Vacuum Circuit Breaker Panel Dealers in Mumbai

Panels are designed in accordance with ABB’s guidelines and as per IEC IS Standards. Compact and Robust Cassette mounted CB of ABB make with draw out feature with cubicle front door closed Complies Complies to latest standards standards of IEC 62271‐200 Modular structure with metal clad design with inter panel metal segregation Lockable Automatic Safety Shutters for Breaker Compartment Mechanical indication of test and service positions Long mechanical life with sturdy and proven operating mechanism Electrical anti‐pumping

• Reted Voltage: 12kv, 36kv, 40.5kv

Virtually maintenance free, High availability through spring charge spring operated mechanism, Single unit - easy to transport & ready to install, Simple & safe to operate, Modular construction for ease to maintain, Compact & rugged design for outdoor application, Well proven vacuum interrupters for switching functions, Long electrical & mechanical life, Adequate ground & sectional clearances as required, Suitable for rapid auto-reclosing duty

Separately lockable shutters for bus and cable side. Access to cable terminals from rear. Guaranteed voltage withstand without conductor insulation .Top lifting arrangement for panel. Conforms to IEC Standard. The breaker cannot be moved from test to service position unless the breaker compartment door is closed The breaker cannot be moved from test to service position or vice versa with breaker in closed condition. The breaker cannot be closed in-between test and service position. The breaker compartment door cannot be opened when the breaker is in service position or in between service & test positions.

Simple, compact & sturdy Reilable vacuum technology for switching Maintenance free and high reliability Complies to IP55 Degree of Protection Long electrical mechanical life Conforms to IEC 62271-100 IS 13118 Compatible for remote and SCADA operations

• Voltage: Up to 17.5 kV
• Rated Current: Up to 4000 A

Medium Voltage Switchgear is in our DNA. CG has over 50 years of experience in the design and manufacturing of MV Switchgear. Power distribution area has been one of the strongholds for CG Medium Voltage (MV) Switchgear Division since its inception in 1985. We pioneered the arrival of vacuum technology in India with vacuum interrupters. Our endeavour is to provide customers the best quality VCB with minimal price. We also offer Mid Mounted Switchgear (Calix VCB in CG-Novitas panel) with lesser footprint in 12kV and 24kV voltage level. Our best in class VCBs are type tested for class E2 ,C2 & M2 with internal arc fault protection for 1 sec.

We offer half panels and sub-cubicles for 11kV. The VCB is ‘draw out’ type and can be racked out directly on the floor. VCBs are type tested according to International Standards IEC-62271 at renowned laboratories. They are compact, safe and reliable. The sub-cubicle is VCB with its compartment having all safety interlocks. The half panel is an assembly of the medium voltage compartments except for low voltage compartment.

• motor voltage: 230V AC and 110V DC/220V DC

We offer half panels and sub-cubicles for 11kV. The VCB is ‘draw out’ type and can be racked out directly on the floor. VCBs are type tested according to International Standards IEC-62271 at renowned laboratories. They are compact, safe and reliable. The sub-cubicle is VCB with its compartment having all safety interlocks. The half panel is an assembly of the medium voltage compartments except for low voltage compartment.

VCB Panel, Industrial Starter Panels, Feeder Pillar Panels, ACB Panel

Indoor VCB Panel, Vacuum Circuit Breaker Panel, Vacuum Circuit Breakers

Outdoor VCB Panel, Electrical AMC, HVAC Engineering Services

VCB Panel, PID Temperature Controller, Electrical Distribution Board

Schneider VCB Panels, Vacuum Circuit Breakers AMC Services
