Graphite Sheet Dealers in Mumbai

Understanding the needs and requirements of several such industrial utilities where there is need and requirements of installation of graphite sheets, we have also brought forth in the market one of the most exclusive quality flexible graphite sheets and rolls. These flexible graphite sheets and rolls have been manufactured at our company using pure and premium quality graphite. We are not only manufacturing these graphite sheets and rolls at our company but also are engaged in its supply, distribution, wholesale and export over several different countries across the world. Features: robust and sturdy durable life time easy installation supreme fabrication and finishing available in different sizes and dimensions

• Brand Name: REX

We offer high quality graphite sheets and gaskets have excellent resistance to chemical, air, water, oil, fuel, etc. They have a built – in anti stick property hence using the product solves the problem of adhesion to the flanges. Due to 98% graphite content and 1% corrosion inhibitor, this material can be used at high temperatures and for all acids and alkalis. This is not recommended for use with nitric acid.

Backed by our team of dexterous professionals, we have emerged as a proficient Manufacturer, Supplier and Exporter of Flexible Graphite Sheets from Maharashtra. Our Graphite Sheets are precisely designed with SS Foil. The Flexible Graphite Sheets offered by us are made using the finest quality factory material and advanced technology. Our Graphite Sheets are known for their durability and impeccable quality. Bulk orders of the Graphite Sheets are processed by us as per the specific requirements of the buyers.

Slade starts with special patented yarns. The yarns are reinforced with flattened strips of stainless steel and totally encapsulated in flexible graphite (fig. 1). We “weave” these yarns into sheets 80” wide (lengths: 80”, 160” and higher). The woven design produces a ‘metallic leaf-spring effect’ (fig. 2), developed to deform easily to fill voids, scratches and warped surfaces. Once compressed, they form a tough but resilient graphite sheet. The sheet cuts easily despite their toughness.

Type Graphite gaskets are made from homogeneous graphite, reinforced by metal mesh, foil or tanged metal. It offers excellent sealing capabilities such as thermal stability, self-lubrication, corrosion resistance, not being brittle and aging etc. It has long life and less maintenance is required under very extreme conditions.The rimmed metal gasket is an improvement from pure cut gaskets. The metal foils rimmed at inner and outer edges offer a special protection against blowout and chemical corrosion for the gasket, and increase the pressure resistance capability. Material   Various shapes are available, used in petrochemical, mining, vessels, boilers, piping and ducts, pumps and valves, flanges etc. Suitable for steam, mineral oil, heat transfer oil, hydraulic oil, fuel, water, seawater, freshwater etc.

We offer Graphite Sheet. Due to excellent Chemical and thermal capabilities of Graphite it is used extensively throughout the Petrochemical and Chemical industries for process duties and Steam application. It is a good solution for higher temperature and pressure application where Non Asbestos Gaskets are to be used. Graphite Sheets are available as, 1. Pure Graphite sheets (GS) - A pure exfoliated graphite sheet for high temperature application. 2. Metallic Graphite sheets (GPSM) - A pure exfoliated graphite sheet with tanged Stainless Steel reinforcement for maximum pressure up to 200bar & 450 Degree Celsius temperature. 3. Metallic Graphite sheets (GSLS) - pure exfoliated graphite sheet with plain Stainless Steel Foil insert for ease of handling.

Graphite sheets contain more than 95% pure exfoliated graphite. An Ultra High Purity (99.8%) grade is available for nuclear industry applications. More care is required in handling and storage of these sheets as they get easily damaged.

• Thickness: 1.0mm to 4.0mm
• Width: 1000mm, 1500mm
• Length: 1000mm, 1500mm

Reinforced Graphite Sheets are made with pure flexible graphite sheet reinforced with stainless steel foil or wire mesh inserted. There are two basic types: mechanically bond (Tang inserted) and adhesive bond. Reinforced graphite laminate sheets are ideal sheet gasket materials for most industrial fluid sealing applications.

We introduce ourselves as an affluent organization, engaged in offering premium quality array of Graphite Sheets. Offered sheets find their applications for the production of refractory materials, coatings, lubricants, fuel cell, batteries, powder metallurgy, carbon brushes, pencil and graphite electrodes. Provided sheets are manufactured in conformity with international standards using pure graphite granules with the help of innovative machines. Clients can bought proposed Graphite Sheets various dimensions and thicknesses at negotiable price range. Features: Fine finishing   Abrasion resistance   Enhanced durability   Maintenance free

Pure Graphite Sheet Standard Sheet Size: 1mtr W x 50 mtrs RollThickness: 1 to 3 mm Expanded graphite sheets are produced from pure, expanded flexible graphite and do not contain any other fibers or filler materials. Temperature range: - 240° C up to 450 ° C,with steam up to 650 °C, under inert conditions up to 1,200°C Properties: Expanded flexible graphite sheets are widely applicable for gases and fluids. They are chemically resistant against most media, have excellent thermal conductivity, can be stored indefinitely, do not need anti-stick coating and are extremely resistant to temperature cycles. Application: Because of its specific structure expanded graphite sheets are particularly suited for applications with extremely high or low temperatures, with highly corrosive and aggressive media, for sensitive flange materials (i.e. enamel, glass, plastic) and for gas and steam applications.

• Brand Name: Bhagyashali Metal
• Thickness: 1 mm to 3 mm
• Shape: Rectangle
• Material: Metal
• Density: 1.0 gms / cm3
• Usage: Pipe pump and valve in power, oil, chemical and light industries
• Size: 1000 mm x 1000 mm

We also offer Toyo Tanso PERMA_FOIL, a Flexible Graphite Sheet, in continuous Roll Form. Salient Features of Perma Foil are as follows: i) Excellent Self-Lubrication ii) Stable in wide range of temperature (-200 C ~ 3200 C) iii) High Flexibility & Compressibility iv) Excellent Chemical Resistance v) Excellent Thermal & Electrical vi) Excellent Purity

We specialize in offering stainless steel plates and duplex steel plates and sheets as our range imparts durability and strength. Available in different dimensions, these plates and sheets can be customized to suit the specific requirement of the clients.

• Color: BLACK
• Grade: PURE
• No. Of Ply: 3 ply
• Size/Length: 500 M
• Packaging Type: Carton
• Material: GRAPHITE
