Pneumatic Quick Coupler Dealers in Mumbai

Available in SS316 with Viton 'O' Ring Robust in Construction. High Flow Capacity. Positive Valve stop. Captive valve seal ensures leak free sealing, minimize the seal washout or damage from high velocity Fluid acceleration. Seal with PTFE back- up rings designed to ensure reliable and leak free sealing even in high pressure application.

CFP, Threaded Quick Couplings     Fiber-reinforced 1-1/4-inch threaded nylon quick coupling to fit abrasive blast machine outlet. Comes bonded to schedule 80 pipe.Description of OperationThe CFP coupling attaches at the blast machine pusher line outlet and allows quick coupling with any blast hose fitted with Clemco quick couplings.Advantages• Fiber-reinforced nylon material springs back from most impacts that would dent or deform metal couplings• Built-in lock-springs eliminate need for safety pins• Lighter weight than metal couplings• Injection molded for precise dimensions, ensuring positive fit

AK Industries Quick release couplings are used for connecting and disconnecting various fluid lines. It can operates simply by one hand push action without twisting or wrenching. Automatic locking during disconnection minimizes fluid loss. Features Double shut off couplings are used when positive shut off of both ends of pressurize lines is required. Single shut off are used where only automatic shut off of socket end is required. Straight through coupling is use for maximum flow and without automatic shut off. Size: 1/8” to 4”. Pressures : Vacuum to 150 PSI (350 kg/cm2 )

authorized distributor for stucchi, italy in india. stucchi- s.p.a. italy– hydraulic quick release couplings, multi couplings & valves iso 7241-a and b series, iso 16028 bir, firg, irbo, irbx series available threads: bsp npt bspt sae available in steel-zinc plated, high strength carbon steel, al, brass and ss. poppet type (standard) flat-face type (non-spill), ball type, ballpoppet type, check valve type sizes: from 14'' to 2'' delivery: ex-stock

Our extensive range of easy to install Quick Connect Couplings are manufactured keeping into attention every detail of functional variations. Quick couplings are exported to a large number of industries across the globe. We hold the capabilities to engineer products as per our client's specifications requirements.

We are authorised representative of stucchi italy in india. iso 7241-a and b series, iso 16028 bir, firg, irbo, irbx series available threads: bsp npt bspt sae available in steel-zinc plated and ss. poppet type (standard) flat-face type (non-spill) sizes: from 14'' to 2'' delivery: ex-stock

High-quality quick-action coupling made of steel, stainless steel, brass or plastic for practically every application contingency Very robust, rapid and secure coupling of practically all fluid media. Special solutions for your application needs can also be implemented upon request.

• Brand Name: OMS
• Material: MS / SS / BRASS
• Color: GREY
• Features: Superior functionality , Unmatched strength ,User friendly
• Item Code: OMSQRC1030
• Pressure: 3000 PSI - 6000 PSI

• Thread Size: 1/4 inch - 3 inch
• Features: used to provide a fast, make-or-break connection of fluid transfer lines, Operated by hand, quick connect fittings replace threaded or flanged connections, which require wrenches

• Type: Coupling
• Material: Brass
• Application: Pipe Jointing
• Color: Multi Colour
• Finishing: Polished
• Diameter: 15-20mm, 20-25mm, 25-30mm, 5-10mm
• Thickness: 10-20mm, 20-30mm
• Length: 1inch, 2inch, 3inch, 4inch
• Weight: 0-10kg
• Feature: Corrsion Proof, Crack Resistance, Durable

we  at  veer  enterprises  are  manufacturers  and  dealers  of  all type of  quick  release  coupling  camlock  coupling  hose  coupling  pipe  coupling in india  we  do  stock  imported  brand  like  holmbury  coupling  stucchi  coupling  faster  coupling DNP italy  make  dealer  in india  veer  enterprise  vardhman bearings

We are offering quick release couplings. Quick release coupling quick disconnect coupling (qrc) are available in three types i.e. Single check valve, double check valve & through type and confirms to is0 7241 series a & b. Through type couplings have no valves in either half and are ideal for maximum flow application. Their smooth, open bore offers the lowest pressure drop of any quick disconnect coupling, and allows them to be thoroughly cleaned. Since there are no valves in either half, fluid flow should be shut off before the coupling is disconnected. While to avoid spillage during decoupling single check valve or double check valve coupling should be used. as compared to double check valve there is some amount of spillage in single check valve. Double check valve coupling are used extensively when it is important to minimize fluid loss upon decoupling. In double check valve both halves i.e. Coupler and adaptor contains shut off valve. These valves open automatically when the coupler and adaptor are connected and close when the two halves are decoupled keeping fluid loss minimal. Quick release coupling permit easy, safe, quick & reliable connection between delivery & pressure line.

• Type: Quick Release Couplings
• Material: Stainless Steel
• Grade: ASTM
• Finishing: Polished
• Application: Pipe Jointing, MARINE
• Diameter: 10-15mm, 15-20mm, 20-25mm, 25-30mm, 5-10mm
• Thickness: 10-20mm, 20-30mm, 30-40mm, 40-50mm
• Length: 1inch, 2inch, 3inch, 4inch
• Weight: 0-10kg, 10-20kg, 20-30kg, 30-40kg
• Condition: New
• Feature: Corrsion Proof, Fine Finished

• Material: Metal
• Application: Pipe Jointing
• Grade: AISI, BS, GB
• Finishing: Polished
• Diameter: 15-20mm
• Thickness: 20-30mm
• Feature: Corrsion Proof, Crack Resistance, Fine Finished

We use latest technology and comprehensive quality control systems in designing and manufacturing wide range of Quick Release Coupling. Designed for reliable performance, our entire range is fabricated from qualitative raw material for ultimate durability and strength. These corrosion resistant coupling come with single & double shut off valves for avoiding leakage.   QRC type coupling work on Push and Pull principle. When the Adaptor is pushed to the coupler, its is accurately held by the self locking arrangement resulting in a positive & leak proof connection. This action simultaneously opens the valve & fluid flow starts. To disconnect, pull back the sleeve of the coupler, the Adaptor ejects out and the valves shut off automatically. Valves are provided in type one way sealing & two way sealing.   Features : Quick connect / Release Couplings eliminate valves and screw on fittings in many pneumatic, hydraulic and chemical systems. Permits easy, safe, quick & reliable connections between delivery lines, pressure hoses etc. Connection disconnection of fluid systems is as easy as plugging in an electric gadget.

• Size: 1/8" upto 3"
• Temperature: Upto +370ºC
• Seal Material: Nitrile/ Viton/ Neoprene/ Silicon/ Teflon.
• Body Material: Carbon Steel / Brass/ S.S. 304/ S.S 316/ Aluminum.
• End Connection: Socket welding, hose thread, pipe thread, hose shank & flanged.
• Pressure: Upto 4000 psi

Type 1) Double Check Valve QRC i,e. with self        Sealing Valve at coupler & adaptor ends.   2) Single Check valve QRC i,e. self sealing        valve at coupler & through types adaptor.   3) Without Check Valve QRC i,e. both coupler        & adaptor through type.   Application Wide application on fluids line connections like   air, steam, gases, liquids, oil, etc, used in   FERTILIZER, CHEMICAL PETROLEUM,   FURNACES,TEXTILE MACHINE, MACHIN   TOOLS, REFRIGERATIONS & MANY   MORE INDUSTRIES.   The advantages of Quick Release Couplings: 1. Instant connection or disconnection without a     drop leakage due to internal action of valves.2. Suitable technology.3. High mechanical precision.4. A quality of materials and sealing suitable for     every fluid.5. A rigorous control which ensures safety for     use with gas, oxygen, hydrogen, propane,     steam, solvent & acids acetylene etc.

We are offering quick release coupling, flat face quick release coupling, 1000 bar screwed tpye coupling, rotary union,high pressure ball valves 2 way and 3 way type.

• Type: Coupler
• Material: Copper, Plastic, Steel
• Thickness: 10-15 mm
• Weight: 10 gm, 20 gm, 50 Gm
• Color: Yellow, Copper
• Condition: New, Used
• Finishing: Polished, Non Polished
• Feature: Light Weight, Durable
• Warranty: 1 Year

FAV Quick Release Couplings or Quick Disconnect Couplings are the most versatile couplings available and are suitable for use with various liquids, chemicals, steam, gases and vacuum. FAV Quick Disconnect Couplings are based on the industry standard and available in Brass, steel and stainless steel construction available in all sizes. Variety of End connections includes female NPTF, BSPP and SAE o-ring boss. We also Promote Heavy duty steel couplings for use in high impulse service and are available in most sizes.

we at veer enterprises are manufacturers and dealers of all type of quick release coupling camlock coupling hose coupling pipe coupling in india we do stock imported brand like holmbury coupling stucchi coupling faster coupling DNP italy make dealer in india veer enterprise vardhman bearings.

We use latest technology and comprehensive quality control systems in designing and manufacturing wide range of Quick Release Coupling. Designed for reliable performance, our entire range is fabricated from qualitative raw material for ultimate durability and strength. These corrosion resistant coupling come with single & double shut off valves for avoiding leakage.Working PrincipleQRC type coupling work on Push and Pull principle. When the Adaptor is pushed to the coupler, its is accurately held by the self locking arrangement resulting in a positive & leak proof connection. This action simultaneously opens the valve & fluid flow starts. To disconnect, pull back the sleeve of the coupler, the Adaptor ejects out and the valves shut off automatically. Valves are provided in type one way sealing & two way sealing.Features1 - Quick connect / Release Couplings eliminate valves and screw on fittings in many pneumatic, hydraulic and chemical systems.2 - Permits easy, safe, quick & reliable connections between delivery lines, pressure hoses etc. Connection disconnection of fluid systems is as easy as plugging in an electric gadget.

• P- Male Pipe Thread: 1/8" BSP

Quick connect coupling Male parallel pipe thread and 60º sealing cone for connection to hose pipes fitted with sealing cone and swivel nut.

We are one of the best manufacturers of Quick Release Couplings in the market. We manufacture only the best grade couplings using the most modern manufacturing techniques and using premium grade raw materials. Keeping customer experience and safety in mind we adhere to all safety and regulatory protocols. We supply this product in bulk at strategic prices worth your time and money. For any further information or doubts please do not hesitate in contacting us.   Details : QRCs are According to ISO 7241 B, ISO 7241A, DIN/SEA/ISO/UNF standard. Range - Double check valve type, single check valve type, through bore type, Flat face type, screw type jack coupling, Free flow type, Screw type jack Coupling I Self lock type. Types & Sizes - Low pressure series up to 3000 PSI W.P I High pressure series up to 6000 PSI & 10000 PSI W.P. End Connection - BSP/BSPT/NPT/UNF/Metric threads type, socket weld or butt weld type, pipe od with Nut & ferrule type, Flange type. Materials - Steel-st.37.5 (IS 1018 or IS2062 grade of C.S) with trivalent Zinc passivation, stainless steel SS304/SS316 grade, Brass (on request).

• Brand Name: Perfect
• Material: ss 304 & ss 316
• Size: 1 inch, 2 inch, 3 inch, 1/2 inch, 3/4 inch
• Weight: 67 Gram
