Vacuum Circuit Breakers Dealers in Mumbai

• Voltage: 22kV/33kV
• Rated Current: 800-1600A
• Brand: Siemens/BEL
• Frequency: 50-60 Hz
• Mounting Type: As Per Standard
• Nominal system voltage: 11kV/22kV/33kV
• Minimum protected creepage distance: 580mm

Compact, sturdy with an adaptable design Maintenance free & high reliability Total compartmentalized design. Provision of discharge flap with wire mesh Provision of safety interlocks Long electrical and mechanical life Conforms to IEC 62271-100 & 200 IEC 606094 IS 13118 Compatible for remote and SCADA operations

We offer vacuum circuit breaker. Sub-cubicle for system voltage 11kv and a short time current rating of 26.3ka half panel for system voltage 11kv and short time current rating of 26.3ka and 40ka half panel comes with an option of copperaluminium bus-bar vcb current rating upto 3150a provision of manual and electrical spring charging in vcb spring charging motor voltage 230v ac and 110v dc220v dc closingtripping coil voltage 24v dc110v dc220v dc vcb comes with inbuilt anti-pumping feature

Salient Features of 36kv Vacuum Circuit Breaker Type tested & Conforms to IEC 62271-100,IS 13118 Simple,compact & Easy to operate Arc interruption in vacuum. Robust porcelain bushing for higher insulation levels. IP55 cabinet housing for spring charged mechanism & Controls. Galvanised Steel Support structure,extendable for CT / PT. Local / Remote Control & Relay Panel. A simple motor charged spring operating mechanism noted for its high performance reliability. Trip free mechanism suitable for repeated auto re-closing duty.

Crompton Greaves (CG) is pioneer in introducing Vacuum Interrupters (VI) and Vacuum Technology in India. In Technical collaboration with then Westinghouse, USA, CG started Vacuum Interrupter manufacturing way back in 1985-86 at its State of the art manufacturing facility at Aurangabad in Maharashtra State. After the technical collaboration period, CG extended its range from 1kV to 72.5kV today to cover all applications with a dedication and continuous Research and Development activity. Since last 30 years, CG has continuously invested in adding the manufacturing capacity to take its annual capacity today to manufacture more than 170,000 Nos. of Vacuum Interrupters. CG is market leader in India & more than 1.5 Million Vacuum Interrupters are in service in & outside India. CG is a regular supplier of VIs to all small & major switchgear manufacturers in India and also an exporter to USA, Europe, Middle East and South East Asia countries.

• motor voltage: 230V AC and 110V DC/220V DC

We offer half panels and sub-cubicles for 11kV. The VCB is ‘draw out’ type and can be racked out directly on the floor. VCBs are type tested according to International Standards IEC-62271 at renowned laboratories. They are compact, safe and reliable. The sub-cubicle is VCB with its compartment having all safety interlocks. The half panel is an assembly of the medium voltage compartments except for low voltage compartment.

We offer half panels and sub-cubicles for 11kV. The VCB is ‘draw out’ type and can be racked out directly on the floor. VCBs are type tested according to International Standards IEC-62271 at renowned laboratories. They are compact, safe and reliable. The sub-cubicle is VCB with its compartment having all safety interlocks. The half panel is an assembly of the medium voltage compartments except for low voltage compartment.

• Reted Voltage: 12kv, 36kv, 40.5kv

Virtually maintenance free, High availability through spring charge spring operated mechanism, Single unit - easy to transport & ready to install, Simple & safe to operate, Modular construction for ease to maintain, Compact & rugged design for outdoor application, Well proven vacuum interrupters for switching functions, Long electrical & mechanical life, Adequate ground & sectional clearances as required, Suitable for rapid auto-reclosing duty

Panels are designed in accordance with ABB’s guidelines and as per IEC IS Standards. Compact and Robust Cassette mounted CB of ABB make with draw out feature with cubicle front door closed Complies Complies to latest standards standards of IEC 62271‐200 Modular structure with metal clad design with inter panel metal segregation Lockable Automatic Safety Shutters for Breaker Compartment Mechanical indication of test and service positions Long mechanical life with sturdy and proven operating mechanism Electrical anti‐pumping

• Rated Current: 630-2500 A
• Rated Voltage: 22 KV
• Mechanical life time: 20000 Times
• Average opening speed: 0.6-1.1 m/s
• Average breaking speed: 1.1-1.7 m/s
• Breaking time: 0.1 s
• Maximum working voltage: 24 KV
• Packing Type: Box
• Features: Consistent operation, Outstanding performance, Noiseless operation Request Callback

We are offering medium voltage vacuum circuit breakers. We have a wide range of vcb from 3.3 kv upto 33 kv, with str upto 31.5 ka. products are type tested from nabl certified labs like cpri & erda.

VCB Panel, industrial starter panels, feeder pillar panels, ACB Panel

Indoor VCB Panel, vacuum circuit breaker panel, Vacuum Circuit Breakers

Vacuum Circuit Breakers, Push Buttons, Indication Lamps, Rotary Cam Switches

Vacuum Circuit Breaker, Short circuit breaker, Oil Circuit Breaker

Outdoor VCB Panel, Electrical AMC, HVAC Engineering Services

Schneider VCB Panels, Vacuum Circuit Breakers AMC Services

abb vacuum circuit breaker
