Water Pouch Packing Machine
Get Price Quote
Product to be filled in Water Pouch Packing Machine
This Water Pouch Filling Machine model is suitable for packing water, artificial fruit juice, flavored milk, lassi in LDPE packing material
Description of Water Pouch Packing Machine
We are leading water pouch packing machine manufacturers providing this is fully automatic water packing machine designed for packing liquid in LDPE film, commonly known as milk packing machine. The film roll mounted on backside of machine, after unwinding mechanism film passes through series of free roller.Film will be folded in folding collar box to get shape of pouch, center sealing will be by vertical impulse strip sealer. Pulling and pouch length of the machine depends on rubber roller pulling assembly driven by eccentric cam which is adjustable.Then desired quantity of liquid is filled in ready formed tube, controlled by gravity fill electromagnetic valve and timer.Horizontal sealing as well as cutting will be done rod type impulse sealer.
Technical Information About Water Packing Machine
Construction of Water Packing MachineIn economy model complete body and covers in mild steel powder coated Only front of machine and all contact parts will be made in stainless steel
Water Packet Packing Machine output2500 pouches per hour for 200 ml to 500 ml packing
Water Pouch Machine Filling Range200 ml to 500 ml adjustable
Filling system of Water Packing MachineGravity fill electromagnetic filling system with timer
Packing MaterialVirgin co-extruded multilayer LDPE film, food grade
Open width of roll325 mm
Pouch width150 mm
Film core ID76 mm
Film roll weightMaximum 20 kg
Machine controlSimple electrical panel microprocessor controlled circuits
Sealing styleStandard vertical overlap
Main driveMechanical machine all sealing, pulling and filling system will be gear driven interlocked with each other
Power supply230 VAC, 50 Hz, earthing
Motor Drive0.5 Hp, Single phase Lawkim/Crompton Greaves Motor with suitable reduction gear box
HeatersImpulse heaters
Machine size1500 mm X 1000 mm X 2350 mm
Nett Weight of machine250 Kilogram
Optional arrangements
• Complete S S machine
• 500 ml to 1000 model
• Online printing,
• Pouch counter
• 4 KVA voltage stabilizer
• Hygienic dairy pump
We are leading Water Packing Machine manufacturer and supplier in Mumbai, India, Contact us to know the best price of the Water Pouch Packing Machine.
