank. Float Operated Liquid Level Switch can be installed in tanks with small dimensions or limited space. The Float Operated Liquid Level Switch can be mounted on the side of the vessel or tank. The Float Operated Liquid Level Switch is constructed with high grade material for tough industrial use.Attributes : Reliable Accurate measurement Compact Affordable

Magnetic Float Switch, Heat Control Switches, Limit Switch

We are pleased to introduce ourselves as a group of engineers specialised in manufacturing and supplying a wide range of magnetic float switch in India.

• Switching Power: 10 W,normally open,(NO)
• Rated Voltage: Less Than DC24V(for high voltage use,access intermediate relay)
• Insulation Resistor: 108 Ohm
• Switching Life: 108 times
• Switching Response Time: 0.2 ms
• Fix Screw: M10
• Floating Diameter: 24 mm
• Installation Method: Vertical Entry 35 mm
• Used medium: Water or liquid that has no damage to the float,0- 60???
• Voltage/electric current: Below DC110V,<0.5A
• Custom-made: Wire harness specification, dimension of float, warning point, switching power
