Horizontal Multistage Pump Dealers in Mumbai

• Color:
• Voltage: 220/415
• Fluid Temperature Range: -15 to +80 Degree C
• Frequency (Hz): 50 Hz
• Maximum Working Pressure: 8kg/cm2g
• Phase: Single, Three Phase
• Protection class: IP55
• Motor Speed: 2900 rpm

• Brand Name: Kirloskar & B.E.
• Head: Upto 150 meter
• Model: 50 mm - 150 mm
• Max Flow Rate: Upto 2500 LPM
• Type: Self priming, Non self priming
• Warranty: 1 Year

UniBoost multistage selfpriming pumps use the side channel design principle. The pumps are built as single stage or multistage pumps. All the wetted parts are made from SS 316 investment casting using lost wax process giving excellent surface finish, sound casting, giving minimum resistance to flow resulting in better efficiencies. The pump stages are staggered redially to bring about balance and minimize shaft deflection. The open star (vane) type impeller are individually hydraulically balanced thus eliminating the axial thrust on the external ball bearings of the pumps. The pumps are fitted with M-seal. Features :   > The pumps are built as single stage or Multistage > All wetted parts are SS-316 investment casting > Selfpriming - side channel design principle > The pump stages are staggered redially to bring about     balance and minimize shaft deflection > The pumps are fitted with M-seal.

MH : Pump stage as well as al moving parts in contact with the pumped liquid are made of stainless Steel AISI 304 .Discharge casing and suction are Grey Iron. MHI: Discharge casing, suction casing as well as all parts in contact with the pumped liquied are made        of srainless steel AISI304. MHN: Discharged casing, suction casing as well as all parts in contact with the pumped liquid are made   of stainless steel AISI316. Applications Liquied transfer and circulation of liquids within light industry and farming Pressure boosting in single-pump and multi-pump booster systems Domestic water supply Cooling systems Air-conditioning systems Washing and cleaning systems Wter treatment. Features and benefits Compact design Reliable and robust construction Energy-optimised pumps Easy and simple installation User- Friendly operation Low noise level Reliable water supply.

• Material: Stainless Steel
• Head: 136 mtr
• Phase: Three Phase
• Max Flow Rate: 22.5 cubic mtr hour
