vacuum filling machines
Get Price Quote
1 Piece(s) (MOQ)
We manufacture a versatile filling machine for volume filling applications. The machine is called vacuumetric filler. Very useful filling machine designed for alcohol, perfumes, and distillery industries. Here, the machine works on the basis of vacuum suction from the container. Fast filling of any glass bottles can be done by using this machine. Various volumes can be filled by adjusting the height of bottle holder and by adjusting the vacuum filling nozzle. Machine structure and working: complete machine frame is made from mild steel angle structure, welded, and finished with polymer. Total frame structure is covered by stainless steel sheet metal of good gauge and finish. A ΒΌ hp 230vac oil cooled vacuum pump is providing the vacuum required during filling. This unit is mounted inside the frame with cover, so that the noise is maintained to a minimum during working. all the other parts like, liquid overflow trap, fill nozzles, are mounted over the frame structure. All material contact parts are made from stainless steel 304 qualities or 316 material as per specifications. A trap vessel with suitable capacity is mounted at one side of the top to collect the overflow liquid from the bottles. Fill nozzles are comes in pairs like, 2, 4 as per fill requirement. Various fill volumes can be filled at a time as per adjustment. Also, the fill nozzles are capable to tilt to upto 90 degrees for easy filling. Machine is easy to operate. The glass bottle to be filled is to be pressed towards the fill nozzle, where a gasket is provided. When the bottle is vacuumised, the liquid is filled fast into it. The fill level is maintained as per the nozzle height adjustment inside the bottle. No maintenance is required since, there is no moving parts is involved. Most economical for level filling applications.
