Strip Heaters Dealers in Mumbai

Industrial Strip Heaters provides greater surface area of length than round elements which means equipment can be designed with more wattage in less linear space. Or by replacing a round element with a strip heater of the same length, the watt density can be significantly reduced. In immersion applications, the narrow profile increases the natural convective flow of fluids, resulting in lower sheath temperature and improved heat transfer to the process.

PHP Mica Strip Heaters offered by us are high on demand in the market. The Mica Strip Heaters offered by us offers superior performance and higher life expectancy. These heaters are good for sheath temperature up to 250 C. The strip Heaters are available with various construction styles with various lead exit options. Also, clients can be benefited from the availability of Mica Strip Heaters at the competitive prices. Applications : Sealing EquipmentDie, Mould & other surface HeatingHot stamping, Hot PlatesFor use where surface contact on both side of heater if necessary Post Terminal Dimension And Location : Post Terminal are located 1/4" from edge of heated section either vertical , parallel or at opposite endsMounting holes may be located anywhere on the  heater as long as there is minimum of 1" between the edge of the hole and one side of the heater Options Available In Mica Strip Heater : S/S braided leads for flexibilityCustom mounting holesCeramic terminal coversSingle & Two Phase voltage Construction Mica Strip Heater - Fiberglass Leads :Fiberglass leads out same end center :10� lead standardLeads rated to 850oFLeads out same end edge :1/2" Sleeving at exitLeads out opposite end :1/2" Sleeving at exitLeads out at the top of heater :Brass eyelet where leads exit sheath1/2" Sleeving at exit

This is Basically a Heavy Duty Refractory insulated strip heater with locked on finns for fast transfer of heat to air as the surface contact area increases, also with this results in higher watt density. The finns also act as a cooling option in area where the temperature has to be precisely monitored. Features Finns act as a fast heat transfer and cooling process The option of GI, S.S.304 or S.S.316 finns Application In forced air ducts Blowers units Ovens Dryers

• Brand Name: Swaraj
• Material: Galvanize
• Application: Panel Board
• Color: Silver
• Voltage: 230V
• Condition: New
• Finishing: Anodized
• Power: 60 / 80 Watt

We are reputed sellers engaged in providing best quality products to our buyers at reasonable prices.

APPLICATION Dryers, Ovens , External heating for tanks & vessels. CONSTRUCTION Rectangular section heater, insulated with compacted MgO for quicker & even heating & better life span. Max. Watt density: 40 W/Sq. inch. Max. surface temp. 650° C

Easy to install with clamping bands or standard bolts and heavy duty clamps provides heat where you need it at accurately maintained temperatures. It is made of standard section 1 ½" to 1 916" by ¼" to 516" and length and load as per requirement.

Strip Heaters are made of Hi Grade Nichrome Wire insulated in Fluted refactory which possess Hi Thermal Conductivity sheathed in Rust Resistant steel along with Robust construction. Uses: Ovens, Drums, Dies and Cylinders for drying

We are a reliable Manufacturer and Supplier of high performance Strip Heaters. Strip Heaters, offered by us, are suitable for heating applications that require very high temperature. The design, material and construction of Strip Heaters ensure long life of Strip Heaters. Clients can avail precision made industrial Strip Heaters from us at very reasonable prices.

Strip Heaters are made of helically wound resistance coil evenly stretched and strung through series of ceramic insulators. Resistance coil is mechanically connected to screw terminals or lead wires for positive connection. The element assembly is electrically insulated and covered by metal sheathing. Features • Resistance wire (Nickel Chrome resistance wire optional)• Screw oR wire lead termination• Available in various sizes as per requirement: • Length Maximum 2000 mm.   Applications • Ovens• Hot plates• Moulds• Dies • Drying• Melting• Baking• Incubators • Food Wormers• Air Heating• Sealing Bars• Load Banks.

We offer Rubber Hydraulic Press Strip Heater. Strip Heater for Rubber Hydraulic Press. (Mica Insulated) Strip Heaters are the Nichrome Ribbon insulated with mica which possess high thermal conductivity sheathed in rust resistant steel ection heating. USES: - Process Rubber making press, Hydraulic Press and Platens.

Uses : Strip heaters are designed for horizontal mounting position. As heating elements in various process machines, ovens, driers, textile machines, dies, rubber machineries for heating & drying of air, liquids, solids, powders & moisture protection in control H.V. cabinets, for efficient baking curring of paints enamels, lacquers, varnish, adhesives etc.Construction : The sheathing is heat-treated mild steel or stainless steel or any other metal or alloy as per requirement. Insulating medium is either refractory or mica. The heater width is 1.11/2" to 2" but recommended widths & length are available. Terminal connections are provided either at one or at each end.Working Temperature : Applicable 250°C.While Placing Order : Please mention diameter, length, wattage, voltage, lead wire length, special features if any.

• Application: Process machines, ovens, drums, dies, platens, pipelines, rolls, kettle tanks, cylinders and nozzles, air heating, industrial drying preheating.

design easy to install with clamping bands or standard bolts and heavy duty clamps provides heat where you need it at accurately maintained temperatures. It is made of standard section 1 ½" to 1 9/16" by ¼" to 5/16" and length and load as per requirement. also available in ceramic insulation.   application    process machines, ovens, drums, dies, platens, pipelines, rolls, kettle tanks, cylinders and        nozzles, air heating, industrial drying preheating.

We offer a wide range of Strip Heater.These heaters are constructed using high class raw material and vastly recognized for its durability and sturdy construction.For best dissipation of heat,fins are also fitted.

We are the reputed supplier and importer of MICA H-760-A in India - Contact us now to Get Quick quote for High performance, high solids, water-based PEI primer in India by MICA Corporation

Being a noteworthy enterprise of this industry, we are offering a vast gamut of Strip Heaters to our esteemed clients. The offered heaters are provided with insulation of asbestos or ceri wool, reducing the heat loss. Our products can be customized as per client's demands.

Description: Vinman Strip Heaters are designed and manufactured with more than 25 years of experience for superior performance and life expectancy., As a manufacturer specialized in industrial electric heating elements & the desire to provide quality products and services to our customers both OEM’s & End Users, Vinman specializes in designing Strip Heaters, Nozzle Heaters, Ceramic Band Heaters & Mica Band Heaters to your exact specifications. Depending upon applications Vinman Strip Heaters are manufactured with high temperature oxidation metal sheath and high grade mica insulation resistant to moisture and high temperatures. A superior grade NiCr resistance wire is evenly wound to provide uniform and reliable heat distribution with best combination of physical strength, high emissivity & good thermal conductivity, good for sheath temperature up to 250Deg C. Vinman strip Heaters are available with various construction styles with various lead exit options. Features : 1. High Temperature oxidation metal sheath. 2. Sealing Equipment. 3. Dia, Mould & other surface Heating Applications. 4. Hot stamping, Hot Plates. 5. For use where surface contact on both side of heater if necessary. Applications: 6. Sealing Equipment. 7. Die, Mould & other surface Heating. 8. Hot stamping, Hot Plates. 9. For use where surface contact on both side of heater if necessary. Post Terminal Dimension and Location. 1. Post Terminal are located 1/4" from edge of heated section either vertical , parallel or at opposite ends 2. Mounting holes may be located anywhere on the heater as long as there is minimum of 1" between the edge of the hole and one side of the heater. 3. Please Provide drawing for hole dimensions and locations. Options Available In Mica Strip Heater: 1. S/S braided leads for flexibility. 2. Single & Two Phase voltage Construction. 3. Custom mounting holes. 4. Ceramic terminal covers. Fiberglass Leads 1. Fiberglass leads out same end center. 10” lead standard. Leads rated to 850°F. 2. Leads out same end edge. 1/2" Sleeving at exit. 3. Leads out opposite end. 1/2" Sleeving at exit. 4. Leads out at the top of heater. Brass eyelet where leads exit sheath. 1/2" Sleeving at exit. Ordering Information 1. Quantity 2. Width & Length 3. Volts & Watts 4. Lead wire or Post Terminal Design 5. Mounting Holes or slots 6. Special construction For more information please visit our website www.phpheat.com
