Protocol Converters Dealers in Mumbai

• Type: Protocol Converters
• Material: Plastic
• Certification: CE Certified
• Condition: New
• Warranty: 1Year
• Country of Origin: Argentina

The HRT2MDB to MODBUS RTU Protocol Converter allows the connection of smart field instruments that use HART protocol over 4-20 mA to monitor equipment that uses MODBUS RTU protocol. The device periodically acquires the four dynamic variables or up to eight of the device variables of the HART instrument and provides them through the MODBUS RTU protocol to the master equipment. HRT2MDB is having DIN rail mounting available with RS232 and RS485 port. Accept operating input power from 9 to 30 VDC. Each system is provided with one configuration modem serial cable (DB9—MiniDin4) and a CD with manuals & PC configuration software.

Telenet’s TPC 3020 E1 to V.35 protocol converter can realize the bi-directional data transfer from E1 port to V.35.This equipment is widely used in communication network including WAN and LAN, realizing the transfer from E1 channel of SDH or PDH equipment to V.35 which maybe provided with router. Features:   E1 channel: both framed & unframed are OK, both 75 & 120ohm are OK Standard: G.703, line code: HDB3 Alarm system for E1 loss Support local/remote loop test DB25 connector for V.35, in DCE mode Multiple clock selection: internal clock, V.35 line clock and E1 recovery clock Panel instruction for easy understanding of equipment working status Internal power supply, 220V AC and -48V DC optional Standalone and module at your selection   Specifications:   E1 Port   Bit rate: 2.048Mbit/s+-50ppm Line code: HDB3 Standard: Compatible with ITU-T G703 Connector: BNC connector with line impedance 75ohm, RJ45 connector with line impedance 120ohm Jitter performance: in full compatible with G742 and G823 V.35 port   Line code: NRZ Bit rate: 2.048 Mbit/s+-50ppm Connector: DB25female, with DB25/M34 transfer line Way of Connection: DCE Clock: Line Clock, Local clock   General   Operating temperature: 0-50 °C Power Supply: -48VDC or 220VAC+-20% Dimension: 170mm(W)*133mm(D)*40mm(H)

Protocol Converter, Hart Gateway, RS232 To RS485 Converter
