Hydraulic Press Brake Machine Dealers in Mumbai

We offer Mechanical & Hydraulic Press Brake Machine of various sizes and capacity and is needed for applications in several industries. We have tie-ups with reliable vendors, and hence our Press Brake Machine is known for its performance and easily managed operations. Made in conformity with high standards, our Press Brake Machine is widely in demand. We make sure that our Press Brake Machine is appropriately delivered without any damage during transportation. Details : Make : BronxLocation : Navi MumbaiStock : STK0001534Origin : Japan Technical Specifications : Beam Length : 3657mmDistance Between Frames : 3150mmThroat Approx : 280mmWith Hibass Light GuardsTop & Bottom Tooling

- All steel construction - Manual Ram adjustment on models RPB-1 and RPB-2 - Motorized Ram adjustment on models from RPB-3 to RPB-8 - Mechanical friction clutch

The Stable robust welded steel frame made of ultrasonically tested IS 2062 Plates as per guidelines of lMTMA Standards. Fast approach & fast return speed to save cycle time, slow pressing speed for better stroke control & bending accuracy, ensures high productivity. Compact Cylinders & low pressure system due to rear cylinders. Better rigidity & load carrying capacity against fatigue failure. Positive synchronisation of cylinders with welded torque tube. Moving work station with ON/OFF Controls, Emergency push button & selector for Manual, Semi-Auto & Automatic mode for easy operation & Safety. Better Safety for operator & machine. Low power consumption. NC upgradation available. Low Noise & Smooth Operation give higher efficiency of operator.

• Automation Grade: Automatic
• Capacity: 50 to 1000 ton
• Normal Pressure: 350 kN
• Main Motor Power: 15 HP
• Return Speed: 125 mm/s

This is a steel fabricated mechanical power press brake with robust steel frame to ensure minimum deflection. It is provided with several salient features:a) Twin type gear drive system provides a balanced transmission of torque on the eccentrics.b)  Fork type connecting links are mounted on the side frames thereby avoiding eccentric loads.c)  Disc type powerful clutch & brake are highly efficient.d)  Motorized Ram adjustment is provided as standarde)  Additional Bolster plate provided in higher capacity machines.The machine is supplied complete with electric motors, control panel, stroke counter, standard Die block and punch, hand operated back gauge, guards and shot lubrication.

• Condition: Good
• Stock No: STK1742016

• Certification: CE Certified
• Voltage: 380V 50HZ
• Condition: New
• After-Sales Service Provided: Spare Parts
• Warranty: 1 Year
• Type: Hydraulic

We are known for offering to the clients ysd twin (tandem) press brake machine, which is suitable for long jobs like pyramid electrical poles. The ysd twin (tandem) press brake machine provided by us is known for its long functional life and effectual functioning. It is widely used in electric pole manufacturing and oil pipe manufacturing. specifications : comprises of two or more press brakes, which works together in synchronicity to bend very large work pieces.range available : 2x3200t / 2x6000 mm to 2x2400t / 2x8500 mm

‘YSD’ HPC Series CNC Press Brake With Delam Da 65w Controller, 4 Axis [Y1, Y2, V, X] With Dac Set of & Hardened and Ground Punch with Multi ‘V’ Die  4 Axis Y1, Y2, X, R Controlled With Delem Da 52 Controller Adjustable Crowning On Work Table Hand Wheel & Micro Adjustment on Crowning Table.        Sailent Features : One Set LVD Classic Style Punch  Multi ‘V’ Die  2 Nos. Front Support Arms   Fence Guard On Throat And Rear Side Of Machine ØFoot Peddle With Emergency  Stopper  ‘T’ Slot In The Centre Of Working Table To Fixing Single ‘V’ Die Cooling Fans Fitted In Electrical Cabinet  User Manual In English

Range : 20 MT to 600 MT Length : 1250 mm to 6000 mm   International quality hydraulics components. Specially designed compact manifolds gives smooth, silent & jerk less operation       STANDARD ACCESSORIES Main Drive motor. Electric Control Panel with selection of 'AUTO', 'INCH' & 'SINGLE CYCLE AUTO' mode operation. Movable Work Station with pair of foot switch. Pair of lifting links. Pair of sheet support. Fine stroke adjustment rod with limit switch. Manual back gauge with micro setting. One suitable five way Die & Punch of EN-9. Centralised lubrication system with flow control valve for proper lubrication. RAM tilting arrangement.   OPTIONAL ACCESSORIES N.C. Operated Stroke control. N.C. Operated back gauge & stroke control. Sliding sheet support with Swing away stoppers. Hardened tools & special toolings Anti-deflection unit. Hydraulic tool clamping. Motorised back gauge with DRO. Higher throat depth. Anti Deflection Unit. Multiple depth setting arrangement. First fill of hydraulic oil

We deals in supplying of wide range of Hydraulic Press Brakes.

Press Brakes are designed and developed through years of experience in sheet metal working machines. Press Brakes are widely accepted in industries for continuous production runs and in areas requiring accuracy and repeatability coupled with high production.Frame : Frame is of robust fabricated steel construction of rigid and interlocked design. It is stain-free and supports the ram and bed against desired deflection under permissible loading condition.Ram and bed : Made from steel plates of suitable thickness, machined for straightness and parallelism of working surfaces. Ram is guided and supported throughout the stroke by accurately machined guideways. Drive system : Power is transmitted to the ram through two individual gear drives for uniform load distribution throughout the length. This also reduces the torsional stresses on the eccentric shaft. Electric motor used is of sufficient H.P. which reduces slowdown of fly wheel and increases energy available per stroke. The gear and pinion are made out of carbon/alloy steel.Ram Adjustment : Motorised ram adjustment through a simple drive mechanism, faciliates quick bending angle adjustment. Angular ram adjustment made simple by incorporating a spring loaded dog clutch.Clutch and brake : All series of press brakes are provided with high-torque tow-inertia friction clutch synchronised with heavy duty mechanical brake ensuring immediate braking of ram on releasing the pedal Clutch operating levers are designed in such a way that minimum enraging force is required at the pedal.Special Features : Connection link mounted on crank shaft for uniform load, separate Drive system for each connection link, Sufficient H.P Normal torque motors provided. Boltless pedal mounted on hexagonal bar. General purpose V-Block and punch supplied as standard accessories.

For getting the desired bending of the metal sheets and plates, we offer high-end Hydraulic Press Brake Machine. Our Hydraulic Press Brake Machine is made using tested components and is highly durable. Hydraulic Press Brake Machine, offered by us, is free from vibration and thus offers noiseless performance. Our precision engineered Hydraulic Press Brake Machine is also appreciated for its high speed performance, wear-and-tear resistance, ease of operation, etc. These Hydraulic Press Brake Machines are used in different industries because of these desirable features. Features Monoblock Constructions with minimum pipe fittings and valvesUse of Good quality seals and surface finish on moving partsProvision of safety pressure relief valve ensure safely under overloadProvides adjustable pressure and full pressing capacity over the entire bending cycleCapacity : 20MT to 200MT Standard Accessories Electric motor (with certificate)Control panelFoot switchStandard v-block & PunchManual back gaugeManual lubricationInstruction & Maintenance manual Optional Accessories Goose nech punch & other toolingElectronic Stroke counterNumerical Control (NC) operated back gauge systemFront operated power back gaugeTwo Front sheet supportsAutomatic lubrication systemAnti deflection systemFirst fill of hydraulic oil Technical Specifications Model Tonnin MT Bending Capacity (in mm) Table Length (in mm) Table Width (in mm) Ram Stroke (in mm) Open Height (in mm) Depth of Throat (in mm) Clear Pass (in mm) Pow in HPMPB215 20 1.6x1500 2x1250 1525 125 100 250 100 1050 3MPB320 30 2x2000 3x1250 2030 125 100 250 200 1550 3MPB420 40 2.5x2000 3x1500 2030 180 100 250 200 1550 5MPB425 40 2x2500 3x1500 2540 180 100 250 200 2050 5MPB515 50 4x1500 5x1200 1525 180 100 250 200 1050 5MPB520 50 3x2000 4x1500 2030 180 100 250 200 1550 5MPB525 50 2.5x2500 3x2000 2540 180 100 250 200 2050 5MPB625 65 3x2500 4x2000 2540 180 150 330 200 2050 5MPB630 65 2.5x3000 3x2500 3125 180 150 330 200 2550 5MPB820 80 5x2000 6x1500 2030 180 150 330 200 1550 7.5MPB825 80 4x2500 5x2000 2540 180 150 330 200 2050 7.5MPB830 80 3x3000 4x2500 3125 180 150 330 200 2550 7.5MPB840 80 2.5x4000 3x3000 4200 180 150 330 200 3100 7.5MPB1025 100 5x2500 6x2000 2540 180 150 330 200 2050 10MPB1030 100 4x3000 5x2500 3125 180 150 330 200 2550 10MPB1040 100 3x4000 4x3000 4200 180 150 330 200 3100 10MPB1225 125 6x2500 8x2000 2540 230 150 350 300 2050 15MPB1230 125 5x3000 6x2500 3125 230 150 350 300 2550 15MPB1240 125 4x3500 5x3000 4200 230 150 350 300 3100 15MPB1625 160 8x2500 10x2000 2540 230 150 350 300 2050 15MPB1630 160 6x3000 8x2500 3125 230 150 350 300 2550 15MPB1640 160 5x4000 6x3000 4200 230 150 350 300 3100 15MPB2025 200 10x2500 12x2000 2540 230 200 400 300 2050 20MPB2030 200 8x3000 10x2500 3125 230 200 400 300 2550 20MPB2040 200 6x4000 8x3000 4200 230 200 400 300 3100 20MPB2530 250 10x3000 12x2500 3125 300 200 400 300 2550 20MPB2540 250 8x4000 10x3000 4200 300 200 400 300 3100 20MPB3030 300 12x3000 15x2500 3125 300 200 400 300 2550 25MPB3040 300 10x3500 12x3000 4200 300 200 400 300 3100 25MPB4030 400 16x3000 20x2500 3125 300 250 500 350 2550 30MPB4040 400 12x4000 16x3000 4200 300 250 500 350 3100 30MPB5030 500 20x3000 25x2500 3125 300 250 500 350 2550 40MPB5040 500 15x4000 20x3000 4200 300 250 500 350 3100 40

Tread Brake Unit type BF2S as per SAB-WABCO design is a very compact device integrating entire brake actuating mechanism for Railway vehicles comprising of Brake Cylinder, Levers for magnification of Braking efforts, Slack Adjuster to keep Cylinder stroke constant irrespective of Brake Shoe Wear and Brake Shoe Holder with twin Brake Blocks.

COUNTRY OF ORIGIN FRANCE TYPE OF CONTROL CONVENTIONAL LOCATION NEW DELHI CAPACITY 40 TON LENGTH OF TABLE 2m WEIGHT OF THE DIMENSION 3.5 TON DIMENSION OF THE MACHINE L: 2400mm W: 1m H: 1800mm POWER REQUIREMENT 4 KW

These are heavy duty Hydraulic Press Brake machines available in a wide range of capacities ranging from 20 tons to 500 tons in pressure and job sheet size from 1500 mm to 5000 mm in length with 1.62mm to 20 mm in thickness.   The machines are supplied complete with all standard accessories including the following: Main Drive Motor Electrical control panel with selection of AUTO, INCH and Single Cycle AUTO mode of operation Pair of foot switches Pair of lifting links Fine stroke adjustment rod with limit switches Front operated manual back gauge with fine setting knobs One suitable 5 way die and universal upper blade- segmented or full length Centralized lubrication system with hand pump Pair of sheet supports Bending chart Maintenance tool kit Comprehensive instruction & maintenance manual with CD   Many optional accessories are offered such as:   Motorized deflection compensation unit Ram tilting arrangement Hardened and ground tools & special toolings Motorized back gauge with DRO Sliding sheet supports with swing away stoppers for front gauging. Hydraulic tool clamping Photo electric finger safety guards   We also offer NC and CNC Synchro Press Brakes. Kindly ask for details with your requirements.
