Yarn Printing Machine
We are the one stop destination for availing precision engineered Yarn Printing Machine. Made from premium grade components, Yarn Printing Machine offered by us is user friendly and demands very low maintenance. Features Suitable for multi colour dyeing of spun yarn of Cotton, Polyster, Acrylic etc. Upto yarn count of NM60. Dyeing cycle is fully automatic and controlled. The yarn duly soft wound either on stainless steel perforated cone or cylindrical cheese can be processed.The Machine is complete with 8 colour tanks of 30 Itrs each,has specially designed sealess pump for each colour. Dye stuff is automatically dosed during operation. Machine is equipped with high capacity vaccum pump directly coupled to squirrel cage induction motor can be installed on floor, as no special foundation is required. It is designed for production capacity of 40 cones/cheeses per hour or approximately 900-1000 kgs. per day production based on 22.5 hours working with one cone/cheese weighing1 kg.For dyeing of yarn in different size and shape of supply package additional jaws can be optionally offered. Technical Specifications Installed Power : 5 H.p./3.8 Kw motor with supply line of 3 phase neutral standard 380/440 volts AC, 50 cycles.Connected Load : 10H.P/7.5KwWater Supply : 1/2" line connection for inlet and 1 1/4" connection for drain outlet. Approximate consumption 10 litres per minute.Compressed Air : 1/2" line connection at 12 CFM. Requirement 21 cubic metres per hour.Cooling Waterforvaccum Pump : 9 litres per minute at 1 kgs / cm2 pressure. Additional Process Requirement : Dyestuff fixation or development can be done in autoclave. Subsequent washing, drying and rewinding will have to edone. For those not having regular package dyeing facilities, Small Soft Cone winding machine of 12-15 spindles as well as small autoclave can beoffered.
...moreYarn Dyeing Machine
Vacuum Pressure Steaming Machine
Avail high performance Vacuum Pressure Autoclave from us. Vacuum Pressure Steaming Machine, that we make available, offers cutting edge performance. Fabricated with great excellence, Vacuum Pressure Steaming Machine provided by us is robustly constructed as well. Auto Clave vacuum pressure steaming machine is a vessel, in which, in controlled parameters i.e. Vacuum, Temperature & pressure, the material is being treated without bringing any changes in its physical, chemical characteristics. Vacuum -pressure steaming machine is normally used for twist of cotton, Synthetic & Woolen Yarn. It is also useful for bulking of Cash milon. Apart from this it has got verity of application in Rubber, plywood chemical processing industries. Yarn steaming is a method in which yarn is being steamed to improve the running of yarn in no. of respective. Due to the curling tendency is twisted yarn; it leads to loop formation during weaving, warping process, ultimately resulting in end break ages. In vacuum steaming process the snarling index of yarn is being is set to the required level thus eliminating possibility of loop formation. Due to vacuum steaming process yarn is being homogeneously moisturized which leads to reduction in electrostatic. Charge or otherwise Yarn will have a hairy look. Due to moisture contents in Yarn it increase the flexibility&elasticity also reducing the formation of fiber fly. By the steaming process one can give the required bulling effect to the carpet,- knitting & hosiery Yarn, & improve its appearance. In steaming process shrinkage in material is Eli"minute in yarn stage itself thus eliminates various difficulties, which may arise during further processing of material. In Vacuum; pr.ocess, Vacuum is created in machine, this allows better & uniform penetration of steam upto inner layer of materials. Since it is a pressure vessel you can very economically & effectively achieve the te.rnperature above 100o C, which is essential for the twist setting of synthetic material. Specifications : The plant consist of one no. Vessel made out of high quality &tested M. S. material. Rapid locking door operated by pneumatic cylinder. Heating : Direct & Indirect heating coil is provided. Connection for steam in let with necessary pipeline &value.Made perforated sheet to avoid direct flushing of steam on material.Inside trolley with nos. aluminum basket or peg type trolley suitable for packages. Two Nos. dead weight type safety value. One connection for draining the vessel with value. Nozzle for drain line of stem condensate outlet. Heat exchanger width connecting pipe line to vacuum pump &vessel. Vacuum pump coupled with reputed make motor of HP, 3 HP, 440 V.A.C. Control panel is M.S. cubical, which contractors, fuses, Vacuum indicator controller, Temperature controller, Timers, step relay, Hooter Cong bell are fitted & is ready for operation. Pneumatic Manifold : One M.S. stand on which solenoid valves, FRL assembly & FCP with pressure gages are fitted & also supplied with brass nipples, tee & copper or PCV pipe, for internal pneumatic connection, for the operation of pneumatically operated diaphragm control valves. Pneumatically operated diaphragm control valves for vacuum steaming, pressure/ Air release line. While Ordering Please Specify Type of materialType of carrier required i.e. basket or peg type trolley.Size of Packages & Weights. Production No. of Batches will Dependup on Following Type of material such as polyester/ Nylon/ Blend etc.Supply of steam water &air at required pressure/ temperature.No. of TrolleyIndividual working practices.Availability of well trained personnel in running of the machine. Guarantee One year from date of supply for components manufactured by us.Warranties received from our sub-suppliers will be transferred to you.However for item like gaskets, temperature indicator, electrical parts etc. our sub- suppliers do no be able to provide any guarantee. Erectionand Commissiong Erection & commission will be done by us at extra cost. For details ask for erection contract. We will be depute our erection engineer after hearing from you that the machine has been brought to the site & that all civil work, foundation utility connection completed as per requirement. Following Service arer equired from Client All civil work &foundations.Water at 30o C at required pressure & quality with valves strainer pressure gauge & fitting to be provided wherever it is required.Supply of air whare ever it is required with valves, fittings and gauges.Electrical cabling with necessary isolating switch upto the control panel & instaltation of cable from control panel to pump motor & other electrical instruments, solenoid valves ect.Drained arrangement from the machine / cooling water / condensate outlet. The Salient features of Vaccum Pressure steaming machine (Auto Clave) The machine is manufactured in best quality - M. S. plates.Operating cycle : fully automatic & interlocked.Door closing : By rapid looking & operated by Pneumatic Cylinder.According to the quality of material, Vaccum, steaming time, no. odd cycles, temperature etc.Can be set individually.Heat resistant paint applied inside. Back by prompt after sales service & easy available in 3 models : VE- 100, VE- 200, VE- 300, VE- 400, VE- 500.
...moretextile processing machinery
stainless steel dye springs
space dyeing machine
Laboratory Sample Dyeing Machine
We are a prominent Laboratory Sample Dyeing Machine Manufacturer, Exporter and Supplier. We are engaged in making available feature packed Laboratory Sample Dyeing Machine. Made from to quality components, Laboratory Sample Dyeing Machine offered by us is precision engineered. Venkteshwara /HP, is a versatile dyeing machine for universal application treating material in various forms, such as packages, muffs, wrap beams, loose stock tops, All Venkteshwara Dyeing Machines are supplied with state of art technology with computerized Dyehouse management in duel versin in Air pad & fully flooded System. Venkteshwara range of Dyeing Machines include laboratory and small production machines. The rage is 1 Kg. to 125 Kg. designed for high operating Temp. 140o C and Pressure 5 bar. All the models have same liquor ratio, functions, specific performance and are of the same modular design. They can be coupled together.All the used for the manufacture of the Dyeing Machines, together with their components and equipment are made of AISI 316 & 316 L stainless steel. Liquor Circulation : Is achieved by means of a high flow rate centrifugal pump with Inverter drive. Variable liquor flow rate is made possible and optimum dyeing results depend upon the type of material being dyed and type of dyestuffs used. With help of inverter drive it is possible to reduce electrical power consumption upto 30% as compared to fixed RPM motor drive. Reversal of Flow : Liquor flow direction is reversed automatically at preset time~ intervals from inside out to outside in vise-verse according to requirement.Material to Liquor Ratio : Programmable and adjustable M:L ratios in rage from 1:4 upto 1:7 are possible. Lower liquor ratio means saving on cost of water, chemicals and energy consumption. The shorter the liquor ratio the lesser the cost of overall dyeing. Air Pad System : By compress air static pressure is obtained and system is pressurized. Material carriers are fully flooded in the dye vat. Variable Loading : A high economic efficiency can be achieved with a constant liquor ratio by simply adjusting the filling level and by using the same material carrier, a smaller amount of material can be dyed. Heat Exchanger : Indirect heating and cooling coil is provided for rapid rise of temperature upto 4 C per minute at steam pressure of 7 Kg / cm2. Heating of liquor is homogenous. Service Tank : A Service tank is provided for feeding dyestuff and chemicals to the dye vat by means of an injection pump. At the top of the tank perforated pipe is mounted for washing of walls. Dispensing System : Linear as well as progressive dosing as per program is possible.Drain : Hot and cold drains have been segregated that installation of heat recovery system is possible. High temperature drain provided so as to eliminate formation of Oligomers while using Dispersed dyes at high temperatures. Rinse : Overflow Rinses provided to remove dirty liquor continuously by having through wash of the material. Carriers : For cone sand cheese,ropes, silver, tops, warp beam sand loose stock with variable loading package carriers. Control System : Fully automatic computerized control system is supplied to increase productivity by reducing production cost & improve flexibility. It offers manual operation, logical functions can done manually Along with the Machine, software of standard dyeing programmed for different type of material is provided or you may feed the new programmed as per your dyeing cycle-Operation by alpha numerical key board or from control panel.Eco-Friendly Machine : Since the pump and Carrier volumes are flooded and low water steam, power consumption and very limited effluents, this, machine is more, Ecology and environment friendly. Venkteshwara manufacturing pneumatic press in duel version 1) Simple Press 2) Motorise Press for package and Top suitable for 25 Kg. to 125Kg. Pressing. Venkteshwara manufacturing all type of HT / LT Panels, PLC Panels & Logic control Panels also under take all type of Electrical turnkey project. Optional Sampling Device.Full capacity preparation tank.Hydro-Extraction in dye- vat.Online PH value measuring and controlling system.Automatic coupling system.Dye Kitchen Equipment.
...moreHydyaulics Press Machine
27,000 Per Set
01 Set(s) (MOQ)
We have attained a top notch position in Manufacturing, Exporting & Supplying Pneumatic Press. Our Pneumatic Press is precisely designed as per the industrial standards. We offer Pneumatic Press which is high in demand owing to its optimum quality, accuracy, durability and flexibility. Our Pneumatic Press is available at pocket-friendly prices. Types Normal Pneumatic Press Motorized Pneumatic Press : Keeping in mind Indian Process houses, we have developed Motorized Pneumatic Press with remote controlling for pressing the package from 25KG to 1250KG under 1 press. It eliminates the need of number of pneumatic press for number of carriers
Brand Name : Venkteshwara Brand
...moreHthp Dyeing Machine
42,000 Per 2 Set
2 Set(s) (MOQ)
we offer hthp dyeing machine which is quite popular among the clients. We manufacture hthp dyeing machine with & without programmer and gear motor to cater to the diversified needs of the customers. Our hthp dyeing machine is designed as per industrial standards which lends durability and strength to its construction. highlights sturdy construction durable low operating cost high efficiency
Brand Name : Venkteshwara Brand
...moreHTHP Beaker Dyeing Machine
Hot Air Dryer
Dye Springs
We hold expertise in manufacturing, exporting and supplying a wide range of Dye Springs. Made from top quality raw materials, Dye Springs offered by us is equipped with all the latest features. Dye Springs, that we offer, are accurately dimensioned as well. Venkteshwara manufactures a range of high quality Venkteshwara stainless steel dyespring with technology from Davidson Industries U.K. Venkteshwara Dyespring are manufactured from superior AISI302/304 grades of stainless steel for dyeing operations, and AISI316 for dyeing and bleaching, withwirediameter tolerance of one micron or less. The main coil wire is made on Swiss coiling machines. This ensures consistent international diameter of the firstand the last spring. The main coil wire isalso laced on Modern lacing machines, thus liminating wobbling on the winding machine. Venkteshwara Dyespring come in a wide range custom built to suit individual winding and dyeing machine requirement. The range includes radially compressible dyespring for flat yarns & high-shrinkage yarn sand specially designed conical dyesprings for high-speed auto coners. Special Feature Dimensional Stability : Fully heat treated and stress relived to prevent deformation during continuous heavy duty operations at extremely high temperatures.Balance : Axially & radially balanced to ensure smooth, steady and vibration free running.Soft-Winding : Can be soft wound on various types of Winders from ordinary to automatic, Auto coners to open End spinning machines.Dyeing Quality : Equalizes densityvariation enabling even dye penetration.Compatibility : Compatible with all Textures and Twisting machines. Can be used effectively with High Frequency Dryers, Pressure Dryers or Rapid Dryers.Reduced Wastage : Enables yarns to unwind to the last layer.Economical : More economical than even Plastic Telescopes Tubes, Average life(3-5 years) longer than Plastic Dyespring.Environment Friendly : Recyclable material.
...morebeam dyeing machine
Autoclave Machine
Industrial Valves
Textile Machinery
yarn conditioning machine
