SMG chucks Chachoki, Phagwara, Punjab

Product description standard jaws chucks supplied with one set forward & one set reverse is used in production jobs. Material construction : * body : semi steel bodies are manufactured from high tensile grade 25 cast iron, hardness 180-210 bhn. * jaws : jaws are made of low carbon case hardening steel and harden in modern heat treatment plant, hardness 55-62 hrc. * scroll : scroll plates are manufactured from forged wear resistant alloy steel, hardness 40-45 hrc. * pinion : pinions are made of case hardening alloy steel hardness 40-45 hrc. Special features : * knob & jaws ways of body hardened & ground. * scroll bore & threads precision ground from both sides. * jaws teeth precision ground form both sides. * hardened & ground pinion. * accuracy less than 0.04 mm from 160-315 mm chucks. * parts interchangeable.

Size : Other

Application : Other

Material : Metal

Color : Other

Condition : New

Finishing : Polished

Shape : Round

Type : Self Centering Chucks

THESE CHUCKS ARE SUPPLIED 2, 3, 4 & 6 JAWS. THE JAWS ARE MADE IN TWO PORTIONS. THE ONE IS BASE HARD JAW FITTED IN THE BODY. ONE SET OF TOP HARD REVERSIBLE AND ONE SET OF TOP SOFT JAW ARE SUPPLIED WITH EACH CHUCK. TOP HARD REVERSIBLE & TOP SOFT JAWS ARE MOUNTABLE IN THE SAME BASE HARD JAW WITH ALLEN BOLTS PROVIDED WITH THE CHUCK. THE ADVANTAGE OF THESE CHUCKS IS THAT USER CAN MODIFIED THE SOFT JAW AS PER THEIR REQUIREMENT. MATERIAL COMPOSITION : * BODY : SEMI STEEL BODIES ARE MANUFACTURED FROM HIGH TENSILE GRADE 25 CAST IRON, HARDNESS 180-210 BHN. * JAWS : JAWS ARE MADE OF LOW CARBON CASE HARDENING STEEL AND HARDEN IN MODERN HEAT TREATMENT PLANT, HARDNESS 55-62 HRC. * SCROLL : SCROLL PLATES ARE MANUFACTURED FROM FORGED WEAR RESISTANT ALLOY STEEL, HARDNESS 40-45 HRC. * PINION : PINIONS ARE MADE OF CASE HARDENING ALLOYS STEEL HARDNESS 40-45 HRC. SPECIAL FEATURES OF TURNO PLUS : * KNOB & JAWS WAYS TO BODY HARDENED & GROUND. * SCROLL BORE & THREADS PRECISION GROUND FROM BOTH SIDES. * JAWS TEETH PRECISION GROUND FROM BOTH SIDES. * HARDENED & GROUND PINION. * ACCURACY LESS THAN 0.04 MM FROM 160-315 MM CHUCKS. * PARTS INTERCHANGEABLE.

Technical features : * body : made from high strength cast iron and machined within tolerance for accurate fitting of jaws, screw and screw and screw lock hardness 180-210 bhn. * jaws : jaws are made of low carbon case hardening steel and harden in modern heat treatment plant. Jaw's slots are ground for accurate fitting and long life. Hardness 55-60 hrc. * screw : made from case hardening alloy steel and harden and ground bearing areas for longer life. * screw lock : case hardened steel and harden to provide longer life.
