Stability Chamber Dealers in Nashik

• Automatic Grade: Automatic
• Driven Type: Electric
• Model: CBh4k
• Temperature Range: 20 to 60 degree C
• Accuracy: ± 0.2 degree C
• Uniformity: ± 1degree C
• Humidity Range: 40 to 90% RH

Equipment : PLC based Humidity chamber (Walkin type) (Also available in controller based ) Control system : Allen Bradley PLC controlling temperature and humidity. Also connected to IOT device to access chamber via mobile Humidity system : A steam generation tank followed by a reservoir water tank generates steam and make a non-condensing steam injection system to the chamber. A standby humidity system will be provided for continuous function during fault Refrigeration system : An eco-friendly refrigerant (R-134) is used in a compressor which satisfies the requirement of CFC free cooling system. Copeland (Emerson) make compressor will be hermetically sealed and coupled with evaporation coil& condenser. A standby refrigeration system will be provided for continuous function during fault Air circulation : To get an uniform temperature & humidity a centrifugal blower connected to a motor will blow the steam & air from up to down, controlled by PLC Heating system : SS. U shaped nichrome wire Insulation : 80 mm sheet of PUF (Poly Urethane Foam) Trays : Stainless steel perforated or wire mesh as per the requirement. Trays will be adjustable as per sample size Illumination : LED light is provided for bright illumination and low power consumption Fault Indications : Audio visual indication is provided for all types of fault occur in the chamber Validation port : A 60 mm port hole sealed with silicon rubber is provided on the side wall of chamber for validation purpose Sensors : Hygroflex sensor to sense both temperature and humidity software : CDAQ complying 21 CFR part 11   Optional features To avoid critical conditions and for ease of operation Hooter GSM technology Extra trays Extra sensor   Certification : ISO 9001:2015   Wireless access : A direct access to chamber is possible via mobile using IOT device

• Type: Environmental Test Chambers
• Certification: CE Certified, ISO 9001:2008
• Voltage: 220V, 440V
• Condition: New
• Warranty: 1year
• Brand Name: Mack
• Voltage: 200-250 Volt
• Usage: Pharmaceutical Industries
• Uniformity: +1.0 °C / +3.0 % RH
• Temperature Range: 20°C - 60 °C
• Humidity Accuracy: +5.0% RH
• Capacity (L): 100 to 25000

• Range: 20°C to 50°C
• 40%RH to 85%RH: Accuracy
• <= +/- 0.2°C: <= +/- 2.0%
• Uniformity: <= +/- 1.0°C

Panel Construction Tongue and groove type PUF insulated sandwich panel with cam lock. The Equipment interior is constructed with stainless steel 304 grade finish-4 and exterior is constructed with pre coated GI sheet/ stainless steel 304 grade finish-4. Construction Double wall inner tank and outer body is dynamically designed from strength and working point of view. The Equipment interior is constructed with stainless steel 304 grade mirror finish and exterior is constructed with powder coated GI sheet/ stainless steel 304 grade finish-4. Tray Stainless steel perforated tray with intervals of ½" height adjustment for better sample storage. Door Heavy duty outer insulated door installed with imported hinges and lock for easy operation and inner glass door with latch to observe samples without disturbing the set condition. UV & Florescent lights • As per ICH Guidelines-1.2 Million Lux/Hours of visible light and 200 watt Hr/m2 of UV light. Auto shut Off after specified exposure level. • Individual PLC based timer is provided to switch ON/OFF UV and Florescent lights as required. • UV light is switched off automatically once inner glass door is opened. • Samples can be tested under Fluorescent light or U.V. lights separately as well as combine. PLC based control system • 4.3” HMI with TFT LCD Colour touch screen • Communication via Ethernet • PLC based auto tune facility • PLC Based Safety cut off • User based Alphanumeric password protection through HMI • Rotronic make 4 to 20 mA sensors

• Temperature: 20°C - 50°C

Photostability Chambers are designed specifically to meet ICH & FDA requirements for Photostability testing. Near UV & visible light testing is Approved Approved performed simultaneously according to ICH Q1B option 2.UV lights get switched off automatically once the door is opened.You can test the samples on Fluorescent light or U .V lights separately as well as simultaneously.Uniform light distribution & high intensity levels allow quick response for forced degradation testing and confirmatory studies.
