infra systems Anandvalli, Nashik, Maharashtra

Brand INFRA Model Name/Number SLC1220 Technique Infrared Sensor Range Of Product Safety Light Curtains, Infrared Sensors Automation Grade Automatic Weight 2 Kg Response Time 10 - 20 m sec. (Sensor) Color SAFETY Yellow

Country of Origin : India

Type : Light Barrier

Material : ALUMINUM

Thickness : 20-40mm

Certification : ISI Certified, industrial

Color : Yellow

Condition : New

Brand INFRA Model Name/Number SLC1220 Technique Infrared Sensor Range Of Product Safety Light Curtains, Infrared Sensors Automation Grade Automatic Weight 2 Kg Response Time 10 - 20 m sec. (Sensor) Color SAFETY Yellow   Specifications:   Power Supply : 24 V DC Supply Protection : Reverse Polarity Output : PNP output 100 mA at 24 V dc Output Protection : Short Circuit, Overload Output Indications : Through LEDs Response Time : 10 - 30 m sec. (Sensor) Restart : Automatic No of elements : 4,6,8,10,16,24,32 nos Beam By Pass : Provided for hand protection models Protected Heights : 90 - 1710 mm Pitch offered (mm) : Hand: 20/30/40/50, Finger: 20LX, Body: 90 Max Range : Adjustable up to 3 mtrs (5 mtrs max possible) Electrical Connections : Plug in Connector for Emitter & Receiver Standard Cable length : 5 meters for Emitter, 3 metes for Receiver Operating Temperature : up to 55 Degrees centigrade Electronic Switches offers new generation Safety Light Curtains / Safety Guards based on advanced micro controller technology. These are available in two types. Parallel Beam ( SLC : type II beam ) and Cross Beam ( LX : type x beam ). For the same protected height, Cross Beam Light Curtains are more sensitive as there are more number of active beams in the same area. Easy to install & may be mounted in any position with non-critical alignment between sensors. Switches are provided for blanking / by-passing individual channels. Sensors can be connected directly to PLC for further interlock

Country of Origin : India

Type : Safety Sensor

Material : Metal

Certification : CE Certified

Color : Yellow

Condition : New

Power : 12-24 VDC

Packaging Type : Paper Boxes

Warranty : 1 Year

Automation Grade : Automatic

nfra systems, offers new generation Safety Light Curtains / Safety Guards based on advanced micro controller technology. For the same protected height, Cross Beam Light Curtains are more sensitive as there are more number of active beams in the same area.

Country of Origin : India

Type : Safety Light Curtains

Application : Industrial

Color : Yellow

Feature : Durable

Voltage : 220V

Power : 10Wt

Power Source : Electric

Certificcation : ISI Certified

Brand Name : infra

Output : PNP

Infra systems, offers new generation Safety Light Curtains / Safety Guards based on advanced micro controller technology. For the same protected height, Cross Beam Light Curtains are more sensitive as there are more number of active beams in the same area. Power Supply 12 - 24 Volts DC Supply Protection NReverse Polarity Protected Output PNP or NPN / NO or NC Output Indications Through LEDs channel Indication LED indication for each channel Response Time On to Off : 10 - 15 m sec. Off to On : 50 - 100 m sec No of beams 4, 6, 8, 10 , 16, 20, 16, 24, 32, 40, 48, 56, 64 Beam By Pass Provided in hand/body protection models Protected Heights 150-1500 mm Pitch offered 20, 30,40, 50, 90mm Adjustable Range Up to 3 meters (Higher range up to 40 meters available) Standard Cable length 5 meters for emitter, 3 meters for receiver Operating Temperature Up to 55 Degrees centigrade Cross Section 36 x 42 mm Electrical Connections Plug in Connector for Emitter Receiver Applicable to Directly work with PLCs / Controllers Protections Output short circuit protected. Suitable for Machines with quick emergency stop

Country of Origin : India

Type : Safety Light Curtains

Application : Industrial

Color : Yellow

Feature : Durable

Voltage : 220V

Power : 10Wt

Power Source : Electric

Lighting Type : LED

Certificcation : ISI Certified

Brand Name : infra

Output : PNP
